Introducing the FireWire 800 M-64
The FireWire 800 M-64 is designed to support both PC and MAC
computers. It provides 3 independent hot-pluggable Firewire 800
(1394b) ports with data transfer rates up to 800Mbps.
Features and Benefits
• Provides 3 FireWire 800 (1394b) ports for multiple 1394b and
1394a (a 9-6 or 9-4 FireWire cable required) device connections
• Supports IEEE 1394b and backwards compatible with 1394a-
2000 and 1394-1995 standards
• Supports data transfer rates of 100, 200, 400, and 800Mbps
• Built-in 4-pin power connector provides extra power when
connected to the system's power supply (Recommended)
• Supports hot-swapping and Plug-n-Play connection of
peripheral devices
• Works with various types of FireWire 800 (1394b) and 1394a
devices including portable hard disk, DV camcorder, digital
camera, CD-RW/DVD-ROM drive and other audio/video
devices
System Requirements
PC:
• Pentium or equivalent PC with an available 64-bit or 32-bit
PCI slot
• Windows 98SE/ME/2000/XP
MAC:
• Power Mac G3 Blue & White or later with an available 64-bit
or 32-bit PCI slot
• Mac OS 8.6-9.x, Mac OS 10.1.x-10.2.3: Up to 400 Mbps
• Mac OS 10.2.4 or later: Up to 800 Mbps
* Note: When installed in a 32-bit PCI slot, a portion of the
edge connector will not be connected to the PCI slot.
04-0311A
FireWire 800 M-64
Quick Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG FireWire 800 M-64
Summary of Contents for SIIG FireWire 800 M-64
- Page 1 FireWire 800 M-64 Quick Installation Guide Introducing the FireWire 800 M-64 The FireWire 800 M-64 is designed to support both PC and MAC computers. It provides 3 independent hot-pluggable Firewire 800 (1394b) ports with data transfer rates up to 800Mbps.
- Page 2 Package Contents • (1) FireWire 800 M-64 host adapter • (1) 1394b 9-pin to 9-pin cable • (1) 1394b 9-pin to 6-pin adapter • (1) Driver software • This quick installation guide Board Layout 4-Pin Power Connector Firewire 800 Ports Figure 1.
- Page 3 For Windows 2000 Windows 2000 automatically installs it's built-in 1394a driver for the Firewire 800 M-64. To get the full potential out of the FireWire 800 M- 64, install the Firewire 800 driver using the directions below. 1. Right click My Computer, click Manage, then click Device...
- Page 4 For Windows XP Windows XP automatically installs it's built-in 1394a driver for the Firewire 800 M-64. To get the full potential out of the FireWire 800 M- 64, install the Firewire 800 driver using the directions below. 1. Right click My Computer, click Manage, then click Device Manager.
- Page 5 - OHCI IEEE 1394b Host Controller should be displayed. Mac OS Driver Installation To ensure proper operation of the FireWire 800 M-64 in your Mac, some Mac OS requires the most current Firewire software from Apple. Apple's website contains all the information needed to download and install Firewire software update.
- Page 6 RMA number posted on the outside of the shipping carton. Step 3: Ship the Product You are responsible for the cost of shipping back to SIIG at the following address: SIIG, Inc.
- Page 7 Fremont, CA 94538-3152 FireWire 800 M-64 is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in publication are for identification only and may be trademarks of their respective companies.
- Page 8 Empty Page...
