Helios Ventilatoren
MONTAGE- UND BETRIEBSVORSCHRIFT
INSTALLATION AND OPERATING INSTRUCTIONS
NOTICE DE MONTAGE ET D'UTILISATION
Zentrales Lüftungsgerät
Central ventilation unit
Unité de ventilation centrale
KWL 250 W
KWL 250 W ET
Kompaktes Wandgerät mit Wärmerückgewinnung
und EC-Technik
Compact wall-mounted unit with heat recovery
and EC technology
Centrale murale compacte avec récupération de chaleur
et technologie EC
DE
EN
FR
easy
Controls 3.0

Advertisement

loading

Summary of Contents for Helios KWL 250 W ET

  • Page 1 Controls 3.0 Zentrales Lüftungsgerät Central ventilation unit Unité de ventilation centrale KWL 250 W KWL 250 W ET Kompaktes Wandgerät mit Wärmerückgewinnung und EC-Technik Compact wall-mounted unit with heat recovery and EC technology Centrale murale compacte avec récupération de chaleur...
  • Page 2: Table Of Contents

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET INHALTSVERZEICHNIS MONTAGE- UND BETRIEBSVORSCHRIFT KAPITEL 1 SICHERHEIT ................................. SEITE 3 Grundlegende Hinweise ................................. Seite 3 Warnhinweise ..................................Seite 3 Sicherheitshinweise ................................Seite 3 Einsatzbereich ..................................Seite 4 Personalqualifikation ................................Seite 4 KAPITEL 2 GRUNDLEGENDE HINWEISE ............................
  • Page 3 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET DEUTSCH KAPITEL 8 SOFTWARE easyControls 3.0............................ SEITE 23 Menüübersicht ..................................Seite 23 Startseite ....................................Seite 23 8.2.1 Lüftungsprofile ................................... Seite 23 8.2.2 Filterwechsel ..................................Seite 23 8.2.3 Temperaturen ..................................Seite 24 8.2.4 Gerätedaten ..................................
  • Page 4 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 1 Grundlegende Hinweise Zur Sicherstellung einer einwandfreien Funktion und zur eigenen Sicherheit sind alle nachstehenden Vorschriften genau SICHERHEIT durchzulesen und zu beachten. Die national einschlägigen Normen, Sicherheitsbestimmungen und Vorschriften (z.B. DIN EN VDE 0100) sowie die Technischen Anschlussbedienungen des örtlichen Energieversorgungsunternehmens sind unbedingt zu beachten und einzuhalten.
  • Page 5: Montage- Und Betriebsvorschrift

    Stillstandzeiten, starke Verschmutzung (z.B. fetthaltige Luft), übermäßige Beanspruchung durch klimatische, tech- nische oder elektronische Einflüsse, geeignet. Gleiches gilt für die mobile Verwendung des Gerätes (Fahr-, Flugzeuge, Schiffe, usw.). Ein Einsatz unter diesen Bedingungen ist nur mit Einsatzfreigabe seitens Helios möglich, da die Serien- ausführung hierfür nicht geeignet ist.
  • Page 6: Grundlegende Hinweise

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 2 Transport Das Gerät ist werkseitig so verpackt, dass es gegen normale Transportbelastungen geschützt ist. Der Transport muss GRUNDLEGENDE sorgfältig durchgeführt werden. HINWEISE Bei Weiterversand, vor allem über längere Distanzen (z.B. Seeweg) ist zu prüfen, ob die Verpackung für Transportart und -weg geeignet ist.
  • Page 7: Vorschriften Und Richtlinien

    Alle Ausführungen der zum Gerät gehörenden Dokumentationen müssen beachtet werden, sonst entfällt die Gewähr- leistung. Gleiches gilt für Haftungsansprüche an den Hersteller. Der Gebrauch von Zubehörteilen, die nicht von Helios empfohlen oder angeboten werden, ist nicht zulässig. Even tuell auftretende Schäden unterliegen nicht der Gewährleistung.
  • Page 8: Geräteübersicht

    Der Wärmebereitstellungsgrad ist von den Faktoren Luftfeuchtigkeit und dem Temperaturunterschied zwischen Außen- und Abluft abhängig. Geräte mit Enthalpie-Wärmetauscher (KWL 250 W ET) gewinnen neben der Wärme auch Feuch- tigkeit aus der Abluft zurück, die den Räumen mit der Zuluft wieder zugeführt wird.
  • Page 9: Technische Daten

    /h (KWL 250 W ET) Temperatur Arbeitsbereich -20 °C bis +40 °C Temperatur Aufstellbereich +5 °C bis +40 °C (< 90 % relative Feuchte, nicht kondensierend) Schutzart IP34 Schutzklasse 36 kg (KWL 250 W) Gewicht 38,5 kg (KWL 250 W ET) Kunststoff Wärmetauscher...
  • Page 10: Abmessungen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Abmessungen Abb. 3 133 192 157 Abluft Fortluft ø125 Zuluft Außenluft Kugelsiphon ø12 ø125 Zuluft Maße in mm Zubehör Zur Erweiterung des KWL Systems stehen weiteres Zubehör sowie passende Systemkomponenten zur Verfügung. ®...
  • Page 11: Einbauhinweise

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 4 Einbauhinweise 4.1.1 Positionierung MONTAGE Das Gerät ist zur Installation innerhalb der Wohneinheit bzw. des Gebäudes, an der Wand oder zum Einbau in einen Schrank, vorgesehen. Aufgrund der Betriebsgeräusche wird empfohlen, das Gerät in einem Nebenraum (z.B. Wasch- raum, Technikraum oder Abstellraum) zu installieren.
  • Page 12: Gerät Montieren

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Für den Umbau des Gerätes wie folgt vorgehen: Verletzungsgefahr durch Herunterfallen der Gerätetür bzw. -rückwand sowie des Wärmetauschers! WARNUNG Die Gerätetür bzw. -rückwand sowie der Wärmetauscher können beim Entfernen herunterfallen und schwere Ver- letzungen verursachen.
  • Page 13: Kugelsiphon Montieren

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Kugelsiphon montieren Während der Heizperiode kann es durch den Prozess der Wärmerückgewinnung, im Wärmetauscher zur Bildung von Kondensat kommen. Das Kondensat muss frei aus dem Gerät ablaufen können. Hierzu muss der beiliegende Kugelsi- phon (Lieferumfang) in der Bodenwanne des Gerätes montiert werden.
  • Page 14: Lüftungsleitungen Anschließen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 6. Kondensatschlauch (Länge max. 1,5 m) an das Entwässerungssystem des Gebäudes anschließen (s. Abb. 17). Abb. 17 Kondensatschlauch DN 12 mm (Gefälle beachten!) 7. Kugelsiphon kontrollieren: – Um die Dichtheit zu gewährleisten, darf der Kugelsiphon bei bauseitiger Montage keinen seitlichen Belastungen durch den Kondensatschlauch ausgesetzt sein! –...
  • Page 15: Anschlussplan

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 5.1.1 Anschlussplan Abb. 18 Modbus Leitungslänge: maximal 100 m es müssen paarw eise verdrillte Aderpaare verw endet KWL-KNX KWL-EM eC w erden. Connect Art. Nr.: 40155 Art. Nr. 20253 3x0,5 mm Externes Modbus KWL-BE Touch...
  • Page 16: Verdrahtungsplan

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 5.1.2 Verdrahtungsplan Abb. 19 MB_A MB_A MB_B MB_B +24V +24V RS_A RS_A RS_B RS_B siehe SS-1433 +24V RS_A +24V RS_A RS_B RS_B +11V1 +24V AN/I D/I1 +24V RM/I Elektroverteilung D/I2 RM/O Basic Platine gb-gn...
  • Page 17: Erstinbetriebnahme

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 6 Erstinbetriebnahme Für die Erstinbetriebnahme muss das Gerät ordnungsgemäß an das Stromnetz angeschlossen bzw. mit dem Stromnetz INBETRIEBNAHME verbunden sein. Anschließend kann der Inbetriebnahmeassistent über den lokalen Webserver oder optional über das Bedienelement KWL-BE Touch (Zubehör) durchgeführt werden.
  • Page 18: Einregulierung

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET > Die Einstellungen für die Konfiguration des Gerätes werden angezeigt. Abb. 22 4. Gerät konfigurieren und auf „Weiter“ klicken. > Die Zusammenfassung der Einstellungen öffnet sich. 5. Einstellungen prüfen und ggf. anpassen. 6.
  • Page 19 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Abb. 23 Abb. 24 Kennlinie KWL 250 W Kennlinie KWL 250 W ET Zu- und Abluft Zu- und Abluft 10 % â â 10 % â â 20 % 20 % ê...
  • Page 20 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 5. Die ermittelten Differenzdrücke der Ab- und Fortluftmessung in die Kennlinie des Gerätes für Abluft (s. Abb. 23 bzw. Abb. 24), entsprechend der im Lüftungsprofil hinterlegten Ventilatorleistungen, eintragen (vgl. Abb. 26 und Abb. 27). Abb.
  • Page 21 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET ⓘ Wir empfehlen folgende Werte in den Lüftungsprofilen zu hinterlegen: • Reduzierte Lüftung ≙ Lüftungsprofil „Unterwegs“ • Nennlüftung ≙ Lüftungsprofil „Zuhause“ • Intensivlüftung ≙ Lüftungsprofil „Intensivlüftung“ Gesamt-Luftvolumenströme durch ventilatorgestützte Lüftung nach DIN 1946-6:2019-12 Lüftung zum Reduzierte Lüftungsart...
  • Page 22: Volumenstrommessung Zur Einregulierung Der Anlage (Feinjustierung) Durchführen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 5. Unter „Ventilatoreinstellung“ die Ventilatorleistungen für Zu- und Abluft gemäß der ermittelten Werte für die Nenn- lüftung eintragen (vgl. Abb. 31). Abb. 31 6.3.3 Volumenstrommessung zur Einregulierung der Anlage (Feinjustierung) durchführen •...
  • Page 23: Lokaler Webserver

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 7 Lokaler Webserver Das Gerät kann über den lokalen Webserver mittels einem Webbrowser, über ein mobiles Endgerät (z.B. Notebook, PC, BEDIEN- Tablet, Smartphone) konfiguriert werden. Es ist keine Anmeldung/Registrierung des Gerätes erforderlich. MÖGLICHKEITEN Lokalen Webserver einrichten: 1.
  • Page 24: Menüübersicht

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 8 Menüübersicht easyControls 3.0 ist die Software für eine smarte und komfortable Bedienung der KWL Geräte über ein mobiles End- ® SOFTWARE gerät. Es können Einstellungen zu den folgenden Bereichen vorgenommen werden: easyControls 3.0 •...
  • Page 25: Temperaturen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET • Wechselintervall Zeigt das Intervall für den Filterwechsel an. Das Intervall für den Filterwechsel ist je nach Verschmutzungsgrad ein- stellbar zwischen 1 und 12 Monaten. ⓘ Die Filter sind je nach Bedarf jedoch mind. 1x jährlich zu wechseln (Werkseinstellung: 6 Monate). 8.2.3 Temperaturen Es werden die aktuellen Temperaturen von Zuluft, Abluft, Fortluft und Außenluft angezeigt.
  • Page 26: Temperaturen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Service Menü 8.4.1 Temperaturen Es werden die aktuellen Temperaturen angezeigt: • Zuluft • Fortluft • Außenluft • Abluft 8.4.2 Eigendiagnose ⓘ Die Eigendiagnose kann bis zu 20 Minuten dauern. Zur Durchführung der Eigendiagnose muss das Gerät länger als 15 Minuten eingeschaltet sein.
  • Page 27: Konfiguration

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Konfiguration 8.6.1 Ventilatoreneinstellung Ventilatorleistung für Zu- und Abluftventilator einstellen. • Zuluft • Abluft ⓘ Die Ventilatorleistungen dürfen nur bei der Einregulierung geändert werden! 8.6.2 Sensoreneinstellungen Parameter der angeschlossenen Sensoren einstellen: •...
  • Page 28: Relais Einstellungen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET 8.6.6 Relais Einstellungen Relais-Funktion auswählen und einstellen: • Wartungsanzeige Filterwechsel wird angezeigt (Relais-Status: geschlossen) • Fehlermeldung Fehlermeldung wird angezeigt (Relais-Status: geschlossen). Der Fehler wird auch im Fehlerprotokoll aufgezeichnet. • Fehlermeldung oder Wartungsanzeige Filterwechsel oder Fehlermeldung wird angezeigt (Relais-Status: geschlossen) •...
  • Page 29: Wärmetauscher

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET • Kälterückgewinnung aktivieren/deaktivieren Durch die Aktivierung der Kälterückgewinnung werden die Wohnräume mit möglichst kühler Zuluft belüftet. Die Funktion des Bypasses hängt dabei vom Temperaturniveau der Außenluft im Verhältnis zur Raumtemperatur ab. Bypass EIN Außenluft ist kühler als die Raumluft.
  • Page 30: Gerät Warten

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET KAPITEL 9 Gerät warten Das Gerät ist je nach Bedarf, jedoch mindestens einmal im Jahr auf Verschmutzungen und Verunreinigungen zu prüfen WARTUNG UND (Sichtprüfung). SERVICE Lebensgefahr durch elektrischen Schlag! Ein elektrischer Schlag kann zu Tod oder schweren Verletzungen führen. GEFAHR >...
  • Page 31: Wärmetauscher Warten Und Reinigen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Wärmetauscher warten und reinigen 9.3.1 Wärmetauscher warten Der Wärmetauscher ist je nach Bedarf oder mindestens einmal jährlich auf Verunreinigungen und Verschmutzungen zu prüfen (Sichtprüfung) und ggf. zu reinigen, s. Kapitel „9.3.2 Wärmetauscher reinigen“ auf Seite 30. 9.3.2 Wärmetauscher reinigen Lebensgefahr durch elektrischen Schlag! GEFAHR...
  • Page 32: Stilllegen Und Entsorgen

    Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET Verbrennungsgefahr durch heiße Oberflächen! WARNUNG Heiße Oberflächen können schweren Verbrennungen verursachen. > Gerät 5 Minuten abkühlen lassen bzw. warten, bis die Ventilatoren ausgedreht sind. Verletzungsgefahr durch rotierende Ventilatoren! WARNUNG Rotierende Ventilatoren können Gliedmaße verletzen und schwere Verletzungen verursachen. >...
  • Page 33 Montage- und Betriebsvorschrift Zentrales Lüftungsgerät – KWL 250 W/W ET...
  • Page 34 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET TABLE OF CONTENTS INSTALLATION AND OPERATING INSTRUCTIONS CHAPTER 1 SAFETY ..................................PAGE 3 Basic information ..................................Page 3 Warning instructions ................................Page 3 Safety instructions .................................. Page 3 Area of application ..................................
  • Page 35 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET ENGLISH CHAPTER 8 SOFTWARE easyControls 3.0........................... PAGE 23 Menu overview ..................................Page 23 Homepage .................................... Page 23 8.2.1 Ventilation profiles ................................Page 23 8.2.2 Filter replacement ................................Page 23 8.2.3 Temperatures ..................................
  • Page 36: Installation And Operating Instructions

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 1 Basic information In order to ensure correct operation and for your own safety, please read and observe the following instructions carefully SAFETY before proceeding. Relevant national standards, safety regulations and provisions (e.g. DIN EN VDE 0100) as well as the technical connection conditions of the energy supply company must be observed and applied.
  • Page 37: Area Of Application

    Therefore, this action can also be carried out by the user. • If the unit network cable is damaged, it must be replaced by the Helios custo- mer service team or a qualified electrician.
  • Page 38: Chapter 2 Basic Information

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 2 Shipping The delivery is packed ex works in such a way that it is protected against normal transport strain. The shipping must BASIC be carried out carefully. INFORMATION When transhipping (especially over longer distances, e.g.
  • Page 39: Regulations And Guidelines

    All versions of this documentation must be observed, otherwise the warranty shall cease to apply. The same applies to liability claims against the manufacturer. The use of accessory parts which are not recommended or offered by Helios is not permitted. Any possible damages are not covered by the warranty.
  • Page 40: Chapter 3 Product Information

    The heat recovery efficiency depends on the factors of humidity and the temperature difference between intake and extract air. Units with enthalpy heat exchangers (KWL 250 W ET) recover humidity from the extract air in addition to heat, which is returned to the rooms through the supply air.
  • Page 41: Technical Data

    Temperature operating range -20 °C to +40 °C Temperature installation area +5 °C to +40 °C (< 90 % relative humidity, non-condensing) Protection category IP34 Protection class 36 kg (KWL 250 W) Weight 38.5 kg (KWL 250 W ET) Plastic Heat exchanger...
  • Page 42: Dimensions

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Dimensions Fig. 3 133 192 157 Abluft Fortluft Extract air Exhaust air ø125 Supply air Zuluft Intake air Außenluft Ball siphon Kugelsiphon ø12 ø125 Supply air Zuluft Dimensions in mm Accessories Additional accessories and matching system components are available to expand the KWL system.
  • Page 43: Chapter 4 Installation

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 4 Installation instructions 4.1.1 Positioning INSTALLATION The unit is designed for installation on the wall inside the residential unit or building or for installation in a cabinet. Due to the operating noise, it is recommended to install the unit in a secondary room (e.g.
  • Page 44: Install Unit

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Proceed as follows to modify the unit: Risk of injury due to the unit door/back panel and the heat exchanger falling down! WARNING The unit door/back panel and the heat exchanger can fall down when removing and cause serious injuries. >...
  • Page 45: Install Ball Siphon

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Install ball siphon During heating periods, condensate may form in the heat exchanger due to the heat recovery process. The condensa- te must be able to drain freely from the unit. The provided ball siphon (scope of delivery) must be installed in the base tray of the unit for this purpose.
  • Page 46: Connect Ventilation Ducts

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 6. Connect condensate hose (length max. 1.5 m) to the building drainage system (see Fig. 17). Fig. 17 Condensate hose DN 12 mm (note gradient!) 7. The ball siphon must be inspected: –...
  • Page 47: Connection Diagram

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 5.1.1 Connection diagram Fig. 18 Modbus cable length: maximum 100 m KWL-KNX tw isted pairs of w ires must be used. KWL-EM eC Connect art. nr.: 40155 art. nr. 20253 Remote monitoring 3x0,5 mm...
  • Page 48: Wiring Diagram

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 5.1.2 Wiring diagram Fig. 19 MB_A MB_A MB_B MB_B +24V +24V RS_A RS_A RS_B RS_B SS-1433 +24V RS_A +24V RS_A RS_B RS_B +11V1 +24V AN/I D/I1 +24V RM/I Distribution board D/I2 RM/O...
  • Page 49: Chapter 6 Commissioning

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 6 Initial commissioning The unit must be properly connected or linked to the mains power supply for the initial commissioning. The commissio- COMMISSIONING ning assistant can then run via the local web server or optionally via the control element KWL-BE Touch (accessories). •...
  • Page 50: Adjustment

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET > The settings for unit configuration are displayed. Fig. 22 4. Configure unit and click “Next”. > The settings summary page will open up. 5. Check settings and adjust if necessary. 6.
  • Page 51 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Fig. 23 Fig. 24 Characteristic curve KWL 250 W Characteristic curve KWL 250 W ET Supply and extract air Supply and extract air 10 % 10 % â...
  • Page 52 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 5. Enter the determined differential pressures from the extract and exhaust air measurement in the unit characteristic curve for extract air (see Fig. 23 and Fig. 24) according to the fan powers saved in the ventilation profile (cf. Fig. 26 and Fig.
  • Page 53 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET ⓘ We recommend setting the following values in the ventilation profiles: • Reduced ventilation ≙ Ventilation profile “Away from home” • Nominal ventilation ≙ Ventilation profile “At home” •...
  • Page 54: Perform Flow Rate Measurement For Adjusting The System (Fine Adjustment)

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 5. Enter the fan powers for supply and extract air according to the determined values for nominal ventilation under “Fan setting” (cf. Fig. 31). Fig. 31 6.3.3 Perform flow rate measurement for adjusting the system (fine adjustment) •...
  • Page 55: Chapter 7 Operating Options

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 7 Local web server The unit can be configured via the local web server using a web browser, via a mobile end device (e.g. notebook, PC, OPERATING tablet, smartphone).
  • Page 56: Menu Overview

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 8 Menu overview easyControls 3.0 is the software for the smart and comfortable operation of the KWL units via a mobile end device. ® easyControls 3.0 Settings can be configured in the following areas: SOFTWARE •...
  • Page 57: Temperatures

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET • Replacement interval Displays the interval for filter replacement. The interval for filter replacement can be adjusted between 1 and 12 months depending on the level of contamination. ⓘ...
  • Page 58: Service Menu

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Service menu 8.4.1 Temperatures The current temperatures are displayed: • Supply air • Exhaust air • Intake air • Extract air 8.4.2 Self-diagnosis ⓘ The self-diagnosis can take up to 20 minutes. The unit must be activated for longer than 15 minutes to perform the self-diagnosis.
  • Page 59: Configuration

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Configuration 8.6.1 Fan setting Set fan power for supply and extract air fans. • Supply air • Extract air ⓘ The fan powers may only be changed during adjustment! 8.6.2 Sensor settings Set the connected sensor parameters: •...
  • Page 60: Relay Settings

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET 8.6.6 Relay settings Set and edit the relay function: • Maintenance display Filter replacement is displayed (relay status: closed) • Error message Error message is displayed (relay status: closed). The error is also recorded on the error log. •...
  • Page 61: Heat Exchanger

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET • Activate/deactivate cold recovery system The living spaces are ventilated with supply air that is as cool as possible by activating the cold recovery system. The bypass function depends on the temperature level of the intake air in relation to the room temperature. Bypass ON Intake air is cooler than the room air.
  • Page 62: Chapter 9 Service And Maintenance

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET CHAPTER 9 Unit maintenance The unit must be checked for contamination and dirt (visual inspection) as needed or at least every year. SERVICE AND MAINTENANCE Danger to life due to electric shock An electric shock can result in death or serious injuries.
  • Page 63: Heat Exchanger Maintenance And Cleaning

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Heat exchanger maintenance and cleaning 9.3.1 Heat exchanger maintenance The heat exchanger must be checked for contamination and dirt (visual inspection) and, if necessary, cleaned, see chapter 9.3.2 „Heat exchanger cleaning“, page 30. 9.3.2 Heat exchanger cleaning Danger to life due to electric shock DANGER...
  • Page 64: Standstill And Disposal

    Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET Risk of injury due to rotating fans! WARNING Rotating fans can injure limbs and cause serious injuries. > Before working on the unit, wait until the fans are turned off. Risk of injury due to the panel or unit door falling down! WARNING The panel or unit door can fall down when removing and cause serious injuries.
  • Page 65 Installation and Operating Instructions Central ventilation unit – KWL 250 W/W ET...
  • Page 66 Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET SOMMAIRE NOTICE DE MONTAGE ET D‘UTILISATION CHAPITRE 1 SÉCURITÉ .................................. PAGE 3 Informations générales ................................Page 3 Consignes de sécurité ................................Page 3 Consignes de sécurité ................................Page 3 Domaines d‘utilisation ................................
  • Page 67 Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET FRANÇAIS CHAPITRE 8 LOGICIEL EASYCONTROLS 3.0 ..........................PAGE 23 Aperçu du menu ................................... Page 23 Page d‘accueil ..................................Page 23 8.2.1 Profils de ventilation ................................Page 23 8.2.2 Remplacement des filtres ..............................
  • Page 68: Informations Générales

    Filet à cheveux Le filet à cheveux empêche les longs cheveux de se coincer dans les pièces mobiles. Pour le fonctionnement, le raccordement et l’utilisation, contacter Helios en cas de doutes. Des informations supplémentaires sont consultables dans les normes et textes de loi.
  • Page 69: Domaines D'utilisation

    à des contraintes climatiques, techniques ou électroniques. Une utilisation en unité mobile (véhicules, avions, bateaux, etc.) n’est pas prévue. L‘utilisation dans ces conditions n‘est possible qu‘avec l‘accord d‘Helios, la version standard n‘étant pas adaptée à une telle utilisation.
  • Page 70: Transport

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 2 Transport L’appareil est emballé en usine et est protégé des dégâts de transport courants. Transporter l’appareil avec précautions. INFORMATIONS En cas de transport ultérieur, en particulier sur de longues distances (par exemple par mer), il faut vérifier si l‘emballage GÉNÉRALES convient au type et à...
  • Page 71: Normes - Règlementations

    Si toutes les consignes indiquées dans cette notice ne sont pas correctement respectées, la garantie s’annule. Idem pour les garanties constructeur Helios. L’utilisation d’accessoires, non fournis, non conseillés ou non proposés par Helios, est interdite. Tous changements ou transformations effectués sur l’appareil sont interdits, altèrent sa conformité...
  • Page 72: Vue D'ensemble De L'appareil

    à l’extérieur par le conduit de rejet. Les appareils avec échangeur de chaleur à enthalpie (KWL 250 W ET) récupèrent jusqu‘à 70% d‘humidité de...
  • Page 73: Données Techniques

    -20 °C à +40 °C Plage de température +5 °C à +40 °C (< 90 % humidité relative, sans condensation) Protection IP34 Classe de protection 36 kg (KWL 250 W) Poids 38,5 kg (KWL 250 W ET) Matière synthétique Échangeur à contre-courant...
  • Page 74: Dimensions

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET Dimensions Fig. 3 133 192 157 Abluft air rejeté Fortluft air extrait ø125 air soufflé Zuluft Außenluft air extérieur Kugelsiphon Siphon à boule ø12 ø125 Zuluft air soufflé...
  • Page 75: Instructions D'installation

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 4 Instructions d‘installation 4.1.1 Positionnement MONTAGE L‘appareil est destiné à être installé au mur ou dans une armoire à l‘intérieur de l‘appartement ou du bâtiment. En raison du bruit de fonctionnement, il est recommandé...
  • Page 76: Montage De L'appareil

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET Pour démonter l‘appareil, procéder comme suit : Risque de blessure dû à la chute de la porte ou du panneau arrière de l‘appareil ! AVERTISSEMENT La porte ou le panneau arrière de l‘appareil peuvent tomber lorsqu‘ils sont retirés et provoquer des blessures graves.
  • Page 77: Montage Du Siphon À Boule

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET Montage du siphon à boule Pendant la période de chauffe, des condensats peuvent se former dans l‘échangeur à contre-courant en raison du processus de récupération de la chaleur. Le condensat doit pouvoir s‘écouler librement de l‘appareil. Le siphon à boule (inclus dans la livraison) doit être monté...
  • Page 78: Raccordement Des Conduits De Ventilation

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET 6. Raccorder le tube des condensats (longueur max. 1,5 m) au système d’évacuation des eaux usées du bâtiment (à un siphon) (voir Fig. 17). Fig. 17 Tubes des condensats DN 12 mm (doit être en pente !) 7.
  • Page 79: Schéma De Raccordement

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET 5.1.1 Schéma de raccordement Fig. 18 Longueur du câble Modbus : 100 m maximum KWL-KNX Il faut utiliser des paires de fils torsadés. KWL-EM eC Connect Numéro de poste: Numéro de 40155...
  • Page 80: Schéma De Câblage

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET 5.1.2 Schéma de câblage Fig. 19 MB_A MB_A MB_B MB_B +24V +24V RS_A RS_A RS_B RS_B voir SS-1433 +24V RS_A +24V RS_A RS_B RS_B +11V1 +24V AN/I D/I1 +24V...
  • Page 81: Première Mise En Service

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 6 Première mise en service Pour la première mise en service, l‘appareil doit être correctement raccordé au réseau électrique ou branché au secteur. MISE EN SERVICE L‘assistant de mise en service peut ensuite être lancé...
  • Page 82: Paramétrages

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET > Les paramètres de configuration de l‘appareil s‘affichent. Fig. 22 4. Configurer l‘appareil et cliquer sur „Suivant“. > Le récapitulatif des paramètres s‘ouvre. 5. Vérifier les paramètres et les ajuster si nécessaire. 6.
  • Page 83 Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET Fig. 23 Fig. 24 Courbe caractéristique KWL 250 W Courbe caractéristique KWL 250 W ET Air soufflé et extrait Air soufflé et extrait 10 % â...
  • Page 84 Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET 5. Entrer les pressions différentielles déterminées de la mesure de l‘air extrait et rejeté dans la courbe caractéristique de l‘appareil pour l‘air extrait (voir fig. 23 et 24), en fonction des performances du ventilateur enregistrées dans le profil de ventilation (voir fig.
  • Page 85 Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET ⓘ Nous recommandons de conserver les valeurs suivantes dans les profils de ventilation : • Ventilation réduite ≙ profil de ventilation „en déplacement“ • Ventilation nominale ≙ profil de ventilation „à la maison“ •...
  • Page 86: Réglage Par Mesure Du Débit Volumique (Réglage Fin)

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET 5. Sous „Réglage du ventilateur“, entrer les performances du ventilateur pour l‘air soufflé et extrait en fonction des valeurs déterminées pour la ventilation nominale (voir fig. 31). Fig.
  • Page 87: Serveur Web Local

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 7 Serveur web local L‘appareil peut être configuré via le serveur web local à l‘aide d‘un navigateur web, via un appareil mobile (par exemple COMMANDE un ordinateur portable, un PC, une tablette, un smartphone).
  • Page 88: Aperçu Du Menu

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 8 Aperçu du menu easyControls 3.0 est le logiciel pour une utilisation intelligente et pratique des appareils KWL via un appareil mobile. ® LOGICIEL Les réglages suivants peuvent être effectués : easyControls 3.0 •...
  • Page 89: Températures

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET • Intervalle de remplacement Indique l‘intervalle de remplacement de filtre. L‘intervalle de remplacement du filtre peut être fixé entre 1 et 12 mois, en fonction du degré d‘encrassement. ⓘ...
  • Page 90: Menu Service

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET Menu service 8.4.1 Températures Les températures actuelles sont affichées : • Air soufflé • Air rejeté • Air extérieur • Air extrait 8.4.2 Autodiagnostic ⓘ L‘autodiagnostic peut durer jusqu‘à 20 minutes. Pour effectuer l‘autodiagnostic, l‘appareil doit être allumé pendant plus de 15 minutes.
  • Page 91: Configuration

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET Configuration 8.6.1 Réglage des ventilateurs Régler la puissance du ventilateur pour l‘air soufflé et extrait. • Air soufflé • Air extrait ⓘ Les puissances du ventilateur ne peuvent être modifiées que pendant le réglage ! 8.6.2 Réglages des sondes Réglages des paramètres des sondes raccordées : •...
  • Page 92: Réglages Des Relais

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET 8.6.6 Réglages des relais Définir et modifier la fonction des relais : • Affichage d‘entretien Le changement de filtre est affiché (état du relais : fermé) •...
  • Page 93: Échangeur À Contre-Courant

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET • Activer/désactiver la récupération de froid En activant la récupération de froid, les espaces de vie sont ventilés avec de l‘air soufflé le plus froid possible. Le fonctionnement du bypass dépend du niveau de température de l‘air extérieur par rapport à...
  • Page 94: Entretien De L'appareil

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET CHAPITRE 9 Entretien de l‘appareil L‘appareil doit être contrôlé en fonction des besoins, mais au moins une fois par an (inspection visuelle). ENTRETIEN ET MAINTENANCE Danger de mort par électrocution ! En choc électrique peut entraîner la mort ou des blessures graves.
  • Page 95: Entretien Et Nettoyage De L'échangeur À Contre-Courant

    Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET Entretien et nettoyage de l‘échangeur à contre-courant 9.3.1 Entretien de l‘échangeur à contre-courant L‘échangeur à contre-courant doit être inspecté selon les besoins ou au moins une fois par an pour détecter les salissu- res et l‘encrassement (inspection visuelle) et être nettoyé...
  • Page 96: Recyclage

    Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET Risque de brûlures en raison de surfaces chaudes ! AVERTISSEMENT Les surfaces chaudes peuvent causer de graves brûlures. > Laisser refroidir la centrale 5 min et attendre l’arrêt complet des ventilateurs. Risque de blessure en raison des ventilateurs en rotation ! AVERTISSEMENT Les ventilateurs en rotation peuvent blesser des membres et provoquer des lésions graves.
  • Page 97 Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET...
  • Page 98 Notice de montage et dutilisation Unité de ventilation centrale – KWL 250 W/W ET...
  • Page 99 Notice de montage et d‘uilisation Unité de ventilation centrale – KWL 250 W/W ET...
