2

Case overview

Operating switch
The following modes of operation
can be selected:
- Manual
for commissioning
and testing for function
- Automatic
for automatic operation
- Off
for switching off
the outputs
ƒ
Manual
ƒ
Automatic
ƒ
Off
Fuses
(see chapter 15)
Replacement fuses
(see chapter 15)
Power connection
6
Outputs
Inputs
EN
Display
Display for controller operation
and system settings
Operating buttons
Arrow up
for scrolling up through the menus
SET button
confirmation or activation of a value
ESC button
escape key
Arrow down
for scrolling down through the menus
Strain relief
RS232 and RS485 interface,
alarm output,
Direct Sensor output
730.137 | 08.37
SD card
