H&S HD Operator's Manual / Parts Book

T/a front unload forage box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD T/A FRONT UNLOAD
FORAGE BOX
OPERATOR'S MANUAL &
PARTS BOOK
READ
AND
UNDERSTAND
THIS
MANUAL
BEFORE
OPERATING
THIS
EQUIPMENT.
WARNING
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.
HSMFG0416
Manufactured By
H&S MANUFACTURING CO., INC.
P.O. BOX 768 • (715) 387-3414 FAX (715) 384-5463
MARSHFIELD, WISCONSIN 54449

Advertisement

Table of Contents
loading

Related Manuals for H&S HD

Summary of Contents for H&S HD

  • Page 1 HD T/A FRONT UNLOAD FORAGE BOX OPERATOR'S MANUAL & PARTS BOOK READ UNDERSTAND THIS MANUAL BEFORE OPERATING THIS EQUIPMENT. WARNING UNSAFE OPERATION OR MAINTENANCE OF THIS EQUIPMENT CAN RESULT IN SERIOUS INJURY OR DEATH. HSMFG0416 Manufactured By H&S MANUFACTURING CO., INC.

  • Page 2: Table Of Contents

    CONTENTS Warranty & Warranty Registration Card..........1-2 Dealer Pre-Delivery &...

  • Page 5: Dealer Pre-Delivery & Delivery Checklist

    DEALER PRE-DELIVERY CHECK LIST After the Forage Box has been completely set-up, check to be certain it is in correct running order before delivering to the customer. The following is a list of points to inspect. Check off each item as you have made the proper adjustments and found the item operating satisfactorily .
  • Page 6 INTENTIONALLY LEFT BLANK...

  • Page 7: Be Alert Symbol

    SAFETY INFORMATION ALERT! YOUR SAFETY IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE.

  • Page 8: Explanation Of Safety Signs

    SAFETY INFORMATION Keep signs in good condition. Immediately replace any missing or damaged signs. RECOGNIZE SAFETY INFORMATION This is the safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices.

  • Page 9: Danger - Warning Signs

    SAFETY INFORMATION HELP A A A VOID INJURY • READ & UNDERST T T AND THE T T ORS MANUAL H & S MANUF F WITH MODEL AND SERIAL NUMBER. • UNDERST T T AND ALL SAFETY W W W ARNINGS AND FUNCTION OF CONTROLS.
  • Page 10 SAFETY INFORMATION DO NOT GO NEAR LEAKS High pressure oil easily punctures skin causing serious injury, gangrene or death. If injured, seek emergency medical help. Immediate surgery is required to remove oil. Do not use finger or skin to check for leaks. Lower load or relieve hydraulic pressure before loosening fittings.

  • Page 11: Warning - Owner Must Read And Understand

    TRACTOR: This Operators Manual uses the term "Tractor" when identifying the power source. W A R N I N G TO PREVENT SERIOUS INJURY OR DEATH BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE SAFETY PRECAUTIONS.

  • Page 12: Warning - Emergency Stop

    SAFETY INFORMATION W A R N I N G TO PREVENT SERIOUS INJURY OF DEATH NEVER OPERATE THIS UNIT UNLESS EMERGENCY STOP FUNCTIONS PROPERLY EMERGENCY STOP In case of an emergency, pushing either the stop panel rearward (A), or pulling the trip cables (B) will stop cross conveyor, beaters, and main apron.

  • Page 13: Bolt Torque Chart

    -11-...

  • Page 14: Set-Up & Assembly

    SET-UP & ASSEMBLY WARNING: Some photographs used in the following pages show guards or shields removed for clarification. Never operate machine until these guards or shields are in proper operating position. NOTE: Determine right or left side of the forage box by viewing it from the rear. If instructions or parts lists call for hardened bolts, refer to the Cap Screw Torque Value page to identify.

  • Page 15: Transporting

    TRANSPORTING TRANSPORT LIGHTING & REFLECTORS WHEN TRANSPORTING ON THE HIGHWAY OR ROADS, PLACE SMV SIGN IN SOCKET PROVIDED AND REGULARLY CLEAN THE REFLECTIVE TAPE AT THE REAR OF THE FORAGE BOX. NOTE: Obey all state and local laws, concerning towed equipment, on public roads. TOWING ON HIGHWAY To view beyond the back of the Forage Box when transporting the unit on a public highway, consider obtaining and installing a rear view mirror on your tractor with a wide load mounting bracket.

  • Page 16: Preparing For Operation

    PREPARING FOR OPERATION Check over entire unit carefully before first operation. Tighten bolts, set screws, and chains which may have come loose in handing. Lubricate as explained in the Lubrication Guide. Successful operation will be achieved by periodic adjustments and experience of the operator. Make sure to read and understand all adjustments.

  • Page 17: Operation

    OPERATION GENERAL INFORMATION Check entire Forage Box carefully before first operation. Tighten bolts and set screws that might have come loose in transporting. Lubricate if needed as explained in the Lubrication Chapter in this manual. EMERGENCY SHUTDOWN In case of an emergency, pushing the emergency stop panel, emergency stop bar, or pulling the safety cable will stop cross conveyor, beaters, and main aprons.
  • Page 18 OPERATION OPERATION OF FRONT UNLOAD FORAGE BOX 1. Park the Forage Box on level ground whenever possible during unloading. Lock tractor parking brake 2. Connect the PTO to a tractor with a 540 PTO ONLY, locking securely in place as stated in the PREPARING FOR OPERATION SECTION.

  • Page 19: Adjustments

    ADJUSTMENTS MAIN APRON Main feeder apron adjustment bolts are located behind the convenient access door located in the bottom portion of rear tailgate . Remove handle nuts (A) to open access door and swing door downward . All apron chains must be taken up evenly before you use the forage box . Check again after the first few loads .
  • Page 20 ADJUSTMENTS TWIN AUGERS Proper tension should be maintained on the auger wipers and hold downs when operating forage box. To adjust wipers and hold downs, start with rear auger first. Loosen bolts (B) holding front wiper on rear auger, and slide wiper against flighting so end of auger can only be raised slightly.
  • Page 21 ADJUSTMENTS BEATER ENGAGE, APRON SPEED CONTROL LEVER This single lever (A) controls both beater engage/ disengage and the speed of the main feeder aprons. CAUTION: DO NOT ENGAGE BEATERS OR MAIN APRONS WHEN CROSS CONVEYOR IS FULL OF MATERIAL OR DAMAGE TO FORAGE BOX WILL RESULT.
  • Page 22 ADJUSTMENTS VARIABLE SPEED BELT ADJUSTMENT You should rarely have to adjust the variable speed drive belt. If, however, it becomes necessary to adjust the belt, follow the steps listed below: 1. Remove belt as previously instructed. 2. Move control lever to the highest apron speed position.

  • Page 23: Service

    SERVICE ENTERING FORAGE BOX Front Unload If you plan to manually unload the Forage Box utilizing cross conveyor, the following two-man procedure must be followed. NEVER ATTEMPT THIS PROCEDURE ALONE. THE PERSON OUTSIDE OF FORAGE BOX OPERATING CONTROLS MUST NOT LEAVE CONTROLS. 1.

  • Page 24: Optional Features & Accessories

    STANDARD SLIDE OUT EXTENSION Extension slides out for easy access to blower and slides in for road and field travel. SLID OUT SLID IN OPTIONS HYDRAULIC DRIVE Hydraulic drive unit easily mounts and dismounts from unit -22-...

  • Page 25: Lubrication Guide

    LUBRICATION GENERAL INFORMATION IMPORTANT: Catch and dispose of fluid per local waste disposal regulations whenever service is performed on hydraulic components, valves, cylinders, hoses, etc. GREASING There are numerous grease fittings on the Forage Box. Become familiar with all lubrication points and establish a routine to ensure complete lubrication of the Forage Box.
  • Page 26 LUBRICATION A. (2) one at each end of PTO at U-joint B. One on variable drive outer upper sheave C. One on variable drive inner lower sheave D. One on beater drive clutch E. One on sprocket type chain tightener - beater drive chain F.

  • Page 27: Decal Location & Identification

    DECAL LOCATION Your H&S Forage Box was manufactured with operator safety in mind. Located on the Forage Box are various decals to aid in operation, and to warn of danger or caution areas. Pay close attention to all the decals on your Forage Box. DO NOT REMOVE ANY OF THESE DECALS.
  • Page 28 DECAL LOCATION CC BB E X G F -26-...

  • Page 29: Instructions For Ordering Parts

    INSTRUCTIONS FOR ORDERING PARTS All service parts should be ordered through your authorized H&S dealer. They will be able to give you faster service if you will provide them with the following Model & Serial number is located in the front center of the box. All reference to left or right apply to the Super Duty as viewed from the rear.

  • Page 30: Parts Notes

    SERVICE NOTES -28-...
  • Page 31 WIRING CODE White - Ground Yellow - LH Flashing & Turn Signal Green - RH Flashing & Turn Signal Brown - Tail Lamp Red - Tail Lamp (Flash LH/RH) FIGURE A H D TWIN AUGER FORAGE BOX LIGHTING ASSEMBLY ITEM PART NO.
  • Page 32 FIGURE 1 -30-...
  • Page 33 FIGURE 1 HOUSING COMPONENTS FOR UNITS ITEM PART NO. DESCRIPTIONS ST82 Poly Hold down and Seal Holder Poly Liner for Rear Auger Poly Liner for Front Auger ST83 Auger Housing LH Side Panel LH Emergency Stop Panel S370 Emergency Stop Panel ES14 Thimble (2) ES15...
  • Page 34 FIGURE 2 -32-...
  • Page 35 FIGURE 2 BEATERS AND MAIN APRON DRIVE ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION Grease Line Bracket Snap Ring Grease Line Fitting Lock Collar Short Grease Line F114 Bearing Flange w/Zerk Long Grease Line F115 Bearing Greaseable Type Drive Shaft Bushing Bearing Flange LH Drive Shaft Bracket LH Beater Stub Shaft...
  • Page 36 FIGURE 3 -34-...
  • Page 37 FIGURE 3 AUGERS AND DRIVE COMPONENTS ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION ES10 5/16’’ x 3’’ I-Bolt ST68 Poly Hold down Snap Ring ST69 Auger Center Wiper 12N36 Bearing Assembly Wiper Blade 12N33 Bearing ST14 Front Wiper Blade Holder 12N34 Bearing Cover ST15...
  • Page 38 FIGURE 4 -36-...
  • Page 39 FIGURE 4 SHIELDS - BEATER CLUTCH - BELT DRIVE ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION S364 Shifter Handle ST40 Side Shield Bottom Cotter Pin S122 Clip Pin Cable Shifting Pipe Bracket U-Bolt S360 Speed Selector Panel S123 Shield Latch Bracket S365 Front Center Angle S234...
  • Page 40 FIGURE 5 -38-...
  • Page 41 FIGURE 5 CROSS CONVEYOR CLUTCH - BELT DRIVE ITEM PART NO. DESCRIPTION S335 Front Clutch Plate S341 Idler-Stop Assembly S337 Handle Lever S332 Drive Belt Set S342 Pulley S339 Handle Mount S343 Shifting Rod 11S19 Sprocket 50B20 S340 Tightener Pivot Shaft S338 Handle Lever Bearing Flange...
  • Page 42 FIGURE 6 -40-...
  • Page 43 FIGURE 6 BEVEL GEARBOX ITEM PART NO. DESCRIPTION 5B10 1/4’’ x 1’’ Woodruff Key ST46 Gearbox Side Shaft Seal 3G19 Snap Ring 3G18 Race #15245 Bearing #15101 Gear Gearbox Housing Gearbox Gasket 3G20 Fill Plug Cover Seal 3G11 5B10 1/4’’ x 1’’ Woodruff Key S134 Gearbox Front Shaft S135...
  • Page 44 FIGURE 7 -42-...
  • Page 45 FIGURE 7 WORM GEARBOX ITEM PART NO. DESCRIPTION Dust Cap 3G19 Snap Ring 3G18 Race #15245 Bearing #15101 Spacer Set Screw Worm G114 Gearbox Housing Gearbox Bushing S138 3/8 x 2-3/8’’ Square Key w/Round Ends S139 Worm Gear Side Shaft S437 3/8 x 1-3/8’’...
  • Page 46 FIGURE 8 -44-...
  • Page 47 FIGURE 8 BOX COMPONENTS ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION S142 14’ Roof Sill Front Section S428 20’ Apron Chain Side Spacer S143 16’ Roof Sill Front Section S489 21’ Apron Chain Side Spacer S470 17’ Roof Sill Front Section S507 22’...
  • Page 48 FIGURE 9 TIE DOWN KIT ITEM PART NO. DESCRIPTION 12V45 1/2’’ x 1-1/2’’ GR.5 Bolt 1/2’’ Flat Washer 1/2’’ Top Lock Nut GR.5 S322 1/4’’ Chain 30-1/4’’ Long S323 Tie Down Bracket Tie Down Kit (Complete) -46-...

  • Page 49: Parts

    FIGURE 10 PTO PARTS HD NEEDLE BEARING PTO ITEM PART NO. DESCRIPTION S372 PTO Assembly Complete S373 Machine Half PTO W/Shield S374 End Yoke - Machine Half S375 “W’’ Repair Kit S376 Yoke and Tube 24N26 Bearing Retainer S206 Nylon Bearing S397 Inner Guard Includes Cent.
  • Page 50 ALL PARTS ALL PARTS #1 THRU #8 FIGURE 11 OPTIONAL HYDRAULIC DRIVE ITEM PART NO. DESCRIPTION S382 Top Motor Hanger S383 Bottom Motor Hanger 17G141 3/8’’ x 1-1/4’’ Bolt GR.5 3/8’’ Nut 12V66 5/16’’ x 3/4’’ Bolt T116 5/16’’ Nut 3G22 5/16’’...
  • Page 51 FIGURE 12 OPTIONAL FRONT HYDRAULIC DRIVE (2000 SERIES) ITEM PART NO. DESCRIPTION S382 Top Motor Hanger S383 Bottom Motor Hanger 17G141 3/8’’ x 1-1/4’’ GR.5 Bolt 3/8’’ Nut T116 5/16’’ Nut 12V66 5/16” x 3/4” Bolt 3G22 5/16’’ x 1-3/4” Expansion Pin S411 Secondary Drive S460...
  • Page 52 PARTS NOTES -50-...
  • Page 54 S MFG. CO. & products approved for the FEMA SEAL OF QUALITY...

This manual is also suitable for:
