Getting Started

2
Getting Started
In This Chapter
This chapter will go through the process of setting up your ProLinx Wireless
PROFIBUS modules to communicate in your network. We will first configure a
Wireless PROFIBUS Master device to communicate with your slave devices.
Then we will configure the wireless network which will allow the two gateways to
communicate. In the next chapter we will configure the data exchange command
portion of both ProLinx modules to move your data from one to the other
wirelessly.
2.1

Configuring the Wireless PROFIBUS Master

Before running the configuration software, ensure that the power cable is firmly
attached to the PROFIBUS DP Master module, and that the LEDs on the front of
the module light up.
Connect the serial cable from your computer to the PROFIBUS Config port
1
on the module, located directly above the PROFIBUS Master port.
Run the SyCon configuration program.
2
From the File menu, select New to start a new project.
3
ProSoft Technology, Inc.
June 2, 2006
6104-WA-PDPM 6105-WA-PDPS ♦ ProLinx Wireless PROFIBUS Modules
Configuring the Wireless PROFIBUS Master ........................... 9
Configuring ProLinx Modules with ProSoft Configuration Builder
............................................................................................... 11
PROFIBUS Master and Slave
Page 9 of 31
