Graco GH 130 Instructions Manual

Electric motor kit
Hide thumbs Also See for GH 130:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Instructions
™
GH
130/200/230
™
DutyMax EH
DI/Electric Motor Kit
For professional use only.
Not approved for use in explosive atmosphere or hazardous locations.
For portable airless spraying of architectural paints and coatings.
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this manual and related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure
See page 3 for model information, including maximum working pressure and approvals.
288473: 120 Vac, 60 Hz, 15A
GH130 Sprayer Electric Motor Kit
288474: 120 Vac, 60 Hz, 20A
Same as 288473 except with ETL approval to CSA and UL standards
248949: 120 Vac, 60 Hz, 15A
GH200/GH230 Sprayer Electric Motor Kit
248950: 120 Vac, 60 Hz, 20A
Same as 248949 except with ETL approval to CSA and UL standards
248946: 220 Vac, 50 Hz, 15.0A
DutyMax EH200/EH200HDI Sprayer Electric Motor Kit
DutyMax EH230DI Sprayer Electric Motor Kit
24M668: 220 Vac, 50 Hz, 15.0A
DutyMax EH200DI Sprayer Electric Motor Kit
24M669: 400 Vac, 50 Hz, 11.0A
DutyMax EH300DI and EH675 Sprayer Electric Motor Kit
200/200 HDI/200 DI/230 DI/300 DI/675
310812P
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH 130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Graco GH 130

Summary of Contents for Graco GH 130

  • Page 1 Instructions ™ 130/200/230 ™ DutyMax EH 200/200 HDI/200 DI/230 DI/300 DI/675 310812P DI/Electric Motor Kit For professional use only. Not approved for use in explosive atmosphere or hazardous locations. For portable airless spraying of architectural paints and coatings. IMPORTANT SAFETY INSTRUCTIONS. Read all warnings and instructions in this manual and related manuals.
  • Page 2 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 3: Power Requirements

    Grounding Grounding Pulley Placement Sprayer Models: 248559, 248560, 248561,248565, 248566, 248568, 253709, 253957, 253959, 253980, 253960, 253962, 253963, 253981, 253964, 253965, 253966, 253982 Improper installation or alteration of the grounding plug Align pulley (4) approximately 0.20 in. from end of electric will result in a risk of electric shock, fire or explosion that motor shaft.

  • Page 4: Electric Motor

    Parts - 288473, 288474, 248949, 248950 Parts - 288473, 288474, 248949, 248950 ti25663a Ref. Part Description Qty. Ref. Part Description Qty. 111192 SCREW, cap, flange hd 1† ELECTRIC MOTOR 15B562 BRACKET, guard, motor 246129 NON-CSA, 2.0 HP, includes 19 176347 LABEL, identification 246125 CSA, 2.0 HP, includes 19 287145 SWITCH, breaker 198838 BRACKET, mount, engine...
  • Page 5 Wiring Diagram for 196836 Power Cord Wiring Diagram for 196836 Power Cord AirPax NETZ IEG2-28495-2-V Switch FAGOR 4100+ FB5006 B250/220-50 AC Power Supply Black White Motor Thermal Switch ti12480a Wiring Diagram for 24M669 (400 Vac) GREY GREY GREY GREY BLACK BLACK BLACK BLACK...
  • Page 6 197188 PLUG, Australian, rewireable 187975 LABEL, warning (Model 248946)  116914 BELT, vee, gripnotch (not shown) 189930 LABEL, warning (Model 24M668) 15B804 LABEL, Graco, logo Warning labels, tags, and cards are free.  290228 LABEL, caution (Model 248946) 15K616 LABEL, caution (Model 24M668) Breaker Switch Repair Kit 287744 is available.
  • Page 7 Parts - 24M669 Parts - 24M669 ti18618a Ref. Part Description Qty. Ref. Part Description Qty. 112958 NUT, hex, flanged 111193 SCREW, cap flange hd 16M473 TUBE, handle, conversion 116780 SCREW, hex, hd, flanged 113817 BUMPER 125811 PULLEY, cast iron, 8.75 in 100057 SCREW, cap, hex hd 15K616 LABEL ...

  • Page 8: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.

This manual is also suitable for:

Gh 230Dutymax eh 200Dutymax eh 200 hdiDutymax eh 200 diDutymax eh 230 diDutymax eh 300 di ... Show all
