(Model 8190)
Woodstove
OWNER'S MANUAL
Installation And
Operating Instructions
SAVE THIS OWNER'S MANUAL
FOR FUTURE REFERENCE
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE YOUR
NEW TULA WOOD STOVE.
If this room heater is not properly installed, a house fire may result.
To reduce the risk of fire, follow the installation instructions.
Failure to follow these instructions can result in property damage, bodily injury, or even death.
CONTACT LOCAL AUTHORITIES WITH JURISDICTION (BUILDING DEPARTMENT or FIRE
OFFICIALS), ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION
INSPECTION IN YOUR AREA.
Tula Model 8190
Manual: 6400-40464
R: 3 - 7/28/2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HearthStone 8190
Summary of Contents for HearthStone 8190
-
Page 1: Operating Instructions
Failure to follow these instructions can result in property damage, bodily injury, or even death. CONTACT LOCAL AUTHORITIES WITH JURISDICTION (BUILDING DEPARTMENT or FIRE OFFICIALS), ABOUT PERMITS REQUIRED, RESTRICTIONS AND INSTALLATION INSPECTION IN YOUR AREA. Tula Model 8190 Manual: 6400-40464 R: 3 - 7/28/2011... - Page 2 Intentionally Blank Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
-
Page 3: Table Of Contents
.................................22 LASS : ........................22 LASS REPLACEMENT PROCEDURES ....................23 ERMICULITE ANEL EMOVAL OR EPLACEMENT TROUBLESHOOTING ......................27 ...........................28 ROUBLESHOOTING UIDE & O ....................29 EPLACEMENT ARTS PTIONAL CCESSORIES SAFETY LABEL ........................30 Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 4: Introduction
Install the stove in your central living area to allow heat to radiate naturally to distant rooms. Do not install your stove in a poorly insulated area. This is inefficient and would likely result in higher fuel usage. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 5: Codes
6. A ventilation system is installed in the house. Never use a wood grate or other device to elevate the fire. If these or other indications suggest that infiltration air is inadequate, additional combustion air should Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 6: Periodic Checklist
Inspect the stove, stovepipe, and chimney thoroughly for any sign of damage before firing the stove again. You must correct any damage before using your stove again. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 7: Specifications
As a constant for comparison and test purposes, we are assuming 20 lbs. (9.1 kg) of seasoned hardwood per cubic foot of firebox volume). Maximum Log Length: 17” (43.2cm), vertically Figure 1 – Tula Dimensions Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 8: Installation
Please refer to NFPA Code 211 for specifications complete details. obtain this Hearthstone packages your Tula stove with the information directly from the NFPA. greatest care so that it ships safely. Under certain circumstances, however, damage may occur during National Fire Protection Agency transit and handling. -
Page 9: Combustible Surface Required Clearances
See NFPA-211 Min. Alcove ceiling from floor with single wall connector 72” – 173cm See NFPA-211 Min. Alcove ceiling from floor with double wall connector 68” – 183cm See NFPA-211 Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 10: Chimney Connector Systems And Clearances
HIMNEY ONNECTOR YSTEMS AND LEARANCES Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 11: Outside Air Supply
Hearthstone recommends the termination be at the the clearances to combustibles discussed earlier to same level, or lower than the air intake on the stove. - Page 12 (21mm/m). interior chimney and may experience increased creosote accumulation. We do not recommend long runs of stovepipe to increase heat dispersal. Longer lengths stovepipe, more connecting elbows, than Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 13 6” Diameter or 8" has a required chimney height that provides too x 8" (203 mm x 203 mm) tile size for best results. An much draft. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 14 Figure 5 – Typical Chimney Configurations Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 15 2'-0" 2'-0" MINIMUM MINIMUM 3'-0" 3'-0" MINIMUM MINIMUM 10'-0" Figure 6 – Chimney Height Requirements Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
-
Page 16: Installing I N A Mobile Home
Install the stove in accordance with 24 CFR, Part 3280 (HUD) Permanently attach the stove to your mobile home’s floor. Use Hearthstone’s Kit #91-99900 - Mobile Home Lock Down Kit. Installation instructions are included with the kit. Figure 7 - Lock Down Kit Detail Install a Mobile Home Chimney &... -
Page 17: Operation
To latch the door, push the door tightly towards the firebox then continue to push the handle in and down until it latches shut. Gently pull on the door handle to make sure it is properly latched. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 18: Choosing Firewood
HOOSING IREWOOD Burn only natural firewood (known as cordwood) in the Tula 8190 Wood Heater. This stove is not Medium designed to burn other fuels. Juniper, Rocky Mtn 3,150 21.8 CAUTION: CHEMICALS Elm, Red 3,112 21.6 FLAMMABLE FLUIDS TO START THE FIRE. DO Coffeetree, Kentucky 3.112... -
Page 19: Buildinga Fire
With use, the color of the arrange logs, it is advisable to open the door just a refractory panels will change and small fractures crack, pause for a moment then open the door Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... - Page 20 ANY SIGNS OF OVER-FIRING WILL VOID YOUR two to two and a half notches, or about half to two WARRANTY! Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 21 Dump ashes from the ash pan directly into a metal from the firebox. container with a tight fitting lid. Do not place any Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
-
Page 22: Maintenance
Alternatively, aim a powerful flashlight into area (your dealer may be a certified sweep!). the space around the door from the outside (then look in through the glass at the area Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 23: Latch Adjustment Procedures
4. Remove any remaining glass and old gasket Figure 13 Latch Catch Detail material. 5. Clean the screw holes and place a small amount Caution: Do not drop catch into opening! of anti-seize compound in each one. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 24: Vermiculite Panel Removal Or Replacement
Work only on a cold stove. 1. Open firebox door. Remove any accumulated ashes. 2. Remove the cast iron bottom of the firebox. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... - Page 25 (P1) and move it forward until the rear edge facing you – remove from firebox. clears the rear shelf. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 26 9. Slide the rear edge of the panel down and rotate 10. To install new panels, or to reinstall the existing it forward out of the firebox. Repeat with the right panels after cleaning, reverse the previous section (P2). procedure. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
- Page 27 Figure 15 – Vermiculite Panel Detail Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190...
-
Page 28: Troubleshooting
This phenomenon of air starvation within the Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 29: Roubleshooting Uide
Do not over-fire the stove. Monitor stove temperatures. Use FINISH seasoned wood only. Excessive Draft Check the DRAFT. A damper may be required. Operate the stove at a LOW BURN range. Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
Page 30: Replacement Parts & Optional Accessories
ACCESSORY KIT: GLOVE AND LEVELING FEET 91-20900 VERMICULITE REFRACTORY PANEL SET 91-54900 ASH PAN AND COVER 91-58900 GLASS WITH GASKET ASSEMBLY 91-85900 DOOR ASSEMBLY OPTIONAL ACCESSORIES 91-53900 OUTSIDE AIR KIT 91-99900 MOBILE HOME ANCHOR KIT Hearthstone Quality Home Heating Products, Inc ® Tula Model 8190... -
