5| Electrical connection
Star-delta start-up is only possible for ∆ (e.g. 280 V) power supply. Example:
Direct start
L1 L2
L3
L1 L2
L3
INFO
96027-11.06-DGbF
© Danfoss | Climate Solutions | 2023.07
280 V ∆
Star-delta start
L1 L2
L1
L2
Insulator
The supplied insulators must be mounted according to the illustrations
as shown.
The connection examples shown refer to the standard version. In the case
of special voltages, the instructions affixed to the terminal box apply.
Direct start only
L3
L3
Insulators
AQ450435396289en-US0201 | 17
L3
L1 L2
460 V Y
L3
L1 L2
96027-11.06-DGbF
D
US
