Physical Characteristics
VDSL Specifications
Band Plan: Up to 6 bands
Signal Bandwidth: 25 kHz to 30MHz
Data Rate: Up to 100 Mbps / 100 Mbps (Downstream/Upstream)
Range: Up to 200 meters (656 ft)
Optional Band: US0 from 4~25 kHz (low end) to 138~276 kHz (high end)
Multi-Carrier-Modulation (MCM) - DMT modulation
Interleaving: general convolution
Tone Spacing: 8.6 kHz
Upstream Power Back-off (UPBO)
Compliance: ETSI 101/270, ANSI T1E1.4 and ITU-T G.993.2 (Plan 998)
Ports
16 VDSL lines (RJ-21 Connector)
16 POTS lines (RJ-21 Connector)
2 Gigabit Ethernet combination uplink ports (RJ-45/SFP)
1 Fast Ethernet management port (RJ-45)
Network Interface
Ports 1-16: VDSL lines, auto-negotiation
Ports 17-18: RJ-45/SFP combo port, auto-negotiation, auto MDI/X
Management Port: RJ-45 connector, auto MDI/X
RJ-45 ports –
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5, 5e, or 6)
Maximum Cable Length - 100 m (328 ft)
A
PPENDIX
S
PECIFICATIONS
C
C-1
