parts list

ITEM QTY REFERENCE
Required Circuit Components
1 1 BAT1
2 1 BTH1
3 1 C1
4 1 C2
5 2 C7, C8
6 2 C3, C6
7 1 C11
8 1 C4
9 1 C5
10 1 L1
11 1 L2
12 3 R2, R4, R6
13 0 R3, R5, R7
14 1 R10
15 1 U1
Additional Demo Board Circuit Components
1 0 C9, C10 (OPT)
2 0 C12
3 0 BTH2
4 1 R1
5 0 R8, R9
6 3 U2, U3, U4
Hardware: For Demo Board Only
1 15 E1-E8, E12-E19
2 3 E9-E11
3 1 J1
4 10 JP1-JP10
5 1 JP11
6 11 JP1-JP11
PART DESCRIPTION
CR2032 COIN LI-ION BATTERY
SMT, CR2032 BATTERY HOLDER
SUPERCAP, 90mF, 5.5V, 20mm × 15mm
CAP, CHIP, X5R, 150µF, 20%, 10V, 1210
CAP, CHIP, X5R, 22µF, 20%, 6.3V, 1206
CAP, CHIP, X5R, 1µF, 10%, 6.3V, 0402
CAP, CHIP, X5R, 10µF, 10%, 6.3V, 0805
CAP, CHIP, X5R, 22µF, 10%, 25V, 1210
CAP, CHIP, X5R, 4.7µF, 10%, 6.3V, 0603
INDUCTOR, 22µH, 0.800A, 0.36Ω, 3.9mm × 3.9mm
INDUCTOR, 22µH, 0.75A, 0.19Ω, 4.8mm × 4.8mm
RES, CHIP, 0Ω, 0603
RES, CHIP, 0Ω, 0603
RES, CHIP, 10M, 1/10W, 5%, 0603
ENERGY HARVESTING DC/DC WITH BATTERY
CAP, CHIP, X5R, 0.1µF, 10%, 10V, 0402
SUPERCAP, 330mF, 55V, 60mΩ
SMT, CR2477 BATTERY HOLDER
RES,CHIP, 1k, 1/16W, 1%, 0402
RES, CHIP, 7.5k, 1/16W,1%,0402
IC, UHS UNIV. CONFIG. TWO-INPUT GATES, SC70-6
TURRET, 0.09 DIA
TURRET, 0.061 DIA
HEADER, 12 PIN, DUST HEADER 2×6
HEADER, 3 PINS, 2mm
HEADER, 4 PINS, 2mm
SHUNT 2MM
DEMO MANUAL DC2048A
MANUFACTURER/PART NUMBER
DURACELL, CR2032
MPD INC, BU2032SM-HD-GCT-ND
CAP-XX, HZ202F
SAMSUNG, CL32A157MQVNNNE
SAMSUNG, CL31A226MQHNNNE
SAMSUNG, CL05A105KQ5NNNC
SAMSUNG, CL21A106KQFNNNE
SAMSUNG, CL32A226KAJNNNE
SAMSUNG, CL104A475KQ8NNNE
COILCRAFT, LPS4018-223MLC
COILCRAFT, LPS5030-223MLC
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW06030000Z0EA
VISHAY, CRCW060310M0JNEA
LINEAR TECH, LTC3330EUH
TDK, C1005X5R1A104K
MURATA, DMF3R5R5L334M3DAO
RENATA, SMTU2477-1
VISHAY, CRCW04021K00FKED
VISHAY, CRCW04027K50FKED
FAIRCHILD, NC7SZ58P6X
MILL-MAX, 2501-2
MILL-MAX, 2308-2
SAMTEC, SMH-106-02-L-D-05
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-104-02-L-S
SAMTEC, 2SN-BK-G
