- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Joleena 04792XX0...
- Page 2 English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140° F (48° - 60° C)* recommandée 120°-140° F (48° - 60° C)* Maximum 158°F (70° C)* maximum 158°F (70° C)* Max. flow rate 1.75 GPM (6.6 L/min) Capacité nominale 1.75 GPM (6.6 L/min) Hole size in mounting surface 1⅜" (35 mm) Dimension du trou dans 1⅜" (35 mm) Max. depth of mounting surface 2¾" (70 mm) la surface de montage Profondeur maximale de 2¾ po (70 mm) la surface de montage * Please know and follow all applicable local plumbing codes when setting the temperature on the water heater.
- Page 3 Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* max. 158°F (70° C)* Caudal máximo 1.75 GPM (6.6 L/min) Tamaño del orificio en la superficie 1⅜" (35 mm) de montaje 16 mm Profundidad máxima de la 2¾" (70 mm) superficie de montaje * Debe conocer y cumplir todos los códigos locales aplicables para ajustar la temperatura del calentador de agua.
- Page 4 Joleena 04792XX0 9¾" (249 mm) 8⅞" (224 mm) Ø1⅛" (28 mm) 2⅜" (59 mm) 5⅛" (131 mm) 3⅛" (79 mm) 4⅛" (104 mm) Ø2½" (65 mm) Ø1¼" (32 mm) ⅜...
- Page 5 Before beginning installation / Avant de commencer l'installation / Antes de comenzar la instalación > 5 min English Español Français Flush the hot and cold supplies Rincez les conduites d' alimenta- Lave los suministros de agua for at least 5 minutes. tion de l'eau chaude et de l'eau caliente y frÍa durante al menos froide aux moins cinq minutes. cinco minutos. Suggestion: Use an extra sup- Suggestion : Utilisez un tuyau Sugerencia: Utilice una ply line (not included) to direct d’arrivée supplémentaire (non manguera de suministro adicio- the water into a bucket. compris) pour diriger l'eau dans nal (no incluido) para dirigir el un seau. agua en un cubo.
-
Page 6: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Place the faucet and sealing ring Placez l'anneau d'étanchéite Coloque el oro de sellado y on the mounting surface. et le robinet sur la surface de el grifo sobre la superficie de montage. montaje. Install the friction washer, metal washer, and mounting nut. Installez la rondelle en fibre, la Instale la arandela de fibra, la rondelle de friction, et l'écrou de arandela de fricción y la tuerca montage. de fijación. Tighten the mounting nut. Serrez l'écrou de montage et les Apriete la tuerca de fijación y vis de serrage. los tornillos. Tighten the screws. - Page 7 English Español Français Connect the hot and cold supply Connectez les tuyaux d’arrivée Conecte las mangueras de hoses to the stops. d’eau chaude et d’eau froide suministro de agua caliente y aux butées d'arrêt. fría a los topes. Do not allow the hose to twist. Assurez-vous que le No permita que la tuyau ne s’entortille manguera se retuerza. pas.
- Page 8 Replacement Parts / Pièces détachées / Repuestos Joleena 04792XX0 Joleena 93539XX0 04797XX0 not included pas d'inclus no incluida 93259000 93256XX0 93546XX0 93537XX0 93263000 xx = Colors / Couleurs / Acabados 00 = Chrome 67 = Matte Black 82 = Brushed Nickel 83 = Polished Nickel...
- Page 9 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold chaud froid caliente frío needle spray aerated spray Temporary stop La fonction d'arrêt temporaire La función de parada temporal...
- Page 10 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it. For best results: • Prevent the buildup of mineral scale and /or soap residue by cleaning your Hansgrohe product(s) when needed. • Select a cleaning agent specifically intended for the type of product. • Do not use these types of cleaners as they will cause damage to your Hansgrohe product: ´ Any cleaning agent containing hydrochloric acid, formic acid, lye, or acetic acid. ´ Abrasive cleaning powders, pads, or brushes. ´ Steam cleaners. ´ “No rinse” cleaning agents. • Always follow the instructions provided by the manufacturer of the cleaning agent. • Do not mix cleaning agents, unless directed by the manufacturer. • Do not spray cleaners directly onto the product as drops could enter openings and gaps and cause damage. When using spray cleaners, spray the cleaner onto a soft cloth or sponge. • Always rinse your Hansgrohe product thoroughly with clear water and polish dry with a soft cloth after cleaning. Important •...
-
Page 11: Para Obtener Mejores Resultados
Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. • Le résidu provenant des nettoyants pour cuvette/baignoire/carrelage peut endommager les robinets et les raccords de tuyauterie. Rincez immédiatement toute surpulvérisation sur le produit Hansgrohe. • De meme, il est interdit de stocker des detergents ou des produits chimiques sous les produits, par ex. dans un meuble sous lavabo, car les vapeurs qui s’en degagent risquent d’abimer les produits. • Les dommages au produit causés par un mauvais entretien ou par l’utilisation de produits de nettoyage inadéquats ne sont pas couverts par la garantie. • Si un composant du produit est endommagé, remplacez-le, car il existe un risque de blessure. -
Page 12: Limited Consumer Warranty
Limited Consumer Warranty This warranty is limited to products manufactured by Hansgrohe, conditions in the home such as excessive water pressure Inc. (“Hansgrohe”) that are purchased by a consumer in the United or corrosion. States or Canada after March 1, 1996, and installed in either the C. Labor and other expenses for disconnection, deinstallation, United States or in Canada. or return of the product for warranty service (including but not limited to proper packaging and shipping costs), or for WHO IS COVERED BY THE WARRANTY installation or reinstallation of the product. D. Accessories, connected materials and products, or related This limited warranty extends to the original purchaser only. This products not manufactured by Hansgrohe. warranty is non-transferable. Hansgrohe neither assumes nor Any Hansgrohe or Axor product sold for display purposes. authorizes any person to create for it any other obligation or liability in connection with this product. HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY OTHER PERSON FOR ANY INCIDENTAL, SPECIAL OR LENGTH OF WARRANTY CONSEQUENTIAL DAMAGES, ARISING OUT OF BREACH...
