2.
PRODUCT DESCRIPTION
2.1 Parts
1
7
8
9
2.2 Accessories
2
3
4
5
6
10
11
12
1
2
3
1
Detergent/Softener Dispenser
2
Worktop
3
Control Panel
4
Door
5
Emergency
Door Opening
6
Front Feet
(Level Adjustment)
7
Water Drain Hose
8
Water Inlet Hose
9
Rear Feet
(Level Adjustment)
10
Mains Cable
11
Transit Bolts
12
Transit Bolts, Hose Support
CAUTION !
All transit bolts (3 pcs) must
be removed before using the
appliance.
1
Plastic Caps
To close the holes on the rear side of
the cabinet after the removal of the
transit bolts.
2
Plastic Hose Guide
To connect the drain hose on the edge
of a sink.
3
Spaner
To remove the transit bolts.
To adjust levelling legs.
7
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the SWF8025DQWA and is the answer not in the manual?
Questions and answers
Where is the lint filter??
Ezi Set inverter SWF8025DQWA Softener not getting to clothes The filler compartment is clean and water inlet and pressure is ok
The Simpson Ezi Set Inverter SWF8025DQWA softener may not be reaching the clothes due to the following reasons:
1. Blocked Dispenser – The detergent/softener dispenser may be clogged, preventing the softener from dispensing properly.
2. Incorrect Use – Ensure the softener is placed in the correct compartment of the dispenser.
3. Water Flow Issues – Low water pressure or a blocked inlet hose may prevent proper dispensing.
4. Overloading – Overloading the machine can obstruct the softener from evenly reaching clothes.
5. Incorrect Wash Program – Some programs may not use softener; verify the selected program allows softener use.
6. Faulty Dispenser Mechanism – If the dispenser drawer is damaged or not operating correctly, the softener may not be released.
Check and clean the dispenser, ensure proper loading, and verify the selected program to resolve the issue.
This answer is automatically generated
Temp & Spin together is not functioning. E40 appears. Need the Temp to appear on the touchpad. Help Help
The Temp & Spin function may not be working because the child lock is activated. When this function is enabled, pressing any touchpad will cause the lock symbol to flash on the display along with a buzzer sound. To deactivate the child lock and restore functionality, press the “Temp” and “Spin” touchpads at the same time until the unlock symbol appears on the display with a sound. This function remains enabled even after the appliance is switched off, so it must be manually deactivated.
This answer is automatically generated
How to remove door seal for cleaning
