Concrete Poker Drive Unit & Lead
Operator's Manual
LFR40
FOR YOUR SAFETY
FOR YOUR SAFETY
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL
READ AND UNDERSTAND THE ENTIRE MANUAL
Ensure you read and understand how to operate
BEFORE OPERATING THIS MACHINE
the machine safely. Check your machines oil
BEFORE OPERATING THIS MACHINE
levels before every use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LFR40 and is the answer not in the manual?

Questions and answers

Related Manuals for Lumag LFR40

Summary of Contents for Lumag LFR40

  • Page 1 Distribution Limited Concrete Poker Drive Unit & Lead Operator’s Manual LFR40 FOR YOUR SAFETY FOR YOUR SAFETY FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL READ AND UNDERSTAND THE ENTIRE MANUAL Ensure you read and understand how to operate BEFORE OPERATING THIS MACHINE the machine safely.
  • Page 3 Vibration Oil 250ml Lumag Trans 1 1 – First service only, 2 = Should be carried out by your Lumag Dealer, 3 = May need to be done more often in dusty areas & 4 = Replace paper element only...
  • Page 6 IMPORTANT INSTRUCTIONS WATCH OUT! Read before assembly and before bringing the entire text of the manual. Familiarize yourself with this manual with the unit, its proper use and the safety instructions. NOTE The manufacturer of this equipment is liable under the applicable product liability law not in for any damage caused to this unit or by this device: improper handling,...

  • Page 7: Table Of Contents

    CONTENT CONTENT introduction Intended Use safety instructions General safety operational safety Safety while using Internal Combustion Engines Service security Residual hazards and protective measures behavior in case of emergency Warning and information symbols used controls commissioning Connection of the vibrator Tilting the machine Check before starting the engine In front Fill Startup Motor Oil...

  • Page 8: Intended Use

    INTRODUCTION INTENDED USE INTRODUCTION This manual contains information and procedures for the safe operation and safe maintenance of this model. For your own safety and protection from injury, you should read the safety instructions in this manual carefully and familiarize yourself with it and observe all instructions. INTENDED USE Spud petrol tank may only according to this manual and operated safety instructions and used only for concrete compaction.

  • Page 9: Safety Instructions

    SAFETY INSTRUCTIONS ATTENTION Failure to follow these instructions slight to moderate injury. NOTE Failure to observe this instruction is a risk of damage to the engine or other property. In addition, the manual contains other important passages that by the word ATTENTION Marked are.
  • Page 10 SAFETY INSTRUCTIONS If you have long hair, a hairnet and helmet. Use personal protective equipment (PPE) Always wear head, eye, hand, foot and ear protection. Use (when compacting occasionally arises in generating dust work Dust) a respirator. Avoid abnormal posture Always keep proper footing and balance at balance .

  • Page 11: Operational Safety

    SAFETY INSTRUCTIONS be a risk of injury for you can mean. 15. Use only approved parts This machine complies with the relevant safety regulations. Repairs may only be performed by an authorized service center or our service team by original spare parts are used;...

  • Page 12: Safety While Using Internal Combustion Engines

    SAFETY INSTRUCTIONS • NO WAY use the choke to stop the engine. • ALWAYS Store the machine properly when it is not used. Select a safe location so that the machine cannot be set by unauthorized persons in motion. Do not place unprotected outdoors or in a humid environment to the device.

  • Page 13: Residual Hazards And Protective Measures

    SAFETY INSTRUCTIONS and properly maintained machine. Just so you can assume that you operate your device safe, economical and trouble-free. And for a long time. • Do not clean the machine while it is running, wait, adjust or repair. Moving parts can cause serious injury.
  • Page 14 SAFETY INSTRUCTIONS Exposure to noise hearing loss Longer unprotected Working with the spud can cause hearing damage. → wear hearing protection principle. Exposure to materials and other substances Contact, inhalation The exhaust gases from the engine can be harmful to health. →...

  • Page 15: Warning And Information Symbols Used

    SAFETY INSTRUCTIONS Warning and information symbols used NOTE The machine is supplied without engine oil. Before the first start is thus fill the first motor oil. Failure to comply may result in irreparable damage to the engine. DANGER! * In the exhaust gas of the engine poisonous carbon monoxide is contained.
  • Page 16 CONTROLS CONTROLS Fig. A Fig. B Fig. C Fig. D Fig. E Gasoline engine on swivel base vibrator cotter Tube receiving socket drive coupling hose connection locking bolt...
  • Page 17 CONTROLS gasoline engine filler cap Fuel tank throttle recoil air filter Spark plug, spark plug muffler choke Engine oil filler plug with dipstick Engine oil drain bolt Recoil ignition switch...

  • Page 18: Connection Of The Vibrator

    GETTING STARTED starting up of ATTENTION Read the safety information (see "Safety") carefully and observe them. The device may not be used on sites where there is danger of explosion. Make sure that the device does not exceed 10 ° slope during use. If once stuck a ball bearing can not be beaten with a hammer on the bottle to bring this back up and running.

  • Page 19: Recommended Fuel

    GETTING STARTED BEFORE Fill Startup Motor Oil NOTE Before the first use engine oil must be filled! Faulty oil filling can cause irreparable damage to the engine. In this case, retailers and manufacturers to distance themselves from any warranty services. •...

  • Page 21: Stop Engine

    GETTING STARTED pull recoil starter lightly until resistance is felt, then rope sharply attract and allowed to slowly roll it back. start the motor If the choke is used, run the engine for about 20 seconds. 10. Then push choke lever to the left in the operating position. Stop engine set the throttle to idle (Symbol "Turtle").

  • Page 22: Maintenance Schedule

    MAINTENA MAINTENANCE WARNING perform maintenance work with the engine stopped. Comply with legal standards apply to the handling and disposal of used oil, filters and cleaning materials. Check the end of maintenance, check that all tools from the engine and all protective devices have been remounted.

  • Page 23: Oil Change

    MAINTENANCE oil change Checking the oil level Check the engine oil level is stopped and in horizontal position motor. The engine oil filler plug Remove the dipstick and wipe clean. Dipstick introduce back into the oil filler neck, but do not screw it, and then to Remove check the oil level.

  • Page 24: Air Filter

    MAINTENA air filter The air filter is equipped with two air filter inserts. Frequent cleaning of the air filter to prevent carburetor malfunction. Clean the air filter and change the air filter inserts • Unscrew the wing nut, remove the air filter cover and for holes or tears check.

  • Page 25: Cleaning The Heel Cup

    MAINTENANCE Cleaning the heel cup Drain fuel tank. Remove the air filter. Sediment cup (18) and seal (17) and remove thoroughly clean in nonflammable solvent and allow to dry. Both parts back on. Mount the air filter. Fill the fuel tank with gasoline and check for leaks. Clean sediment cup spark plug WARNING...

  • Page 26: Cleaning The Machine

    MAINTENANCE NOTE ON ENVIRONMENTAL PROTECTION Cleaning the machine After each use the device as well as the vibrator of concrete, mud, dust and other contaminants must be removed. Swivel base with a damp cloth and if necessary clean with some commercial detergent. NOTE The use of solvents, corrosive chemicals or abrasives resulting in damage to the unit! storage...

  • Page 27: Technical Specifications

    TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Model: LFR-40 Drive motor: 1-cylinder 4-stroke OHV gasoline engine Rated capacity: Fuel: Regular unleaded gasoline Fuel tank capacity: Engine oil: SAE 10W-30 or 10W-40 Oil capacity: 0.60 Spark plug: E7RTC or other equivalent spark plug Electrode gap: 0.7 0.8 operating weight about 22...

  • Page 28: Warranty / Customer Service

    WARRANTY / SERVICE WARRANTY / SERVICE warranty The statutory warranty period is 2 years from date of purchase. In case of possible product defects, please contact our customer service. To this end, we recommend that you keep your sales receipt. The warranty is in such a way that defective parts will be repaired free of charge at our discretion or replaced with correct parts.

  • Page 29: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY 10. EC DECLARATION OF CONFORMITY Under the provisions of the EC directives - Electromagnetic compatibility 2004/108 / EC - Machinery Directive 2006/42 / EC - Outdoor Directive 2000/14 / EC - 2005/88 / EC, Annex VI explains the company: LVG Hartham GmbH Robert-Bosch-Ring 3...

  • Page 30: Equipment

    EQUIPMENT EQUIPMENT designation description Order no. Ø 45 mm 5FL45 40 47424 00568 2 FL-bottle 45 flexible hose Sump pump SP-50 Ø 75 mm 5SP50 40 47424 00570 5 drive tube...
  • Page 31 D-84375 Kirchdorf Phone: +49 (0) 85 71/92 556 - 0 Fax: +49 (0) 85 71/92 556 - 19...
