- Page 1 MANUAL ENGLISH Performer 2000 RGBAL Ordercode: 33038 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
- Page 2 Performer 2000 RGBAL Table of contents Warning ....................................3 Safety Instructions ................................. 3 Operating Determinations ............................5 Rigging .................................... 5 Connection with the mains............................6 Return Procedure ................................7 Claims ....................................7 Description of the device ..............................8 Features ..................................8 Frontside..................................
- Page 3 Performer 2000 RGBAL DMX Channels ................................25 8 channels (HSIC) ..............................25 10 channels (SSP) ..............................26 13 channels (TOUR) ..............................27 19 channels (TR16) ..............................29 Cleaning ....................................31 Cleaning the Glass Lens ............................31 Maintenance ..................................32 Replacing the Fuse ..............................32 Troubleshooting ................................32 No Light ..................................32 No Response to DMX..............................33 Product Specifications ..............................34 Dimensions ..................................35...
- Page 4 Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● Showtec Performer 2000 RGBAL ● Pro power cable (1,5 m) ●...
- Page 5 ● If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
- Page 6 Performer 2000 RGBAL Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 1 meter.
- Page 7 Performer 2000 RGBAL Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NEUTRAL...
- Page 8 Performer 2000 RGBAL Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture.
- Page 9 Performer 2000 RGBAL Description of the device Features The Showtec Performer 2000 RGBAL is a theater spotlight with high output and great effects. Input voltage: 100-240V AC, 50/60Hz Power consumption: 230W Light source: 1 x 240W LED Array 5-in-1 ...
- Page 10 Performer 2000 RGBAL Backside Fig. 02 05) 100-240V Pro power connector Blue IN 06) 3-pin DMX signal connector IN 07) 5-pin DMX signal connector IN 08) 3-pin DMX signal connector OUT 09) 5-pin DMX signal connector OUT 10) 100-240V Pro power connector Gray OUT 11) Fuse T6,3AL/250V 12) LCD display + control buttons Installation...
- Page 11 Performer 2000 RGBAL Color Frame Retaining Clip The color frame holder is equipped with a spring-loaded retaining clip. This prevents color frames and accessories from falling out. Make sure that all color frame accessories are locked in position with the retaining clip before hanging the Performer 2000 RGBAL.
- Page 12 Performer 2000 RGBAL Control Modes There are 3 modes: • Stand-alone • Master/Slave • RDM/DMX-512 (8CH, 10CH, 13CH, 19CH) One Performer (Stand-alone) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket.
- Page 13 Performer 2000 RGBAL Multiple Performers (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin/5-pin XLR cable to connect the Performers and other devices. 04) Link the units as shown in fig.
- Page 14 Performer 2000 RGBAL Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.
- Page 15 Performer 2000 RGBAL The Performer 2000 RGBAL can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) MENU button ENTER button C) LCD display D) DOWN button UP button Control 1 G) Control 2 Control 3 Fig.
- Page 16 Performer 2000 RGBAL Menu Overview Ordercode: 33038...
- Page 17 Performer 2000 RGBAL Main Menu Options 01) On start-up, the display will show information about the device’s current status: 02) Press the ENTER button to open the main menu. 03) Press the UP/DOWN buttons to toggle through the 10 main menu options: 04) Press the ENTER button to open the desired submenu.
- Page 18 Performer 2000 RGBAL 1.1. Mode 1 In this menu you can set the dimmer, zoom and CCT. 01) Turn the controls (F/G/H) to adjust settings. 02) The adjustment ranges are: (F) Dimmer: 0-100% (from dark to brightest) (G) Zoom: 0-100% (from small to big) ...
- Page 19 Performer 2000 RGBAL 1.4. Mode 4 In this menu you can set the dimmer, CCT and green. 01) Turn the controls (F/G/H) to adjust settings. 02) The adjustment ranges are: (F) Dimmer: 0-100% (from dark to brightest) (G) CCT: 2700K, 3000K, 3200K, 3500K, 4000K, 4200K, 4500K, 5600K, 6000K, 6500K, 7200K, 8000K ...
- Page 20 Performer 2000 RGBAL 3. Preset Colors In this menu you can choose the desired color preset. 01) While in main menu, press the UP/DOWN buttons until the display shows PRESET COLOR. 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle through the 16 color presets: L106, R05, L194, R54, L019, R08, R89, R86, L213, R377, R80, L202, L328, R3314, L101, L768.
- Page 21 Performer 2000 RGBAL 5. Run Mode In this menu you can set the device as a master or slave. 01) While in main menu, press the UP/DOWN buttons until the display shows RUN MODE. 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the 2 options: DMX and SLAVE.
- Page 22 Performer 2000 RGBAL 7.1. Upload In this menu you can send the custom programs to the slave devices. 01) When the display shows UPLOAD, press the ENTER button to open the menu. 02) The display will show PASS CODE and you will need to insert a key combination which will unlock this hidden menu.
- Page 23 Performer 2000 RGBAL 7.5. DMX Error In this menu you can determine what the device will do in case of a DMX signal error. 01) When the display shows DMX ERROR, press the ENTER button to open the menu. 02) Press the UP/DOWN buttons to toggle between the 2 options: SAVE and BLACK. 03) If the display shows SAVE, the Performer will utilize the last working DMX signal, which will ensure undisrupted performance.
- Page 24 Performer 2000 RGBAL 7.8. PWM Rate (refresh rate) In this menu you can set the refresh rate. 01) When the display shows PWM_RATE, press the ENTER button to open the menu. 02) Press the UP/DOWN buttons to toggle through the 6 options: 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25000Hz.
- Page 25 Performer 2000 RGBAL 9. Calibration.C In this menu you can set the color calibration. 01) While in main menu, press the UP/DOWN buttons until the display shows CALIBRATION.C. 02) Press the ENTER button to open the menu. 03) The display will show PASS CODE and you will need to insert a key combination which will unlock this hidden menu.
- Page 26 Performer 2000 RGBAL 10. Info In this menu you can view the device’s status. 01) While in main menu, press the UP/DOWN buttons until the display shows INFO. 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the 2 options: VERSION and RDM. 04) Press the ENTER button to open the menu.
- Page 27 Performer 2000 RGBAL 211-230 7200K 231-255 8000K Channel 6 –Strobe CH1-4 must be open Not functional 10-99 Strobe flash frequency, from low to high frequency 100-109 Not functional 110-179 Pulse strobe, from low to high frequency 180-189 Not functional 190-255 Random strobe, from low to high frequency Channel 7 –...
- Page 28 Performer 2000 RGBAL 101-110 R377 111-120 121-130 L202 131-140 L328 141-150 R3314 151-160 L101 161-170 L768 171-255 Not functional Channel 8 –Strobe CH1 must be open; CH2-6 or CH7 must be open Not functional 10-99 Strobe flash frequency, from low to high frequency 100-109 Not functional 110-179...
- Page 29 Performer 2000 RGBAL 41-50 51-60 L019 61-70 71-80 81-90 91-100 L213 101-110 R377 111-120 121-130 L202 131-140 L328 141-150 R3314 151-160 L101 161-170 L768 171-255 Not functional Channel 8 – Macros CH1 must be open 0-10 Not functional 11-30 Red 100% / Green Up / Blue 0% 31-50 Red Down / Green 100% / Blue 0% 51-70...
- Page 30 Performer 2000 RGBAL 121-140 Auto 5 141-160 Auto 6 161-180 Auto 7 181-200 Auto 8 201-220 Auto 9 221-255 Auto 10 Channel 12 – Program speed CH11 must be set between 41-255 0-255 Program speed adjustment, from slow to fast Channel 13 –...
- Page 31 Performer 2000 RGBAL Channel 11 – Lime CH1 must be open; CH13-14 must be closed 0-255 Gradual adjustment Lime, from 0-100% Channel 12 – Fine Lime CH1 and CH11 must be open; CH13-14 must be closed 0-255 Fine adjustment Lime, from 0-100% Channel 13 –...
- Page 32 Performer 2000 RGBAL Channel 15 –Strobe CH1 must be open; CH2-12 or CH13-14 must be open Not functional 10-99 Strobe flash frequency, from low to high frequency 100-109 Not functional 110-179 Pulse strobe, from low to high frequency 180-189 Not functional 190-255 Random strobe, from low to high frequency Channel 16 –...
- Page 33 Suspect three potential problem areas as: the power supply, the LEDs, the fuse. 01) Power supply. Check if the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Performer to your Showtec dealer. 03) The fuse. Replace the fuse. See page 32 for replacing the fuse.
- Page 34 Performer 2000 RGBAL No Response to DMX Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 01) Check the DMX setting. Make sure that DMX addresses are correct. 02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power. Try your DMX control again.
- Page 35 Performer 2000 RGBAL Product Specifications Model: Showtec Performer 2000 RGBAL Input voltage: 100-240V AC, 50/60Hz Power consumption: 230W (full output) DMX linking: 30pcs Fuse: T6,3AL/250V Dimensions: 455 x 285 x 435 mm (LxWxH) Weight: 7,5 kg Operating and Programming: Signal pin OUT:...
- Page 36 Performer 2000 RGBAL Dimensions Ordercode: 33038...
- Page 37 Performer 2000 RGBAL Notes Ordercode: 33038...
- Page 38 Performer 2000 RGBAL Ordercode: 33038...
- Page 39 Performer 2000 RGBAL Ordercode: 33038...
- Page 40 ©2017 Showtec...
