Getting Started
Click on the Master device in the project screen to select it. From the Online
8
menu, select Download. The Device Assignment CIF Serial Driver dialog will
appear. Click the Connect button for the COM port your module is attached
to. For this example we are using COM 1. The COM check box on the far left
of the dialog should become active. Check this check box and click OK.
A dialog will appear that warns of interrupting communications, and asks if
9
you want to continue with the download. Click Yes.
10 A download progress dialog will appear, showing the current progress. When
this dialog finishes successfully it will disappear.
11 At this point, save your project again and close SyCon.
ProSoft Technology, Inc.
June 2, 2006
6104-WA-PDPM 6105-WA-PDPS ♦ ProLinx Wireless PROFIBUS Modules
PROFIBUS Master and Slave
Page 11 of 31
