PRODUCT DESCRIPTION

2.1 WASHING MACHINE PARTS
FRONT VIEW
INSIDE VIEW : SWT7055TMWA
SWT6055TMWA
SWT6555TMWA
1
2
3
4
PARTS LIST
1
Control Panel
2
Lid
3
Cabinet
4
Levelling
Adjustable Front Feet
5
Water Inlet Hose
- RED fittings
(Hot Water)
- BLUE fittings
(Cold Water)
6
Mains Cable
7
Outlet Hose/
Drain Hose (See
installation instructions
sheet to fit & position
drain hose)
8
Back Feet (fixed)
9
Wash Bowl
10
Bleach Dispenser
11
Fabric Softener
Dispenser
12
Lint Filter
14
13 Agitator
15
BACK VIEW
INSIDE VIEW : SWT7055LMWA
Low profile agitator
Softener Drawer
5
5
6
7
8
16
15
14
16
Magnet
