(Model 8191)
Woodstove
OWNER'S MANUAL
Installation And
Operating Instructions
SAVE THIS OWNER'S MANUAL
FOR FUTURE REFERENCE
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE YOUR
NEW TULA WOOD STOVE.
If this room heater is not properly installed, a house fire may result.
To reduce the risk of fire, follow the installation instructions.
Failure to follow these instructions can result in property damage, bodily injury, or even death.
CONTACT LOCAL AUTHORITIES WITH JURISDICTION (BUILDING DEPARTMENT or FIRE
OFFICIALS), ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION
INSPECTION IN YOUR AREA.
Tula Model 8191
Manual: 6400-40464
R:2 03/8/2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tula and is the answer not in the manual?

Questions and answers

Summary of Contents for HearthStone Tula

  • Page 1 FOR FUTURE REFERENCE PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL AND USE YOUR NEW TULA WOOD STOVE. If this room heater is not properly installed, a house fire may result. To reduce the risk of fire, follow the installation instructions.
  • Page 2 CO Emissions: The Tula 8191 has the following CO emission rates by burn level: Category 1 - 0.46%, Category 2 - 0.44%, Category 3 - 0.62% and Category 4 - 0.59%. In general, the higher burn rate that can be safely maintained without over-firing the stove the cleaner the stove will operate.
  • Page 3 LASS REPLACEMENT PROCEDURES ....................22 ERMICULITE ANEL EMOVAL OR EPLACEMENT TROUBLESHOOTING ......................25 ........................... 26 ROUBLESHOOTING UIDE & O ....................27 EPLACEMENT ARTS PTIONAL CCESSORIES SAFETY LABEL ........................28 WARRANTY..........................29 Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 4 Tula the primary heat additional information. source for your home. The Tula’s large glass window allows you to enjoy the fire from a variety of Contact your dealer for any necessary warranty locations in the room.
  • Page 5 Quincy, MA 02269 www.nfpa.org Keep all combustible items such as furniture, If you are installing your Tula in a mobile or drapes, clothing, and other items, at least 36" manufactured home, follow the guidelines described (0.92 m) from the stove (See page 8) in the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 (United States).
  • Page 6 TEMPERATURE OF SUCH FIRES CAN CAUSE INSTANTANEOUS STEAM AND SERIOUS BODILY HARM. Once the chimney fire expires, leave the primary air control closed and let the fire in the stove die out Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 7 Mobile Home Lockdown Kit- 91-99910 test purposes, we are assuming 20 lbs. (9.1 kg) of seasoned hardwood per cubic foot of firebox volume). Maximum Log Length: 17” (43.2cm), vertically Figure 1 – Tula Dimensions Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 8 Under certain circumstances, however, damage may occur during National Fire Protection Agency transit and handling. When you receive the Tula, Batterymarch Park carefully unpack and inspect the stove and all Quincy, MA 02269 accompanying parts.
  • Page 9 See NFPA-211 81” – 206cm Min. Alcove ceiling from floor with single wall connector See NFPA-211 77” – 196cm Min. Alcove ceiling from floor with double wall connector See NFPA-211 Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 10 HIMNEY ONNECTOR YSTEMS AND LEARANCES Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 11 Hearthstone recommends the termination be at the ensure a safe stove installation. same level, or lower than the air intake on the stove.
  • Page 12 Only install this stove to a lined masonry draft. In such cases, a damper can help regulate the chimney or an approved high temperature draft. The Tula requires a draft between 0.06" and prefabricated residential type building heating 0.1" WC. For drafts above 0.1" WC, install a appliance chimney.
  • Page 13 Ensure the size of the prefabricated chimney’s flue Mortared brick or modular block at least 4" (102 is appropriate for the Tula. The Tula requires a 6" mm) thick – must use liner (152 mm) inside diameter flue for new installations.
  • Page 14 Figure 5 – Typical Chimney Configurations Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 15 Adjustable vented flashing – 0/12 – 6/12, Two 24” chimney pipes, 24” support box with built-in starter section and trim. * (any UL or ULC approved equipment is acceptable) Figure 8 Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 16 Operation Once your Tula is installed, you are ready to light a stove. To latch the door, push the door tightly fire. towards the firebox then continue to push the handle in and down until it latches shut. Gently pull on the Every installation, season’s firewood, and operator’s...
  • Page 17 HOOSING IREWOOD Burn only natural firewood (known as cordwood) in the Tula 8191 Wood Heater. This stove is not Medium designed to burn other fuels. Juniper, Rocky Mtn 3,150 21.8 CAUTION: CHEMICALS Elm, Red 3,112 21.6 FLAMMABLE FLUIDS TO START THE FIRE. DO Coffeetree, Kentucky 3.112...
  • Page 18 With use, the color of the arrange logs, it is advisable to open the door just a refractory panels will change and small fractures crack, pause for a moment then open the door Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 19 ANY SIGNS OF OVER-FIRING WILL VOID YOUR two to two and a half notches, or about half to two WARRANTY! Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 20 Coals within a bed of ashes can remain hot for several days once removed from the firebox. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 21 Alternatively, aim a powerful flashlight into area (your dealer may be a certified sweep!). the space around the door from the outside (then look in through the glass at the area Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 22 4. Remove any remaining glass and old gasket Figure 13 Latch Catch Detail material. 5. Clean the screw holes and place a small amount Caution: Do not drop catch into opening! of anti-seize compound in each one. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 23 5. To remove the side panels (PL/PR), rotate the ashes. forward edge in towards the center of the firebox 2. Remove the cast iron bottom of the firebox. until the rear edge clears the back panel. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 24 (P2). 7. Tilt back panel (PB) forward and down – remove from firebox. 10. To install new panels, or to reinstall the existing panels after cleaning, reverse the previous procedure. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 25 Figure 15 – Vermiculite Panel Detail Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 26 This phenomenon of air starvation within the Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 27 Do not over-fire the stove. Monitor stove temperatures. Use FINISH seasoned wood only. Excessive Draft Check the DRAFT. A damper may be required. Operate the stove at a LOW BURN range. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 28 ACCESSORY KIT: GLOVE AND LEVELING FEET 91-20900 VERMICULITE REFRACTORY PANEL SET 91-54900 ASH PAN AND COVER 91-58900 GLASS WITH GASKET ASSEMBLY 91-85910 DOOR ASSEMBLY OPTIONAL ACCESSORIES 91-53900 OUTSIDE AIR KIT 91-99910 MOBILE HOME ANCHOR KIT Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 29 Safety Label Hearthstone Quality Home Heating Products, Inc ® Tula Model 8191...
  • Page 30 ) year after the Purchase Date, Hearthstone will pay for warranty labor performed by an authorized Dealer at Hearthstone’s published labor rates in effect at the time the labor is performed only if the appliance is installed by an authorized dealer or their designated representative. Otherwise or thereafter, the Original Purchaser is responsible for the cost of labor.
  • Page 31 Hearthstone or an authorized Dealer, as the case may be. Notwithstanding any other provision of this document, in no event will Hearthstone pay for any Dealer fees or other fees for pick up or delivery of the appliance returned for repair; the Original Purchaser shall be responsible for any such fees.
  • Page 32 Dealer on behalf of Hearthstone, as the case may be, will instruct the Original Purchaser to either return the defective part, or the entire appliance (if requested), to the Dealer or Hearthstone or allow a Dealer to make a service call at the place where the appliance is located. Hearthstone may require that a digital picture be provided to support the claim.
