- Page 1 ® BOCK Operating guide HGX12/20-4 ML CO HGX12/20-4 S CO HGX12/20-4 SH CO HGX12/30-4 ML CO HGX12/30-4 S CO HGX12/30-4 SH CO HGX12/40-4 ML CO HGX12/40-4 S CO HGX12/40-4 SH CO Translation of the original instructions AQ450745530628en-000301...
-
Page 2: Table Of Contents
4.9 Operating mode of the lockable service connections 4.10 Oil return 4.11 Suction pipe filter Electrical connection 5.1 Information for contactor and motor contactor selection 5.2 Connection of the driving motor 2 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... - Page 3 6.10 Filter dryer Maintenance Preparation 7.2 Work to be carried out 7.3 Spare parts recommendation / accessories 7.4 Lubricants / oil 7.5 Decommissioning Technical data Dimensions and connections Declaration of incorporation AQ450745530628en-000301 | 3 © Danfoss | Climate Solutions | 2023.09...
-
Page 4: Safety
As well as professions with comparable training, which enable personnel to assemble, install, maintain and repair refrigeration and air-conditioning systems. Personnel must be capable of assessing the work to be carried out and recognising any potential dangers. 4 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 5: Safety Instructions
Only the refrigerant specified in these instructions may be used. Any other use of the compressor is prohibited! AQ450745530628en-000301 | 5 © Danfoss | Climate Solutions | 2023.09... -
Page 6: Short Description
Transport eyelet Valve plate Name plate Oil pump Oil sight glass Fig. 1 Cylinder cover Terminal box Connection Connection Fig. 2 Dimension and connection values can be found in chapter 9 6 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 7: Type Key
ML - Normal cooling and deep freezing at low and medium evaporation temperatures ³ - For frequency regulation and extended limits of application SH - For high evaporating temperatures eg. heat pumps, different oil charge AQ450745530628en-000301 | 7 © Danfoss | Climate Solutions | 2023.09... -
Page 8: F 3 Areas Of Application
- A minimum running time of 3 min. steady-state condition (continuous operation) must be achieved. Avoid continuous operation in limit range. LP = Low pressure Max. permissible operating : 100/150 bar HP = High pressure pressure (LP/HP) 8 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 9: Compressor Assembly
Do not use in a corrosive, dusty, damp atmosphere or a com- bustible environment. Setup on an even surface or frame with sufficient load-bearing capacity. Single compressor preferably on vibration damper. Compound connection basically rigid. AQ450745530628en-000301 | 9 © Danfoss | Climate Solutions | 2023.09... -
Page 10: Connecting The Pipelines - Solder System
After assembly, it is necessary to check the collar. The gasket must not be damaged. At least 80 % of the cutting face has to be covered. After check-up, screw on and tighten again as described above. 10 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 11: Pipes
Risk of injury. The compressor must be depressurized through connections A1 and B1 before commencing any work and prior to connecting to the refrigerant system. Fig. 7 Abb. 8 Fig. 8 AQ450745530628en-000301 | 11 © Danfoss | Climate Solutions | 2023.09... -
Page 12: Laying Suction And Pressure Lines
Before opening or closing the shut-off valve, release the valve spindle seal by approx. of a turn counter-clockwise. After activating the shut-off valve, re-tighten the adjustable valve spindle seal clockwise. Tighten Release Valve spindle seal Fig. 11 Fig. 10 12 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 13: Operating Mode Of The Lockable Service Connections
For systems with long pipes and higher degree of contamination, a filter on the suction-side is recommended. The filter has to be be renewed depending on the degree of contamina- tion (reduced pressure loss). AQ450745530628en-000301 | 13 © Danfoss | Climate Solutions | 2023.09... -
Page 14: Electrical Connection
Adjust the overload protection device so that it must be actuated within 2 hours at 1.2 times the maximum working current. 14 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 15: Connection Of The Driving Motor
Star-delta start refer to the stand- L1 L2 INFO ard version. In the case of special volt- ages, the instruc- tions affixed to the terminal box apply. L1 L2 L1 L2 AQ450745530628en-000301 | 15 © Danfoss | Climate Solutions | 2023.09... - Page 16 Cold conductor (PTC sensor) motor winding Thermal protection thermostat (PTC sensor) Load circuit safety switches Control power circuit fuse High pressure safety monitor Safety chain (high/low pressure monitoring ) Release switch (thermostat/pressostat) 16 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09...
- Page 17 L1.1 L2.1 L3.1 L1.2 P> Θ Θ Main switch Control voltage switch Compressor motor Compressor contactor INT69 G Electronic trigger unit INT69 G Oil sump heater AQ450745530628en-000301 | 17 © Danfoss | Climate Solutions | 2023.09...
-
Page 18: Electronic Trigger Unit Int69 G
5.6 Function test of the trigger unit INT69 G Before commissioning, after troubleshooting or making changes to the control power circuit, check the functionality of the trigger unit. Perform this check using a continuity tester or gauge. 18 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 19: Oil Sump Heater
The permissible frequency range can be found in the technical data chapter 8, p. 26. Rotational speed 0 - f-min f-min - f-max range < 1 s ca. 4 s Start-up time immediately Switch-off time f-min/f-max see chapter 8: Technical data: permissible frequency range AQ450745530628en-000301 | 19 © Danfoss | Climate Solutions | 2023.09... -
Page 20: Commissioning
Only dry test gases may be used for the leak test, e.g. nitrogen N2 min. 4.6 (= purity 99.996 % or higher). 20 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 21: Evacuation
Avoid overfilling the machine with refrigerant! ATTENTION Do not charge liquid refrigerant into the suction-side on the compressor. Do not mix additives with the oil and refrigerant. AQ450745530628en-000301 | 21 © Danfoss | Climate Solutions | 2023.09... -
Page 22: Start-Up
(con- nections A and B, see Chapter 9). 22 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 23: Decompression Valves
EN 378-2 or appropriate safety standards. Failure to observe can result in risk of injury from CO streaming out of the two decompression valves! streaming Fig. 17 AQ450745530628en-000301 | 23 © Danfoss | Climate Solutions | 2023.09... -
Page 24: Avoiding Slugging
CO is produced which blocks the outlet and could hinder the streaming out of CO . Otherwise, there is the danger that pressure can be built up again. 24 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... -
Page 25: Work To Be Carried Out
For this reason the suction side (LP) and the high pressure side (HP) of the compressor have to be secured by decompression valves. AQ450745530628en-000301 | 25 © Danfoss | Climate Solutions | 2023.09... -
Page 26: Technical Data 26 F
220-240 V ∆ / 380-420 V Y - 3 - 50 Hz Voltage 265-290 V ∆ / 440-480 V Y - 3 - 60 Hz Displacement (1450 / 1740 rpm) No. of cylinders Type HGX12/ 26 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... - Page 27 8 | Technical data AQ450745530628en-000301 | 27 © Danfoss | Climate Solutions | 2023.09...
- Page 28 242 9,53 82 3,22 293 11,54 + 0,08 19,69 Dimensions and connections with shut-off valves: 99 3,9 SV A1 397 15,62 + 0,08 20,2 Dimensions in mm [inch] Fig. 18 28 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09...
- Page 29 Decompression valve HP M24x1,5 Decompression valve LP M22x1,5 Connection for Schrader valve, suction side 7 / 16 “ UNF 7 / 16 “ UNF Connection for Schrader valve, discharge side AQ450745530628en-000301 | 29 © Danfoss | Climate Solutions | 2023.09...
-
Page 30: Declaration Of Incorporation
Bock GmbH Authorized person for compiling and handing Alexander Layh over technical documentation: Benzstraße 7 72636 Frickenhausen, Germany Frickenhausen, 04th of January 2021 i. A. Alexander Layh, Global Head of R&D 30 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09... - Page 31 Bock GmbH Authorized person for compiling and handing Alexander Layh over technical documentation: Benzstraße 7 72636 Frickenhausen, Germany Frickenhausen, 14th of October 2022 i. A. Alexander Layh, Global Head of R&D AQ450745530628en-000301 | 31 © Danfoss | Climate Solutions | 2023.09...
- Page 32 32 | AQ450745530628en-000301 © Danfoss | Climate Solutions | 2023.09...
