Type Key - Danfoss BOCK UL-HGX12e CO2 LT Operating Manual

2 | Product description
2.2 Name plate (example)
BOCK
Type
: UL-HGX12e/40 S 3 CO
1
No
: BC12345A001
2
3 10,7/6,2A
4 111A
LP/HP = 1450/1450 psig
5
Fig. 3
1 Type designation
2 Machine number
3 maximum operating current
4 Starting current (rotor blocked)
5 LP: max. admissible operating
pressure (g) Low pressure side
HP: max. admissible operating
pressure (g) High pressure side
Observe the limits of application
diagrams!
2.3 Type key (example)
UL - HG X 1 2 e
¹ ) HG - Hermetic Gas-Cooled (suction gas-cooled)
² ) X - Ester oil charge
)
³ ML - Deep freezing at low and medium evaporation temperatures
S - For frequency regulation and extended limits of application
© Danfoss | Climate Solutions | 2023.06
Bock GmbH, Benzstr. 7
72636 Frickenhausen, Germany
LT
2
64A
100/100 bar
IP66
6
7
8
9
10 Nominal rotation speed
11 Displacement
12 Oil type filled at the factory
13 Terminal box protection type
/
40 S 3
thermally protected system
27,3 6,0
123 cfh
32,8 7,2
Oil: BOCK lub E85 C 85E SE 55
Öl: BOCKlub E85
Voltage, circuit, frequency
Nominal rotation speed
Displacement
Voltage, circuit, frequency
Electrical accessories can change
the IP protection class!
CO LT
2
Low Temperature
CO version
2
HP code for motor size
Compressor version
Swept volume
e-series
Number of cylinders
Size
Oil charge ²
Series ¹ )
Identification
UL compressor
