- Page 1 Installation Instructions / Warranty Steel 35115801 Steel 35116801...
-
Page 2: Technical Data
Wall Mounted Single-Handle Lav Set with Base Plate 35115801 Wall Mounted Single-Handle Lav Set 35116801 35115801 35116801 Technical Data Max. flow rate: . gpm Max. water pressure: 147 psi Recommended pressure: 14.7 - 7 psi Test pressure: 3 psi Max. hot water temperature: 176°... - Page 3 Installation with 38111181 rough manufactured before 03/2004 Turn the water off at the supply before beginning this installation. Remove the covers from the plaster shields (1). Trim the plaster shields so that they extend 1/16” out- side the surface of the finished wall (). Seal the wall around the plaster shield with waterproof sealant.
- Page 4 Install the new cup washers and springs in the rough. Install the cartridge assembly. Installation with 38111181 rough manufactured after 04/2004 Turn the water off at the supply before beginning this installation. Remove the covers from the plaster shields. Trim the plaster shields so that they extend 1/16” outside the surface of the finished wall.
- Page 5 Install the cartridge and anti-twist device in the housing. Install the cup washers and springs in the rough. Install the cartridge assembly. Installation with all models: Push the handle over the cartridge stem. Tighten the handle screw with a mm Allen wrench. If you are installing 35115801, turn to page 6.
- Page 6 Model 35115801 only: Measure the distance between the wall surface and the end of the handle (x). If x is between 3 1/4” and 3 7/8”, select the two “A” sleeves (1 1/4”). If x is between 3 7/8” - 4 3/8”, select the two “B” sleeves (7/8”).
- Page 7 Connect the fixation nuts to the sleeves. Measure the distance from the rough to the outside surface of the finished wall (X) (1). Add 1 3/16” to X. Cut the spout connecting thread so that it is X + 1 3/16” long (). Wrap the connecting thread with Teflon tape.
- Page 8 Push the baseplate against the wall (1). Thread the sleeves into the rough (). Tighten the retaining nuts with the service key. Lightly lubricate the o-rings on the spout and handle escutcheons with the enclosed lubricant (1). Push the escutcheons onto the baseplate ().
- Page 9 Push the spout over the connecting thread (1). Tighten the set screw with a 3 mm Allen wrench (). Install the handle flange (3).
- Page 10 Model 35116801 only: Measure the distance between the wall surface and the end of the handle (x). If x is between 3 1/4” and 3 7/8”, select the “A” sleeve (1 1/4”). If x is between 3 7/8” - 4 3/8”, select the “B” sleeve (7/8”).
- Page 11 Push the sealing ring into the handle escutcheon (1). Install the handle escutcheon onto the sleeve (). Push the sleeve / handle escutcheon assembly into place over the handle (1). Tighten it by rotating it clockwise (). Push the flange over the handle.
- Page 12 Measure the distance from the rough to the outside surface of the finished wall (X) (1). Add 1 3/16” to X. Cut the spout connecting thread so that it is X + 1 3/16” long (). Wrap the spout connecting thread with Teflon tape. Install the spout connecting thread.
- Page 13 User Instructions Pivot the handle up to turn the water on, down to turn it off. Pivot the handle to the left for warmer water, to the right for cooler water. 35115801...
-
Page 14: Replacement Parts
35116801 Replacement Parts flange 608800 handle escutcheon 60800 handle 3504800 spout escutcheon 610800 handle escutcheon 61800 washer 7600000 spout escutcheon 613800 fixing set 771000 baseplate 67800 cartridge 633000 *not included aerator 6683800 spout 78800 anti-twist device 780000 connecting thread 730000 extension kit 388000* set screw... -
Page 15: Limited Lifetime Consumer Warranty
Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. - Page 16 including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Hansgrohe and Commercial products, and (ii) for 5 years, with respect to AXOR products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship.
