310648 Rev.E
Solvent Purge Plural Component Gun
248597, Series A
Solvent Purge Manual Spray Gun
248647, Series A
Machine Mount Spray Valve with Manual Solvent Purge
248603, Series A
Standard Mechanical Purge Conversion Kit
3500 psi (24.2 MPa, 242 bar) Maximum Fluid Working Pressure
80-130 psi (0.55-0.9 MPa, 5.5-9.1 bar) Air Inlet Pressure Range
200°F (94°C) Maximum Fluid Temperature
3500 psi (24.2 MPa, 242 bar) Maximum Solvent Working Pressure
TI5006a
TI4965a
US Patent Pending
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
II 2 G
Copyright 2004, Graco Inc. is registered to I.S. EN ISO 9001
