OPERATOR'S MANUAL
Revision #01
5215 Starting Serial #912TS15011
H&S MANUFACTURING CO.,INC.
Top Shot
5215
WARNING
Manufactured By
2608 S. HUME AVE. MARSHFIELD, WI 54449
(715) 387-3414 | hsmfgco.com
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.
HSMFG1218
Part #79845

Advertisement

Table of Contents
loading

Related Manuals for H&S Top Shot 5215

Summary of Contents for H&S Top Shot 5215

  • Page 1 Top Shot 5215 OPERATOR’S MANUAL READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS EQUIPMENT. UNSAFE OPERATION OR MAINTENANCE OF WARNING THIS EQUIPMENT CAN RESULT IN SERIOUS INJURY OR DEATH. Revision #01 HSMFG1218 Part #79845 5215 Starting Serial #912TS15011 Manufactured By H&S MANUFACTURING CO.,INC.

  • Page 2: Table Of Contents

    CONTENTS Warranty ..............1 Manufacturer’s Statement .

  • Page 4: Manufacturer's Statement

    H&S reserves the right to make changes or add improvements to its products at any time without incurring any obligation to make such changes to products previously manufactured. Specifications, statements and descriptions of Products contained in this publication are subject to change without prior notification.
  • Page 6 Intentionally Left Blank...

  • Page 7: Dealer Pre-Delivery Checklist

    H&S DEALER PRE-DELIVERY CHECKLIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS After the Top Shot has been completely set up, check to be certain it is in correct operating order before delivering to the customer. The following is a list of points to inspect. Check off each item as you have made the proper adjustments and found the item operating satisfactorily.
  • Page 8 Intentionally Left Blank...
  • Page 9 H&S DEALER DELIVERY CHECKLIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS This checklist that follows is an important reminder of valuable information that should be passed on to the customer at the time this machine is delivered. Check off each item as you explain it to the customer. This delivery checklist, when properly filled out and signed assures the customer that the Pre-Delivery Service was satisfactorily performed.
  • Page 10 Intentionally Left Blank...

  • Page 11: Safety Information - Be Alert Symbol

    SAFETY INFORMATION ALERT! YOUR SAFETY IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.

  • Page 12: Explanation Of Safety Signs

    SAFETY INFORMATION Keep signs in good condition. Immediately replace any missing or damaged signs. RECOGNIZE SAFETY INFORMATION This is the safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices.

  • Page 13: Safety Decals

    SAFETY INFORMATION -11-...
  • Page 14 SAFETY INFORMATION -12-...

  • Page 15: Safety Information - Warning - Owner Must Read And Understand

    TRACTOR: This Operators Manual uses the term “Tractor” when identifying the power source. W A R N I N G TO PREVENT SERIOUS INJURY OR DEATH BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE SAFETY PRECAUTIONS.

  • Page 16: Cap Screw Torque Values

    -14-...

  • Page 17: Set-Up & Assembly

    SET-UP & ASSEMBLY WARNING: Some photographs used in the following pages show guards or shields removed for clarification. Never operate machine until these guards or shields are in proper operating position. NOTE: Determine right or left side of the Manure Spreader by viewing it from the rear. If instructions or parts lists call for hardened bolts, refer to the Cap Screw Torque Value page to identify.

  • Page 18: Transporting

    TRANSPORTING REFLECTORS Red reflective safety decals and an SMV sign are on the rear of the tank for safety. SAFETY CHAIN (Optional) Follow state and local regulations regarding use of a safety chain and transport lighting when towing farm equipment on public highways. A proper safety chain should be used to retain the safety connection between the towing and towed machines in the event of separation of the primary attaching system.

  • Page 19: Preparing For Operation

    PREPARING FOR OPERATION PREPARING TOP SHOT Properly lubricate the Top Shot, check automatic oiler level and fill if necessary before operating. Refer to Lubrication Section of this Operator’s Manual for locations. Before loading material, adjust the hitch clevis to your tractor in order to obtain a level or forward position of the Top Shot tank.
  • Page 20 PREPARING FOR OPERATION TRACTION CONNECTIONS Tractor Hitch that it 1. The hitch of the Top Shot is designed for a standardized tractor hitch. Adjust the drawbar so is 13 to 17 inches above the ground. 2. Extend or shorten it so that the horizontal distance from the end of the tractor power takeoff shaft to the center of the hitch pin hole is 14 inches for 540 RPM PTO and 15-3/4”...
  • Page 21 PREPARING FOR OPERATION The Top Shot is equipped with a constant velocity telescoping PTO drive shaft. This constant velocity capability results in a smooth, quiet running drive line without power fluctuation. The Top Shot can only be properly hooked-up to a tractor which has PTO and hitch dimensions conforming to ASAE Standard S203.

  • Page 22: Operation

    OPERATION EMERGENCY SHUTDOWN In case a foreign object becomes lodged in the expeller or auger area, disengage the PTO. Stop the tractor engine, remove ignition key, and allow all mechanisms to stop before cleaning or working on the machine. If an object is lodged inside the tank, block-up the discharge gate and raise the conveyor auger before attempting to remove the object.
  • Page 23 OPERATION APPLICATION RATE The side discharge style Top Shot features a hydraulically operated discharge gate to control the material flow out of the tank and into the expeller. Several factors influence the rate of discharge and the spread pattern. These factors include: ground speed, type or consistency of discharge material, PTO RPM, and discharge gate opening.
  • Page 24 OPERATION UNLOADING & SPREADING Packed Material To unload and spread packed material and prevent unnecessary stress on the drive line components, observe the following guidelines: 1. Make sure the auger is completely lowered. 2. Engage the tractor PTO at as low an RPM as possible. Then, slowly bring the PTO up to the rated RPM.
  • Page 25 OPERATION CHAIN ROUTING & SPECS 1. Jackshaft Drive Chain 2. Auger Drive Chain 3. Expeller Drive Chain 4. Jackshaft Chain Spring Length - 9-1/2” 5. Auger Chain Spring Length - 13-1/2” - 15” 6. Expeller Drive Chain Deflection - 1/2”-3/4” ADJUSTABLE EXPELLER SHIELD All Top Shot models have a multi-position manual adjust expeller shield to direct material and provide...
  • Page 26 OPERATION CONTROLS & SAFETY EQUIPMENT Top Shots are provided with several features for operator safety and convenience. GUARDS & SHIELDS Whenever possible and without affecting the operation of the Top Shot, guards, shields and/or hinged shields have been used on this equipment to protect potentially hazardous areas.
  • Page 27 OPERATION HITCHJACK A jack is furnished with the Top Shot to support the machine when the tractor is disconnected and to adjust the hitch clevis to the tractor drawbar for hookup. The jack should never be used to support a loaded Top Shot. When the jack is not being used to support the Top Shot, it should be relocated to the...

  • Page 28: Adjustments

    ADJUSTMENTS DRIVE CHAIN IDLERS Expeller Drive Chain Idler The expeller drive chain is tensioned with an adjustable sprocket Idler. The chain is properly tensioned when the chain can be deflected 1/2” to 3/4” (13-19 mm) with hand pressure. NOTE: If an Idler fails to maintain proper tension, replace the worn chain.
  • Page 29 ADJUSTMENTS FRONT & REAR AUGER SLIDES The front and rear auger slide assemblies are retained by adjustment plates with diagonal slots. To adjust, loosen retaining hardware and drive the plates downward with a hammer until the slide assembly is snug against the tank, then retighten the retaining hardware. Grease the slide assembly to ensure a leak-free seal.

  • Page 30: Service

    SERVICE EXPELLER Periodically inspect the expeller teeth for wear or damage. Damaged, broken, or missing expeller teeth will cause excessive machine vibration. Consult with your local H&S dealer for additional ordering information. AUGER & EXPELLER SPEED OPTIONS The expeller input drive sprocket can be changed by raising the auger and then removing the sprocket that is retained by a snap ring and set screws.
  • Page 31 SERVICE Main Auger Shear Device The auger jackshaft hub is secured to the auger drive sprocket with two 5/16” x 1-1/2” grade 8 shear bolts and locknuts. Additional shear bolts are stored on the chain tensioner bracket. Shield open for viewing If the auger jackshaft bolts shear, proceed as follows: 1.

  • Page 32: Optional Equipment

    OPTIONAL FEATURES & ACCESSORIES NOTE: The optional features & accessories listed in this chapter, are shipped with separate instruction for installation, as applicable. 1000 RPM PTO DRIVE The Top Shot can be ordered from the factory with an optional 1000 RPM drive, as desired. AUGER SPEED OPTIONS Several different drive sprockets are available to change auger speeds to various spreading needs.

  • Page 33: Lubrication Guide

    LUBRICATION Become familiar with all lubrication points and establish a routine to ensure complete lubrication of the Top Shot. GENERAL INFORMATION IMPORTANT: Catch and dispose of fluid per local waste disposal regulations whenever service is performed on hydraulic components, valves, cylinders, hoses, etc. PTO ASSEMBLY Keep the male and female shafts of the PTO well-lubricated and free-sliding.
  • Page 34 LUBRICATION DRIVE CHAINS The drive chains are lubricated by the optional automatic chain oiler. Any time that the discharge door is raised, a specified amount of oil is sent to the brushes on each of the chains. The oiler is adjustable to set the amount that is being discharged.
  • Page 35 LUBRICATION GREASING There are numerous grease fittings on the Top Shot must be lubricated properly and often with a high-quality grease. Replace any missing or plugged grease fittings. Wipe dirt from the fittings before greasing to prevent the dirt from being forced into the bearing or pivot. Grease should come out around the shaft on sleeve type bearings.
  • Page 36 LUBRICATION Grease Fitting Locations - Grease Every 10 Hours (or Daily) Expeller Bearings (2 Places) ear Auger Bearing Rear Auger Slide Plate (4 Zerks) Expeller Pan Release Pivot Single or Tandem Axle Hubs Single or Tandem Axle Wheel Pivot (Each Side) -34-...

  • Page 37: Decal Location

    DECAL LOCATION Your H&S Top Shot was manufactured with operator safety in mind. Located on the Top Shot are various decals to aid in operation, and to warn of danger or caution areas. Pay close attention to all the decals on your Top Shot.
  • Page 38 DECAL LOCATION 71067 111209C DCAMB 71064 093020 71067 71064 DCAMB 111209C 71188B 093020 DCAMB 093366 -36-...
  • Page 39 DECAL LOCATION 51010 111209C 72203A LW112901 11599 71096 71089 DCAMB 9194B 1494J 66076 1494B 54033 9194A 3494A 1494A 1494A 11211176 11599 1494A 093020 081312 093020 -37-...
  • Page 40 DECAL LOCATION 5896B 111209A 1494L 8515 82602 9194A 82602 9194A 093020 -38-...
  • Page 41 DECAL LOCATION 11210A 51010 57803 DCAMB 111209B 1494K 093020 1494A 11211176 57803 093020 111209B DCRED 11210B 093020 -39-...
  • Page 42 DECAL LOCATION 11599 71085 111209C DCRED TFM97 DCRED 093020 093020 32320 51010 11599 58703 111209B 51010 -40-...

  • Page 43: Troubleshooting Guide

    TROUBLESHOOTING NOTE: This Troubleshooting Chapter presents problems, causes and suggested remedies beyond the extent of loose, worn or missing parts and it was developed with the understanding that the machine is in otherwise good operating condition. PROBLEM CAUSE REMEDY 1.) Material NOT Discharge gate is NOT Open gate.

  • Page 44: Service Notes

    SERVICE NOTES -42-...
