REMS Python Instruction Manual page 4

Fig. 4
10
7
15
Fig. 5
20
19
8
4
9 7 7 3
Fig. 6
Biegesegment Bending Segment
für Rohre for Pipes
Ø mm/Zoll
ø inch/mm
10, ⅜
12, 10 U, ½
14, 12 U
15, 12 U, ⅝
16, 14 U
17, 15 U
18, 14 U, 15 U, 16 U, ¾
20, 18 U
22, 18 U, ⅞
25, 26
32
Bend radius mm of the neutral axis of the bend (DVGW GW 392)
1)
Biegeradius mm der neutralen Achse des Bogens (DVGW GW 392)
1)
Cu: soft copper tubes, also thin-walled
Cu: weiche Kupferrohre, auch dünnwandig
St 10305-U: soft coated carbon steel pipes of the pressfitting system
St 10305-U: weiche ummantelte C-Stahlrohre der Pressfi tting-Systeme
EN 10305-3
EN 10305-3
St 10305: soft precision steel tubes EN 10305-1, EN 10305-2,
St 10305: weiche Präzisionsstahlrohre EN 10305-1, EN 10305-2,
EN 10305-3
EN 10305-3
U: encased
U: ummantelt
V: composite pipes of the pressfitting systems
V: Verbundrohre der Pressfi tting-Systeme
4
11
Suitable for:
Geeignet für
Bending Biege-
Radius radius
1)
mm
30 ● ●
36 ● ● ●
50 ● ● ● ●
55 ● ● ●
55 ● ● ● ●
60 ● ●
72 ● ● ● ●
79 ● ● ● ●
86 ● ●
88 ●
128 ●
18
153155
R
153160
R
153170
R
153175
R
153180
R
153185
R
153190
R
153195
R
153200
R
153205
R
153210
R
3
