  • Page 1 C O L U M N D R I L L I N G M A C H I N E S HU 32-4 TOPLINE...
  • Page 2 Fig. A - Main parts Fig. 1 Fig. 3 Fig. 2 CHANGES AND T YPING ERRORS RESER VED CHANGES AND T YPING ERRORS RESER VED...
  • Page 3 Fig. 4 Fig. 5 Fig. 7 Fig. 6 Fig. 8 Fig. 9 CHANGES AND T YPING ERRORS RESER VED...
  • Page 4 Fig. 10 Fig. 11 Fig. 12 Fig. 13 Fig. 15 Fig. 14 CHANGES AND T YPING ERRORS RESER VED CHANGES AND T YPING ERRORS RESER VED...
  • Page 5 Fig. 15A Fig. 15B Fig. 16 Fig. 18 Fig. 17 CHANGES AND T YPING ERRORS RESER VED...
  • Page 6 Fig. 19 CHANGES AND T YPING ERRORS RESER VED CHANGES AND T YPING ERRORS RESER VED...

  • Page 7: Table Of Contents

    able of conTenTs General safety rules for all machines Additional safety rules Instructions for using this machine Unpacking Assembly Adjustment 5.1 Table adjustment 5.2 Feed depth adjustment 5.3. Speed adjustment 5.4 Belt tension adjustment 5.5 Quill spring adjustment Usage 6.1 Installing drills 6.2 Positioning the work piece 6.3 Using the vice Troubleshooting...

  • Page 8: General Safety Rules For All Machines

    hu 32-4 T olumn drilling machines opline 1. g eneral safeTy rules for all machines N.B.: Read the instructions carefully in order to avoid any problems. As with all machinery there are certain hazards involved with operation and use of this machine. Using the machine with respect and caution will considerably lessen the possibility op personal injury.

  • Page 9: Additional Safety Rules

    ddiTional safeTy rules Always keep in mind that: • the machine must be switched off and disconnected from the power supply during maintenance and repairs, • clamped workpieces may only be measured when the machine is switched off. Never lean over the machine, mind loose clothing, ties, jewellery etc. and wear a cap. Do not remove safety devices or guards.

  • Page 10: Assembly

    4. a ssembly • Place the column on the base and align the holes in the column support with the holes in the base (fig. 1). • Secure the column with the bolts and washers. • Take off the collar and the rack. (fig. 2) •...

  • Page 11: Belt Tension Adjustment

    5.4 b elT Tension adjusTmenT For proper belt tension: Use a light pressure on the V-belt. You should be able to push the belt in by about 10 mm. 5.5 Q uill spring adjusTmenT Figure 16 • Pull the knob towards you and move it to the next or previous notch. •...

  • Page 12: Maintenance

    Check with a qualified electrician if the grounding instructions are not completely understood, or in doubt as to whether the tool is properly grounded. • Repair or replace damaged or worn cords immediately. 9.2 p roducT specificaTions Model HU 32-4 Topline Motor power 1,1 kW Drilling capacity 30 mm Drilling depth 110 mm...

  • Page 13: Parts List

    10. p arTs lisT 15-1 50 51 25-1 25-2 25-3 20 21 22 23 88-2 25 26 27 25-4 88-1 111 112 90-1 90-3 94(A) 94(B) Fig. 20 - Explosion drawing CHANGES AND T YPING ERRORS RESER VED...
  • Page 14 Description Q’ty Description Q’ty Spindle pulley Motor Pulley guard Quill Idle pulley shaft Bearing Screw Bearing Ball bearing V-belt Bearing Idle pulley Gasket, quill "C"snap ring Rack collar V-belt Screw "C"snap ring Column Motor pulley Rack Set screw Clamp bolt Switch pin Scale Electric cord...
  • Page 15 CHANGES AND T YPING ERRORS RESER VED...
  • Page 16 All rights reserved. No part of this booklet may be reproduced in any form, by print, photoprint, microfilm or any other means without written permission from the publisher. © Huberts bv, Kennedylaan 14, Veghel, the Netherlands. Internet: www.huvema.nl CHANGES AND T YPING ERRORS RESER VED CHANGES AND T YPING ERRORS RESER VED...
  • Page 17 (in accordance with supplement II, section 1A of the Machinery Directive) Industrie & Handelsonderneming Huberts bv, Kennedylaan 14, 5466 AA Veghel, the Netherlands, in the capacity of importer, is to be held responsible for declaring that the Huvema machines: Column drilling machines HU 32-4 Topline...
  • Page 18 CHANGES AND T YPING ERRORS RESER VED CHANGES AND T YPING ERRORS RESER VED...
  • Page 19 CHANGES AND T YPING ERRORS RESER VED...
