PRODUCT OVERVIEW
Category
SMS
Certifications and Compliance
EMC Compliance
Radio Compliance
Safety Compliance
Network Compliance
Carrier

RS-232 9-Pin Female Connector

Pin Abbreviation
1 CD
2 RX
3 TX
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI

Power Measurements

Multi-Tech Systems, Inc. recommends incorporating a 10% buffer into your power source when determining
product load.
12
Description
Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
FCC Part 15 Class B
FCC Part 22, 24, 27
UL 60950-1 2nd ED
cUL 60950-1 2nd ED
IEC 60950-1 2nd ED
PTCRB
GCF
AT&T
Verizon
Description
Carrier Detect
Receive
Transmit
Data Terminal Ready
Ground
Data Set Ready
Request to Send
Clear to Send
Ring Indicator
In/Out
O
O
I
I
--
O
I
O
O
