5.2.2 J2 – MIPI Video Interface
Hirose BM20B(0.8)-30DS-0.4V
Pin No.
Name
1
MIPI-DATA1-
2
MIPI-DATA1+
3
DGND
4
MIPI-DATA3-
5
MIPI-DATA3+
6
DGND
7
MIPI-DATA0-
8
MIPI-DATA0+
9
DGND
10
MIPI-DATA2-
11
MIPI-DATA2+
12
DGND
13
MIPI-CLK-
14
MIPI-CLK+
15
AGND
16
NOT CONNECTED
17
AVDD
18
DVDD
19
DOVDD
20
NOT CONNECTED
21
CLK
22
NOT CONNECTED
23
SID
24
I2C SCL
25
I2C SDA
26
#Reset
27
NOT CONNECTED
28
NOT CONNECTED
29
NOT CONNECTED
30
NOT CONNECTED
Note:
This video interface is natively compatible with the IONODES MIPI camera with OV12A10 sensor
and Panomorph lens (ION-CAM-OV12A10MIPI). For connecting other MIPI cameras an adapter
board is required.
Comments
2.8V
1.2V
1.8V
0 (connected to GND)
www.ionodes.com
11
