C
4
HAPTER
M
N
AKING
ETWORK
C
ONNECTIONS
The TigerAccess EE Switch is designed to connect subscriber ports via
VDSL lines, and uplink to the service provider's network via twisted-pair
or fiber optic cabling. The uplink ports can be connected to network cards
in PCs and servers, as well as to hubs, switches or routers. The dedicated
management port is designed for local configuration access outside of the
data network.
Connecting RJ-21 Cables
For incoming phone lines, a switch can connect directly to a PBX or can
be connected via a punch-down block or patch panel. The particular
connection method used will depend on the type of connectors and cables
supported on the PBX, and on the existing cabling in the building.
The RJ-21 cables from the switch are connected to the punch-down block
that connects the phone lines and run up to the end users.
For all connections to the switch, cables with standard Telco RJ-21
connectors must be used. Some punch-down blocks and panels can be
pre-wired with an RJ-21 connector, making the connection simple.
Otherwise, a cable with an RJ-21 on one end and free wiring on the other
end will be required.
Note: RJ-21 Cable is Type-1 26 AWG (100 ohm)/0.4 mm, or Type-2 24
AWG (100 ohm)/0.5 mm cable with male RJ-21 connectors at
4-1
