Introducing the DP ADD2 PCIe DVI Adapter
The DP ADD2 PCIe DVI Adapter is an economical way to
add a second monitor to PCs using select Intel PCI
Express based graphics controllers.
productivity by using it as an extended desktop or as a
larger/different display for your main screen.
Features and Benefits
•
Adds a DVI-D port for an additional monitor
•
Multiple display functionality: primary, extended,
twin (mirror) and rotation
•
Dual profile design to work with standard height
and low profile chassis
•
Supports Intel SDVO (Serial Digital Video Output)
technology
•
DVI 1.0 compliant
•
Bandwidth: 25 - 165 MHZ
•
Maximum resolution: 1600 x 1200 (UXGA)
System Requirements
•
Intel
915G/945/965 based desktop PC
®
•
An available x16 PCI Express slot
•
Intel Graphics Media Accelerator Driver installed
•
Windows
bit) / Server 2008 (32-/64-bit)
04-0534A
DP ADD2 PCIe DVI Adapter
Quick Installation Guide
2000 / XP (32-/64-bit) / Vista (32-/64-
®
Increase your
1
Advertisement
Table of Contents
Related Manuals for SIIG VV-CV0012-S1
Summary of Contents for SIIG VV-CV0012-S1
-
Page 1: Quick Installation Guide
DP ADD2 PCIe DVI Adapter Quick Installation Guide Introducing the DP ADD2 PCIe DVI Adapter The DP ADD2 PCIe DVI Adapter is an economical way to add a second monitor to PCs using select Intel PCI Express based graphics controllers. productivity by using it as an extended desktop or as a larger/different display for your main screen. -
Page 2: Package Contents
Package Contents • DP ADD2 PCIe DVI Adapter • Spare low profile bracket • This quick installation guide Layout DVI port Figure 1: DP ADD2 PCIe DVI Adapter... -
Page 3: Hardware Installation
Hardware Installation Note: For low-profile systems, remove the full-profile bracket and install the low-profile bracket before proceeding. General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer's reference manual for further information, if needed. - Page 4 Using the DP ADD2 PCIe DVI Adapter To get the full function from the DP ADD2 PCIe DVI Adapter, Intel Graphics Media Accelerator Driver must be installed and working properly with the existing monitor. For systems that do not have this utility, contact the system manufacturer directly or go to www.Intel.com for the latest graphics drivers.
- Page 5 Figure 3: Display Devices screen Modes • Extended Desktop: extends your desktop for easy viewing of multiple windows. Use the two monitor graphic representation, in the bottom right corner, to virtually position each monitor to conveniently move from one screen to the other •...
- Page 6 Figure 4: Display Settings screen Modes • Color Quality: selects the amount of colors your monitor will display • Screen Resolution: changes the resolution of the selected monitor • Refresh Rate: selects the refresh rate of the selected monitor • Rotation: rotates the screen from 0, 90, 180, and 270 degrees of the selected monitor Click Apply or OK to view or save any changes you have...
-
Page 7: Technical Support And Warranty
Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product. - Page 8 Fremont, CA 94538-3152, USA Ph: 510-657-8688 DP ADD2 PCIe DVI Adapter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Intel is a registered trademark of Intel Corporation in the United States and other countries.
