Installation Manual - 230.4000VT
Ver. 2.53
www.isenbergfaucets.com
Thermostatic Valve Trim & Handle Set
Use With TVH.2693, TVH.2717F & TVH.2705F Valves
BEFORE YOU BEGIN
•
You must observe all local plumbing laws and codes.
•
Do not install this valve if it does not meet local plumbing codes.
•
Shut off the main water supply.
Advertisement
Table of Contents
Related Manuals for Isenberg 230.4000VT
Summary of Contents for Isenberg 230.4000VT
- Page 1 Installation Manual - 230.4000VT Thermostatic Valve Trim & Handle Set Use With TVH.2693, TVH.2717F & TVH.2705F Valves BEFORE YOU BEGIN • You must observe all local plumbing laws and codes. • Do not install this valve if it does not meet local plumbing codes. • Shut off the main water supply. Ver. 2.53 www.isenbergfaucets.com...
- Page 2 INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Remove mud guards Install 42mm ring The 42mm ring must be flush. Otherwise the handle A hard push may be required will not fit properly www.isenbergfaucets.com...
- Page 3 INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Insert trim plate Align Trim plate till it is straight Insert adapter base and tighten Insert centring knob & screws www.isenbergfaucets.com...
- Page 4 INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Insert volume handle. Tighten hex screw & insert Remove anti-scald temperature ring and reinsert cover button in correct position - see next image Caliberate cartridge before inserting temperature Correctly re-insert anti-scald temperature ring in the handle. Red marks must align. right position www.isenbergfaucets.com...
- Page 5 INSTALLING THE TRIM - TRIM PLATE SIZE AND SHAPE MAY VARY - ILLUSTRATION ONLY Insert temperature handle. Tighten hex screw & This photo shows a completely installed trim insert cover button www.isenbergfaucets.com...
