IEI Technology TANGO-7010 Series User Manual

Embedded system support 12th gen. intel® cpu, ddr4 dimm, triple 2.5gbe lan, dual hdmi, dp, four usb, 12v dc, rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL:
TANGO-7010 Series
Embedded System Support 12th Gen. Intel® CPU, DDR4 DIMM, Triple 2.5GbE
LAN, Dual HDMI, DP, Four USB, 12V DC, RoHS
User Manual
Rev. 1.00 – July 18, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TANGO-7010 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology TANGO-7010 Series

Summary of Contents for IEI Technology TANGO-7010 Series

  • Page 1 MODEL: TANGO-7010 Series Embedded System Support 12th Gen. Intel® CPU, DDR4 DIMM, Triple 2.5GbE LAN, Dual HDMI, DP, Four USB, 12V DC, RoHS User Manual Rev. 1.00 – July 18, 2023...
  • Page 2 TANGO-7010 Embedded System Revisions Date Version Changes July 18, 2023 1.00 Initial release Page II...
  • Page 3 TANGO-7010 Embedded System Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 TANGO-7010 Embedded System Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 5: Table Of Contents

    TANGO-7010 Embedded System Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 F ......................3 RONT ANEL 1.4 R ....................... 4 ANEL 1.5 L ....................... 4 ANEL 1.6 T ..................5 ECHNICAL PECIFICATIONS 1.7 P...
  • Page 6 TANGO-7010 Embedded System 4.1 O ........................ 29 VERVIEW 4.1.1 Layout ......................29 4.2 I ..............31 NTERNAL ERIPHERAL ONNECTORS 4.2.1 RTC Battery Connector (BAT1) ............... 32 4.2.2 CPU Fan Connector (CPU_FAN1)..............34 4.2.3 System Debug Connector (DBG_PORT1) ............35 4.2.4 EC Debug Connector (EC_DEBUG1) ............. 36 4.2.5 EC Flash Connector (EC_FLASH1) ..............
  • Page 7 TANGO-7010 Embedded System 5.1.4 Unable to Reboot after Configuration Changes ..........62 5.1.5 BIOS Menu Bar ....................62 1.2M ........................63 1.3A ........................ 66 DVANCED 5.3.1 CPU Configuration ..................68 5.3.2 Trusted Computing ................... 73 5.3.3 IT5571 Super IO Configuration ............... 74 5.3.4 IT5571 H/W Monitor ..................
  • Page 8 TANGO-7010 Embedded System List of Figures Figure 1-1: TANGO-7010 Series ....................2 Figure 1-2: Front Panel ........................3 Figure 1-3: Rear Panel ........................4 Figure 1-4: Left Side Panel ......................4 Figure1-5: Physical Dimensions ....................7 Figure 3-1: Remove the Cover .....................14 Figure 3-2: Open the HDD bracket ....................15...
  • Page 9 TANGO-7010 Embedded System Figure 4-9: BIOS Programming Connector Location ..............41 Figure 4-10: Clear CMOS Button Location .................42 Figure 4-11: Flash Descriptor Override Setting Jumper Locations ........43 Figure 4-12: Buzzer Connector Location ...................44 Figure 4-13: M.2 E-key Slot Location ..................45 Figure 4-14: M.2 M-key Slot Location ..................48 Figure 4-15: HDD LED Connector Location ................50 Figure 4-16: LAN LED Connector Location ................51 Figure 4-17: PMBUS Connector Location ..................52...
  • Page 10 TANGO-7010 Embedded System List of Tables Table 1-1: Technical Specifications ....................6 Table 3-1: RJ-45 Ethernet Connector LEDs ................22 Table 3-2: RS-232 (COM1) & RS-232/422/485 (COM2) Connector Pinouts ......23 Table 4-1: Peripheral Interface Connectors ................31 Table 4-2: Battery Connector Pinouts ..................33 Table 4-3: CPU Fan Connector Pinouts ..................34 Table 4-4: System Debug Connector Pinouts ................35 Table 4-5: EC Debug Connector Pinouts ...................37...
  • Page 11 TANGO-7010 Embedded System Table 5-2: BIOS Options and Configured USB Ports ..............97 Page XI...

  • Page 12: Introduction

    TANGO-7010 Embedded System Chapter Introduction Page 1...

  • Page 13: Overview

    GbE LAN ports, two USB 3.2 Gen2 (10Gb/s) ports, two USB 3.2 Gen1 (5Gb/s) ports, one RS-232 port and one RS-232/422/485 port. The TANGO-7010 Series has two HDMI 2.0b & one DP1.4 ports supporting up to 4k@ 60Hz resolution, and includes one M.2 2230 A-key slot (pre-installed WIFI module) and two M.2 2280 M-key slot for expansions.

  • Page 14: Features

    One 2.5" HDD/SSD SATA 6Gb/s bay (supports up to 9.5 mm SSD) ▪ Built-in Wi-Fi 6E & Bluetooth 5.2 module (internal antenna) 1.3 Front Panel The front panel of the TANGO-7010 Series has the following features (See Figure 1-2): Figure 1-2: Front Panel Page 3...

  • Page 15: Rear Panel

    The rear panel of the TANGO-7010 Series is shown below (See Figure 1-3). Figure 1-3: Rear Panel 1.5 Left Side Panel The left side panel of the TANGO-7010 Series is shown below (See Figure 1-4). Figure 1-4: Left Side Panel Page 4...

  • Page 16: Technical Specifications

    TANGO-7010 Embedded System 1.6 Technical Specifications The TANGO-7010 Series technical specifications are listed in Table 1-1 Model Name TANGO-7010-i9AWC-R10 TANGO-7010-i7AWC-R10 TANGO-7010-i5AWC-R10 TANGO-7010-i3AWC-R10 Color Black C & grey (Pantone 430C) Dimension( WxDxH)(mm) 192.09*158*64 mm Chassis System Fan Chassis Construction ABS Plastic + Aluminum Intel®...

  • Page 17: Table 1-1: Technical Specifications

    TANGO-7010 Embedded System Operating Temperature 0° C ~ 40° C with air flow (SSD), 10% ~ 95%, non-condensing Storage Temperature -10° C ~ 60° C with air flow (SSD), 10% ~ 90%, non-condensing Operating Shock Half-sine wave shock 5G, 11ms, 100 shocks per axis (SSD) Operation Vibration 10-500 Hz, 1.04 Grms, random, 1 hr/axis (SSD) Weight (Net/Gross)

  • Page 18: Physical Dimensions

    TANGO-7010 Embedded System 1.7 Physical Dimensions The physical dimensions of the TANGO-7010 are shown in Figure1-5. Figure1-5: Physical Dimensions Page 7...

  • Page 19: Unpacking

    TANGO-7010 Embedded System Chapter Unpacking Page 8...

  • Page 20: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the TANGO-7010 Series. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the TANGO-7010 Series or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 21: Unpacking Checklist

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the TANGO-7010 Series from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.
  • Page 22 TANGO-7010 Embedded System Quantity Item and Part Number Image Standard Power adapter (P/N: 63040-380060-101-RS) Screw driver Table 2-1: Packing List Page 11...

  • Page 23: Installation

    TANGO-7010 Embedded System Chapter Installation Page 12...

  • Page 24: Installation Precautions

    Electric shock and personal injury might occur if the rear panel of the TANGO-7010 Series is opened while the power cord is still connected to an electrical outlet.

  • Page 25: Back Cover Removal

    TANGO-7010 Embedded System 3.2 Back Cover Removal Before installing or maintaining the internal components, the back cover must be removed from the TANGO-7010. Follow the steps below to complete the task. Step 1: Turn the TANGO-7010 over and loosen the 4 screws on the back cover (the screws cannot be removed).

  • Page 26: Tool-Less Hdd/Ssd Installation

    TANGO-7010 Embedded System 3.3.1 Tool-Less HDD/SSD Installation The TANGO-7010 Series allow installation of one 2.5" HDD/SSD. Follow the steps below to complete the task. Step 1: Remove the 2 hard disk bracket screws and push out the hard disk bracket in parallel.

  • Page 27: Figure 3-3: Install Hard Drive

    TANGO-7010 Embedded System Figure 3-3: Install hard drive Step 3: Push the hard disk bracket back to secure the hard disk, and lock it with 2 retention screws. Figure 3-4: Lock bracket with screws Step 4: Connect the SATA cable to an HDD/SSD and re-install the back cover. Page 16...

  • Page 28: Figure 3-5: Connect The Sata Cable

    TANGO-7010 Embedded System Figure 3-5: Connect the SATA cable Page 17...

  • Page 29: Ssd Installation

    TANGO-7010 Embedded System 3.3.2 M.2 SSD Installation The TANGO-7010 Series allows installation of two M.2 2280 M-key card. Follow the steps below to complete the task. Step 1: Locate the M.2 2280 M-key slot. (See Figure 3-6) Figure 3-6: The M.2 Module Locations Step 2: Remove the on-board retention screw as shown below (See Figure 3-7).

  • Page 30: Figure 3-8: Inserting The M.2 Module Into The Slot At An Angle

    TANGO-7010 Embedded System Step 3: Line up the notch on the module with the notch on the slot. Slide the M.2 module into the socket at an angle of about 20º (Figure 3-8). Figure 3-8: Inserting the M.2 Module into the Slot at an Angle Step 4: Secure the M.2 module with the previously removed retention screw Figure 3-9: Securing the M.2 Module...

  • Page 31: Back Cover Installation

    TANGO-7010 Embedded System 3.4 Back Cover Installation Install the back cover and fasten the 4 screws to secure it (See Figure 3-10). Figure 3-10: Back Cover Installation Page 20...

  • Page 32: External Peripheral Interface Connectors

    TANGO-7010 Embedded System 3.5 External Peripheral Interface Connectors 3.5.1 HDMI Connection To connect the HDMI devices, please plug in HDMI connector in the right direction as shown below: Figure 3-11: HDMI Connection Page 21...

  • Page 33: Lan Connection

    Chapter 1. Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of the RJ-45 connectors on the TANGO-7010 Series. (See Figure 3-12). Figure 3-12: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector.

  • Page 34: Rs-232/422/485 Serial Port Connection

    TANGO-7010 Embedded System 3.5.3 RS-232/422/485 Serial Port Connection The system has one RS-232/422/485 port & one RS-232 serial port. The pinouts for the serial ports are listed in the table below (See Table 3-2). PIN NO. RS232 RS422 RS485 DCD# DTR# DSR# RTS#...

  • Page 35: Powering On/Off The System

    TANGO-7010 Embedded System 3.6 Powering On/Off the System WARNING: Make sure a power supply with the correct input voltage is being fed into the system. Incorrect voltages applied to the system may cause damage to the internal electronic components and may also cause injury to the user. ▪...

  • Page 36: Figure 3-16: Power Connector

    TANGO-7010 Embedded System Figure 3-16: Power Connector Page 25...

  • Page 37: Available Drivers

    TANGO-7010 Embedded System 3.8 Available Drivers All the drivers for the TANGO-7010 Series are available on IEI Resource Download Center (https://download.ieiworld.com). Type TANGO-7010 Series and press Enter to find all the relevant software, utilities, and documentation. Figure 3-17: IEI Resource Download Center 3.8.1 Driver Download...
  • Page 38 TANGO-7010 Embedded System Step 5: Click the driver file name on the page and you will be prompted with the following window. You can download the entire ISO file ( ), or click the small arrow to find an individual driver and click the file name to download ( NOTE: To install software from the downloaded ISO image file in Windows 10 (or later), double-click the ISO file to mount it as a virtual drive to view...

  • Page 39: System Motherboard

    TANGO-7010 Embedded System Chapter System Motherboard Page 28...

  • Page 40: Overview

    TANGO-7010 Embedded System 4.1 Overview This chapter details all the jumpers and connectors of the system motherboard. 4.1.1 Layout The figures below show all the connectors and jumpers of the system motherboard. Page 29...

  • Page 41: Figure 4-1: Connector And Jumper Locations

    TANGO-7010 Embedded System Figure 4-1: Connector and Jumper Locations Page 30...

  • Page 42: Internal Peripheral Connectors

    TANGO-7010 Embedded System 4.2 Internal Peripheral Connectors The table below shows a list of the internal peripheral interface connectors on the system motherboard. Pinouts of these connectors can be found in the following sections. Connector Type Label Battery Connector 2-pin wafer BAT1 CPU Fan Connector 4-pin wafer...

  • Page 43: Rtc Battery Connector (Bat1)

    Dispose of used batteries according to instructions and local regulations. NOTE: It is recommended to attach the RTC battery onto the system chassis in which the TANGO-7010 Series is installed. CN Label: BAT1 CN Type: 2-pin wafer, p=1.25 mm...

  • Page 44: Figure 4-2: Battery Connector Location

    TANGO-7010 Embedded System Figure 4-2: Battery Connector Location DESCRIPTION PIN NO. DESCRIPTION VBATT(+3V) Table 4-2: Battery Connector Pinouts Page 33...

  • Page 45: Cpu Fan Connector (Cpu_Fan1)

    TANGO-7010 Embedded System 4.2.2 CPU Fan Connector (CPU_FAN1) CN Label: CPU_FAN1 CN Type: 4-pin wafer, p=2.00 mm CN Location: See Figure 4-3 CN Pinouts: See Table 4-3 Figure 4-3: CPU Fan Connector Location DESCRIPTION PIN NO. DESCRIPTION VCC12V FANIO Table 4-3: CPU Fan Connector Pinouts Page 34...

  • Page 46: System Debug Connector (Dbg_Port1)

    TANGO-7010 Embedded System 4.2.3 System Debug Connector (DBG_PORT1) CN Label: DBG_PORT1 CN Type: 6-pin header, p=2.00 mm CN Location: See Figure 4-4 CN Pinouts: See Table 4-4 Figure 4-4: System Debug Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMCLK_EC SMDAT_EC RST# Table 4-4: System Debug Connector Pinouts...

  • Page 47: Ec Debug Connector (Ec_Debug1)

    TANGO-7010 Embedded System 4.2.4 EC Debug Connector (EC_DEBUG1) CN Label: EC_DEBUG1 CN Type: FPC, p=0.5 mm CN Location: See Figure 4-5 CN Pinouts: See Table 4-5 Figure 4-5: EC Debug Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION KSI0 KSO9 KSO0 KSO10 KSO1...

  • Page 48: Ec Flash Connector (Ec_Flash1)

    TANGO-7010 Embedded System KSO5 KSI3 KSO6 KSO7 KSO8 Table 4-5: EC Debug Connector Pinouts 4.2.5 EC Flash Connector (EC_FLASH1) CN Label: EC_FLASH1 CN Type: 4-pin header, p=1.25 mm CN Location: See Figure 4-6 CN Pinouts: See Table 4-6 The 4-pin Flash EC ROM connector is used to flash the EC internal ROM. Figure 4-6: EC Flash Connector Location Page 37...

  • Page 49: Sata Connector (Sata1)

    TANGO-7010 Embedded System PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_FLASH_DAT EC_FLASH_CLK Table 4-6: EC Flash Connector Pinouts 4.2.6 SATA Connector (SATA1) CN Label: SATA1 CN Type: 20-pin iSATA connector CN Location: See Figure 4-7 CN Pinouts: See Table 4-7 The SATA 6Gb/s drive connector is connected to a SATA 6Gb/s drive. The SATA 6Gb/s drive transfers data at speeds as high as 6Gb/s.

  • Page 50: At/Atx Power Mode Switch (J_Atx_At1)

    TANGO-7010 Embedded System SATA_RXP0_C SATA_RXN0_C VCC5 VCC4 SATA_TXN0_C VCC3 SATA_TXP0_C VCC2 Table 4-7: SATA Connector Pinouts 4.2.7 AT/ATX Power Mode Switch (J_ATX_AT1) CN Label: J_ATX_AT1 CN Type: 3-pin switch CN Location: See Figure 4-8 CN Pinouts: See Table 4-8 The AT/ATX power mode selection is made through the AT/ATX power mode switch which is shown in Figure 4-8.

  • Page 51: Figure 4-8: At/Atx Power Mode Switch Locations

    TANGO-7010 Embedded System Figure 4-8: AT/ATX Power Mode Switch Locations PIN NO. DESCRIPTION ATX Power Mode (default) AT Power Mode Table 4-8: AT/ATX Power Mode Switch Pinouts Page 40...

  • Page 52: Bios Programming Connector (Jspi1)

    TANGO-7010 Embedded System 4.2.8 BIOS Programming Connector (JSPI1) CN Label: JSPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 4-9 CN Pinouts: See Table 4-9 The 6-pin Flash SPI ROM connector is used to flash the BIOS. Figure 4-9: BIOS Programming Connector Location PIN NO.

  • Page 53: Clear Cmos Button (J_Cmos1)

    TANGO-7010 Embedded System 4.2.9 Clear CMOS Button (J_CMOS1) CN Label: J_CMOS1 CN Type: Button CN Location: See Figure 4-10 CN Pinouts: See Table 4-10 To clear the CMOS Setup (for example if you have forgotten the password, you should clear the CMOS and then reset the password), you should disconnect the RTC battery and press the button for about 3 seconds.

  • Page 54: Flash Override Jumper (Me_Flash1)

    TANGO-7010 Embedded System 4.2.10 Flash Override Jumper (ME_FLASH1) CN Label: ME_FLASH1 CN Type: 2-pin header, P=2.00mm CN Location: See Figure 4-11 CN Pinouts: See Table 4-11 The ME_FLASH1 connector is used for Flash Descriptor Security Override. Figure 4-11: Flash Descriptor Override Setting Jumper Locations PIN NO.

  • Page 55: Buzzer Connector

    TANGO-7010 Embedded System 4.2.11 Buzzer Connector CN Label: BUZZER1 CN Type: 2-pin wafer, p=1.25mm CN Location: See Figure 4-12 CN Pinouts: See Table 4-12 The buzzer connector is connected with the buzzer to give a beep warning when the motherboard goes wrong. Figure 4-12: Buzzer Connector Location Description PC_BEEP_N...

  • Page 56: E-Key Slot

    TANGO-7010 Embedded System 4.2.12 M.2 E-key Slot CN Label: M2_E1 CN Type: M.2 E-key slot CN Location: See Figure 4-13 CN Pinouts: See Table 4-13 The M.2 slot is keyed in the E position and accepts 2230 size of M.2 modules. The M.2 slot supports PCIe Gen3 x1 and USB 2.0 signals.

  • Page 57: Table 4-13: M.2 E-Key Slot Pinouts

    TANGO-7010 Embedded System Description Description CNV_WR_0_DN CNV_WR_0_DP UART_BT_WAKE_N CNV_WR_CLK_DN CNV_BRI_RSP CNV_WR_CLK_DP Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key CNV_RGI_DT Module Key CNV_RGI_RSP PCIE_TX1+ CNV_BRI_DT_R PCIE_TX1- MLK_RST_N MLK_DATA PCIE_RX1+ MLK_CLK PCIE_RX1- CNV_PA_BLANKING CNV_MFUART2_TXD CLK_PCIE1+ CNV_MFUART2_RXD...

  • Page 58: M-Key Slot

    TANGO-7010 Embedded System 4.2.13 M.2 M-key Slot CN Label: M2_M1, M2_M2 CN Type: M.2 M-key slot CN Location: Figure 4-14 791H CN Pinouts: See Table 4-14 The M.2 M key (M2_M1 2280) slot with PCIe Gen4 x4 supports NVMe storage. Page 47...

  • Page 59: Figure 4-14: M.2 M-Key Slot Location

    TANGO-7010 Embedded System Figure 4-14: M.2 M-key Slot Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V PCIE_3_RX_DN PCIE_3_RX_DP NGFF1_ACT_N PCIE_3_TX_DN +3.3V PCIE_3_TX_DP +3.3V +3.3V PCIE_2_RX_DN +3.3V PCIE_2_RX_DP PCIE_2_TX_DN PCIE_2_TX_DP PCIE_1_RX_DN PCIE_1_RX_DP Page 48...

  • Page 60: Hdd Led Connector

    TANGO-7010 Embedded System PCIE_1_TX_DN PCIE_1_TX_DP M_2_SSD_SLP SMB_CLK_M2 PCIE_0_RX_DN SMB_DATA_M2 PCIE_0_RX_DP PCIE_0_TX_DN PCIE_0_TX_DP PLT_SLOT_RST_N SRCCLKREQB_1_N REFCLKN REFCLKP Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key +3.3V +3.3V +3.3V Table 4-14: M.2 M-key Slot Pinouts 4.2.14 HDD LED Connector CN Label: H_LED1...

  • Page 61: Lan Led Connector

    TANGO-7010 Embedded System Figure 4-15: HDD LED Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V5S HD_LED_N Table 4-15: HDD LED Connector Pinouts 4.2.15 LAN LED Connector CN Label: LED_LAN1, LED_LAN2, LED_LAN3 CN Type: 2-pin header, p=2.00mm CN Location: Figure 4-16 791H CN Pinouts: See Table 4-16...

  • Page 62: Pmbus Connector

    TANGO-7010 Embedded System Figure 4-16: LAN LED Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V LAN1_LED_LNK#_ACT Table 4-16: LAN LED Connector Pinouts 4.2.16 PMBUS Connector CN Label: CN Type: 3-pin header, p=2.54mm CN Location: See Figure 4-17 CN Pinouts: See Table 4-17 Page 51...

  • Page 63: Figure 4-17: Pmbus Connector Location

    TANGO-7010 Embedded System Figure 4-17: PMBUS Connector Location PIN NO. DESCRIPTION PIN NO. DESCRIPTION PM_SCL PM_SDA Table 4-17: PMBUS Connector Pinouts Page 52...

  • Page 64: External Interface Panel Connectors

    TANGO-7010 Embedded System 4.3 External Interface Panel Connectors The table below shows a list of the external interface panel connectors on the system motherboard. Pinouts of these connectors can be found in the following sections. Connector Type Label HDMI Connectors HDMI 1.4b HDMI1, HDMI_DP2 DP Connectors...

  • Page 65: External Dp Connectors (Hdmi_Dp2)

    TANGO-7010 Embedded System Figure 4-18: HDMI Connector 4.3.2 External DP Connectors (HDMI_DP2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE0P LANE3N LANE0N AUX_CTRL_DET_D LANE1P DPB_AUX_CTRL_P2 LANE1N LANE2P DPB_AUX_CTRL_N2 LANE2N LANE3P +3.3V Table 4-20: DP Connector Pinouts Figure 4-19: DP Connector 4.3.3 External 2.5GbE LAN Connectors (LAN1, LAN2, LAN3) PIN NO.

  • Page 66: External Rs-232/422/485 Serial Port Connector (Com2)

    TANGO-7010 Embedded System MDIA2- MDIA0- MDIA1- MDIA0+ Table 4-21: LAN Connectors Pinouts Figure 4-20: LAN Connectors LED. DESCRIPTION PIN NO. DESCRIPTION No link 100 Mbps connection Yellow Linked Orange 1 Gbp connection TX/RX activity Green 2.5 Gbps connection Blinking Table 4-22: LAN Connectors LEDs 4.3.4 External RS-232/422/485 Serial Port Connector (COM2) Mode RS-232...

  • Page 67: External Rs-232 Serial Port Connector (Com1)

    TANGO-7010 Embedded System Figure 4-21: RS-232/422/485 Serial Port Connectors 4.3.5 External RS-232 Serial Port Connector (COM1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION SOUT Table 4-24: RS-232 Serial Port Connector Pinouts 4.3.6 External USB 3.2 GEN2 Type-A Connectors (USB1, USB2) DESCRIPTION DESCRIPTION USB_DATA0- USB_DATA1-...

  • Page 68: External Usb 3.2 Gen1 Type-A Connectors (Usb3, Usb4)

    TANGO-7010 Embedded System Figure 4-22: USB 3.2 GEN2 Port Location 4.3.7 External USB 3.2 GEN1 Type-A Connectors (USB3, USB4) DESCRIPTION DESCRIPTION USB_DATA0- USB_DATA1- USB_DATA0+ USB_ DATA1+ USB3_RX0- USB3_RX1- USB3_RX0+ USB3_ RX1+ USB3_TX0- USB3_TX1- USB3_TX0+ USB3_TX1+ Table 4-26: USB 3.2 GEN1 Type-A Connectors Pinouts Figure 4-23: USB 3.2 GEN1 Port Location Page 57...

  • Page 69: Bios

    TANGO-7010 Embedded System Chapter BIOS Page 58...

  • Page 70: Introduction

    TANGO-7010 Embedded System 1.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 71: Using Setup

    TANGO-7010 Embedded System 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen 5.1.2.1 Keyboard Navigation Function Up arrow Move to previous item Down arrow Move to next item Left arrow Move to the item on the left-hand side Right arrow Move to the item on the right-hand side Increase the numeric value or make changes...

  • Page 72: Touch Navigation

    TANGO-7010 Embedded System 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Function Button Previous Values Load the last value you set. Optimized Load the factory default values in order to achieve Defaults the best performance. Back Return to the previous menu.

  • Page 73: Getting Help

    TANGO-7010 Embedded System 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window, press the key. 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

  • Page 74: Main

    TANGO-7010 Embedded System 1.2 Main The Main BIOS menu (BIOS Menu 1 & BIOS Menu 2) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/2) BIOS Menu 2: Main (2/2) Page 63...
  • Page 75 TANGO-7010 Embedded System ➔ BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include: ▪ BIOS Vendor: Installed BIOS vendor ▪ Core Version: Current BIOS version ▪...
  • Page 76 TANGO-7010 Embedded System ▪ Stepping: Displays the PCH Stepping ▪ Production Type: Displays the Production Type ▪ Dual Output Fast Read support: Displays the Processor Details ▪ Read ID/Status Clock Freq: Displays the Read ID and Read Status Clock Frequency ▪...

  • Page 77: Advanced

    TANGO-7010 Embedded System 1.3 Advanced Use the Advanced menu (BIOS Menu 3 & BIOS Menu 4) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction.
  • Page 78 TANGO-7010 Embedded System BIOS Menu 4: Advanced (2/2) Page 67...

  • Page 79: Cpu Configuration

    TANGO-7010 Embedded System 5.3.1 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5 & BIOS Menu 6 & BIOS Menu 7) to view detailed CPU specifications or enable the Intel Virtualization Technology. BIOS Menu 5: CPU Configuration (1/3) Page 68...
  • Page 80 TANGO-7010 Embedded System BIOS Menu 6: CPU Configuration (2/3) BIOS Menu 7: CPU Configuration (3/3) ➔ Performance-core Information The Performance-core Information displays the P-core Information. Page 69...
  • Page 81 TANGO-7010 Embedded System ➔ L1 Data Cache 48 KB x 4 ➔ L1 Instruction Cache 32 KB x 4 ➔ L2 Cache 1280 KB x 4 ➔ L3 Cache 18 MB ➔ Efficient-core Information The Efficient-core Information displays the E-core Information. ➔...
  • Page 82 TANGO-7010 Embedded System ➔ Active Efficient-cores [All] Use the Active Processor Cores BIOS option to enable numbers of E-cores in the processor package. ➔ Enable all cores in the processor package. EFAULT ➔ Enable seven cores in the processor package. ➔...
  • Page 83 TANGO-7010 Embedded System ➔ Disables CPU to go to C states when it’s not Disabled EFAULT 100% utilized. ➔ Enables CPU to go to C states when it’s not Enabled 100% utilized. ➔ Power Limit 1 [0] Use the + or – key to change the Power Limit 1 value. BIOS will program the default values for Limit 1 and Power Limit 1 Time Window.

  • Page 84: Trusted Computing

    TANGO-7010 Embedded System 5.3.2 Trusted Computing Use the Trusted Computing menu (BIOS Menu 8) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 8: Trusted Computing ➔ Security Device Support [Enable] Use the Security Device Support option to configure support for the TPM. ➔...

  • Page 85: It5571 Super Io Configuration

    TANGO-7010 Embedded System 5.3.3 IT5571 Super IO Configuration Use the IT5571 Super IO Configuration menu (BIOS Menu 9) to set or change the configurations for the serial ports. BIOS Menu 9: IT5571 Super IO Configuration Page 74...
  • Page 86 TANGO-7010 Embedded System 5.3.3.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 10) to configure the serial port 1. BIOS Menu 10: Serial Port 1 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...
  • Page 87 TANGO-7010 Embedded System 5.3.3.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 11) to configure the serial port 2 BIOS Menu 11: Serial Port 2 Configuration Menu ➔ Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ➔...

  • Page 88: It5571 H/W Monitor

    TANGO-7010 Embedded System 5.3.4 IT5571 H/W Monitor The IT5571 H/W Monitor menu (BIOS Menu 12) contains the smart fan mode configuration submenu and shows the state of H/W real-time operating temperature, fan speeds and system voltages. BIOS Menu 12: IT5571 H/W Monitor ➔...

  • Page 89: Smart Fan Mode Configuration

    TANGO-7010 Embedded System 5.3.4.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 13 ) to configure the CPU/system fan start/off temperature and control mode. BIOS Menu 13: Smart Fan Mode Configuration ➔ CPU_FAN1 Smart Fan Control [Auto Mode] Use the CPU_FAN Smart Fan Control option to configure the CPU Smart Fan.
  • Page 90 TANGO-7010 Embedded System ➔ Auto mode fan off Temperature [40] Use the Auto mode fan off Temperature option to shows the temperature drops below 40 degrees, it will turn off. Use the Number key to change the value or enter a decimal number between 1 and 100 ➔...

  • Page 91: Hdmi Cec Configuration

    TANGO-7010 Embedded System 5.3.5 HDMI CEC Configuration Use the HDMI CEC Configuration submenu (BIOS Menu 14 ) to configure the HDMI CEC function. With CEC enabled, the user only needs to power-up the TANGO-7010 Series, and the TV connected with it will also turn on and automatically display audio and video content delivered by the device.
  • Page 92 TANGO-7010 Embedded System ➔ Auto Turn On Monitor If Enabled, from sleep/S4/S5 Boot, the system will turn on Monitor ➔ Auto Turn Off Monitor If Enabled, When S0 to sleep/S4/S5, the system will turn off Monitor ➔ Monitor Control System ➔...

  • Page 93: Rtc Wake Settings

    TANGO-7010 Embedded System 5.3.6 RTC Wake Settings Use the RTC Wake Settings menu (BIOS Menu 15) to enable or disable System wake on alarm event. BIOS Menu 15: RTC Wake Settings ➔ Disabled Disable System wake on alarm event. EFAULT ➔...

  • Page 94: Serial Port Console Redirection

    TANGO-7010 Embedded System 5.3.7 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 16) allows the console redirection options to be configured. Console Redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port. BIOS Menu 16: Serial Port Console Redirection ➔...

  • Page 95: Console Redirection Settings

    TANGO-7010 Embedded System 5.3.7.1 Console Redirection Settings The following options are available in the Console Redirection Settings submenu (BIOS Menu 17) when the COM Console Redirection (form COM1 to COM2) option is enabled. BIOS Menu 17: COM Console Redirection Settings ➔...
  • Page 96 TANGO-7010 Embedded System ➔ 9600 Sets the serial port transmission speed at 9600. ➔ 19200 Sets the serial port transmission speed at 19200. ➔ 57600 Sets the serial port transmission speed at 57600. ➔ 115200 Sets the serial port transmission speed at 115200. EFAULT ➔...
  • Page 97 TANGO-7010 Embedded System ➔ Sets the number of stop bits at 2. Page 86...

  • Page 98: Ami Graphic Output Protocol Policy

    TANGO-7010 Embedded System 5.3.8 AMI Graphic Output Protocol Policy Use the AMI Graphic Output Protocol Policy (BIOS Menu 18) menu to select output interface HDMI3 is Active BIOS Menu 18: AMI Graphic Output Protocol Policy Page 87...

  • Page 99: Network Stack Configuration

    TANGO-7010 Embedded System 5.3.9 Network Stack Configuration Use the Network Stack Configuration (BIOS Menu 19) menu to configure the UEFI Network Stack BIOS Menu 19: Network Stack Configuration The UEFI Network Stack is disabled by default. When enabled, the following options will be available for configuration.

  • Page 100: Nvme Configuration

    TANGO-7010 Embedded System 5.3.10 NVMe Configuration Use the NVMe Configuration (BIOS Menu 20) menu to display the NVMe controller and device information. BIOS Menu 20: NVMe Configuration Page 89...

  • Page 101: Chipset

    TANGO-7010 Embedded System 5.4 Chipset Use the Chipset menu (BIOS Menu 21) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. BIOS Menu 21: Chipset Page 90...

  • Page 102: System Agent (Sa) Configuration

    TANGO-7010 Embedded System 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 22) to configure the System Agent (SA) parameters. BIOS Menu 22: System Agent (SA) Configuration ➔ VT-d [Enabled] Use the VT-d option to enable or disable the VT-d capability. ➔...

  • Page 103: Memory Configuration

    TANGO-7010 Embedded System 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 23) to view memory information. BIOS Menu 23: Memory Configuration Page 92...

  • Page 104: Graphics Configuration

    TANGO-7010 Embedded System 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 24) menu to see the video device connected to the system. BIOS Menu 24: Graphics Configuration Page 93...

  • Page 105: Pci Express Configuration

    TANGO-7010 Embedded System 5.4.1.3 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 25) to configure the PCI Express slots. BIOS Menu 25: PCI Express Configuration ➔ PCI Express Root Port [Enabled] Use the PCI Express Root Port option to control the PCI Express Root Port ➔...
  • Page 106 TANGO-7010 Embedded System ➔ Gen4 Configure PCIe Speed to Gen4. Page 95...

  • Page 107: Pch-Io Configuration

    TANGO-7010 Embedded System 5.4.2 PCH-IO Configuration Use the PCI-IO Configuration menu (BIOS Menu 26 ) to configure the PCH Parameters BIOS Menu 26: PCI-IO Configuration ➔ Auto Power Button Status [Disabled(ATX)] The Auto Power Button Status BIOS option to show the power mode state is ATX ➔...
  • Page 108 TANGO-7010 Embedded System Power Saving Function (EUP) [Disabled] ➔ Use the Power Saving Function (EUP) BIOS option to enable or disable the power saving function. ➔ Disabled Power saving function is disabled. EFAULT ➔ Enabled Power saving function is enabled. It will reduce power consumption when the system is off.

  • Page 109: Pci Express Configuration

    TANGO-7010 Embedded System 5.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 27) to configure the PCI Express slots. BIOS Menu 27: PCI Express Configuration ➔ PCIe Express Root Port [Enabled] Use the M2_E1 and M2_M1 submenu to configure the PCI Root Port Settings. ➔...
  • Page 110 TANGO-7010 Embedded System ➔ Gen3 Configure PCIe Speed to Gen3. Page 99...

  • Page 111: Sata Configuration

    TANGO-7010 Embedded System 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 28) to change or set the configuration of the SATA devices installed in the system. BIOS Menu 28: SATA Configuration ➔ SATA Mode Selection [AHCI] Use the SATA Mode Selection option to determine how the SATA devices operate. ➔...

  • Page 112: Security

    TANGO-7010 Embedded System 5.5 Security Use the Security menu (BIOS Menu 29 & BIOS Menu 30 to set system and user passwords. BIOS Menu 29: Security (1/2) BIOS Menu 30: Security (2/2) Page 101...
  • Page 113 TANGO-7010 Embedded System ➔ Administrator Password Use the Administrator Password to set or change an administrator password. ➔ User Password Use the User Password to set or change a user password. Page 102...

  • Page 114: Boot

    TANGO-7010 Embedded System 5.6 Boot Use the Boot menu (BIOS Menu 31) to configure system boot options. BIOS Menu 31: Boot 5.6.1 Boot Configuration ➔ Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots ➔...

  • Page 115: Save & Exit

    TANGO-7010 Embedded System 5.7 Save & Exit Use the Save & Exit menu (BIOS Menu 32) to load default BIOS values, optimal failsafe values and to save configuration changes. BIOS Menu 32: Save & Exit ➔ Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.
  • Page 116 TANGO-7010 Embedded System ➔ Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. ➔ Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup Page 105...
  • Page 117 TANGO-7010 Embedded System Appendix Regulatory Compliance Page 106...
  • Page 118 TANGO-7010 Embedded System DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.
  • Page 119 TANGO-7010 Embedded System Appendix Product Disposal Page 108...
  • Page 120 TANGO-7010 Embedded System CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.
  • Page 121 TANGO-7010 Embedded System Appendix Error Beep Code Page 110...
  • Page 122 TANGO-7010 Embedded System C.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available C.2 DXE Beep Codes...
  • Page 123 TANGO-7010 Embedded System Appendix Hazardous Materials Disclosure Page 112...
  • Page 124 TANGO-7010 Embedded System D.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).
  • Page 125 TANGO-7010 Embedded System D.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 114...

This manual is also suitable for:

Tango-7010-i9awc-r10Tango-7010-i7awc-r10Tango-7010-i5awc-r10Tango-7010-i3awc-r10

Table of Contents
