- Page 1 5.5 Kg Front Load Washer Instruction Booklet SWF85562...
-
Page 2: Table Of Contents
Contents / Customer Care And Service CONTENTS SAFETY INFORMATION ....................3 PRODUCT DESCRIPTION ................... 5 CONTROL PANEL ...................... 6 BEFORE FIRST USE ....................10 DAILY USE ........................ 11 WASHING HINTS ...................... 16 INTERNATIONAL WASH CODE SYMBOLS ............... 19 CARE AND CLEANING ..................... -
Page 3: Safety Information
Safety Information SAFETY INFORMATION Conditions of use Wash small items such as socks, laces, washable belts etc in a washing This appliance is intended to be used in bag or pillow case as it is possible for household and similar applications such items to slip down between the such as: tub and the inner drum. -
Page 4: Child Safety
Safety Information After having installed the appliance, Never use the washing machine if the check that it is not standing on the power supply cable, the control panel, inlet and drain hose and the worktop the working surface or the base are is not pressing the electrical supply damaged so that the inside of the cable. -
Page 5: Product Description
Product Description PRODUCT DESCRIPTION Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. The program selector dial combines the function of program and temperature selection, making it easier to set the program. The automatic cooling of the washing water from 90°... -
Page 6: Control Panel
Product Description / Control Panel Accessories Spanner Plastic caps To close the holes on the rear side To remove the transit bolts. of the cabinet after the removal of To adjust levelling legs. the transit bolts. Plastic hose guide To connect the drain hose on the edge of a sink. -
Page 7: Options Button
Control Panel 3.1 Program Selector Knob 3.3 Options Button Turn this knob to set program/ Press the ‘Options’ button temperature, the machine will repeatedly, to select the desired automatically select the spin speed option. The relevant light will light up. for selected program. - Page 8 Control Panel 3.7 Working Status You must select this option after you have set the program and After pressing the Start/Pause before you press the Start/Pause button, the “Washing” pilot light button. comes on. If you wish to add laundry in the When the pilot light “Washing”...
- Page 9 Control Panel 3.8 Programs + Options Program; Type of load; Cycle Options can be Temperature Max. weight of load description combined Cottons; White cotton (heavy Main wash Spin Reduction, No Spin, 90 °C soiled cotton items):e.g. at 90° C Rinse Hold, sheets,tablecloths, Rinses Pre Wash, Eco,...
-
Page 10: Before First Use
Control Panel/Before First Use Program; Type of load; Cycle Options can be Temperature Max. weight of load description combined Hand Wash; Special program for hand Main wash Spin Reduction, No Spin, 30 °C washing fabrics; at 30° C Rinse Hold, maximum load 1 kg. -
Page 11: Daily Use
Daily Use DAILY USE Connect the mains plug to the mains socket. Turn the water tap on. 5.1 Four Steps Start Up Guide Step 1 - Setting A Program For Washing Turn the program selector dial to the If you want to delay the start of the required program. - Page 12 Daily Use Step 2 - Loading The Laundry Check and remove objects (if there are any) that could be Before loading the laundry, trapped in the fold. please make sure: Place the laundry in the drum, one item at a time, shaking them Empty pockets.
- Page 13 Daily Use Step 3 - Using Detergent And Additives Position down : Position down : Detergent Dispenser Drawer for liquid for liquid detergent. detergent. Position up : Position up : for powder for powder detergent detergent (factory setting). (factory setting). The detergent dispenser is divided into three compartments.
-
Page 14: Changing A Program
Daily Use If you wish to carry out the “Prewash” phase, pour it into the compartment marked If required, pour fabric softener into the compartment marked (the amount used must not exceed the “MAX” mark in the drawer). Close the drawer gently. Step 4 - Starting a program To start a program, press the Attention! -
Page 15: Stand By Mode
Daily Use If the door lock indicator does not The ‘Door Lock’ indicator is on. disappear, this means that the The door stays locked. machine is already heating and the You must drain the water to open water level is above the bottom the door. -
Page 16: Washing Hints
Washing Hints WASHING HINTS 6.1 Sorting The Laundry Remove persistent stains before washing. Follow the wash code symbols on Rub particularly soiled areas with a each garment label and the special detergent or detergent paste. manufacturer’s washing instructions. Treat curtains with special care. Sort the laundry as follows: whites, Remove hooks or tie them up in a coloureds, synthetics, delicates,... -
Page 17: Detergents And Additives
Washing Hints 6.6 Detergents and Additives Rust: oxalic acid dissolved in hot water or a rust removing product Good washing results also depend used in cold water. Be careful with on the choice of detergent and use rust stains which are not recent of the correct quantities to avoid since the cellulose structure will waste and protect the... - Page 18 Washing Hints Any fabric softener or starching Use less detergent if: additives must be poured into the you are washing a small load, compartment marked ‘ ’ before the laundry is lightly soiled, starting the wash program. large amounts of foam form Follow the product manufacturer’s during washing.
-
Page 19: International Wash Code Symbols
International Wash Code Symbols INTERNATIONAL WASH CODE SYMBOLS These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash Hand wash DO NOT temperature temperature temperature... -
Page 20: Care And Cleaning
Care And Cleaning CARE AND CLEANING To run a maintenance wash: WARNING! You must DISCONNECT the The drum should be empty of appliance from the electricity laundry. supply, before you can carry out Select the hottest ‘Cottons 90 °C’ any cleaning or maintenance wash program. -
Page 21: Cleaning The Drawer Recess
Care And Cleaning To aid cleaning, the top part of the additive compartment should be removed. 8.6 Cleaning The Drawer Recess WARNING! Disconnect the mains plug Having removed the drawer, use a from the mains socket. small brush to clean the recess, ensuring that all washing powder To clean the drain filter: residue is removed from the upper... - Page 22 Care And Cleaning 2. Open the filter cover by pressing Hold filter securly and pull the special hook and by rotating upwards to remove it from its the cover upwards. position. Clean the filter under the water tap. Remove eliminate the eventual fluff or small objects (if there are any) around the filter.
-
Page 23: Cleaning The Water Inlet Filter
Care And Cleaning IMPORTANT! Close the filter cover. The filter is inserted correctly when the indicator on this top is visible and you will hear “Click” sound. Insert the mains plug again. WARNING! Do not start washing clothes without the filter in its place. - Page 24 Care And Cleaning 8.9 The Dangers Of Freezing If the machine is exposed to 4. Put the ends of the drain and temperatures below 0°C, certain inlet hose in a container. Let the precautions should be taken. water flow out of the hoses. 5.
-
Page 25: Troubleshooting
Troubleshooting TROUBLESHOOTING Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During machine operation it is possible that the red Start/Pause pilot light flashes to indicate that the machine is not working. - Page 26 Troubleshooting Malfunction Possible cause Solution Too much detergent or Reduce the detergent unsuitable detergent (creates too quantity or use another one. much foam) has been used. Check whether there are any leaks Check the water inlet hose There is water from one of the inlet hose fittings.
- Page 27 Troubleshooting Malfunction Possible cause Solution The electronic unbalance Pause the machine and detection device has cut in redistribute laundry manually. because the laundry is not evenly distributed in the drum. The laundry is redistributed by reverse rotation of the drum. Spinning starts late or the This may happen several times...
-
Page 28: Technical Data
Technical Data TECHNICAL DATA Width 60 cm Dimensions Height 85 cm Depth 56 cm Power supply (voltage/frequency) 220-240 V/50 Hz Total power absorbed 2000 W Minimum fuse protection 10 A Maximum 0.8 MPa Water supply pressure Minimum 0.05 MPa Programs Max. -
Page 29: Installation
Installation INSTALLATION 11.1 Unpacking CAUTION! All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. Put one of the polystyrene packaging elements on the floor Use gloves. - Page 30 Installation 11.2 Positioning It is important that your washing machine stands firm and level on the floor to ensure correct operation. That the appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the washing machine door is restricted.
-
Page 31: Water Inlet
Installation When the washing machine is levelled, try to rock it from corner to corner. If it does rock, adjust the legs again until it is levelled and does not rock. The inlet hose must not be lengthened. If it is too short and you do not wish to move the tap, you will have to purchase a new, longer hose specially designed for... -
Page 32: Electrical Connection
Installation The end of the drain hose must Should the appliance power always be ventilated, i.e. the supply cable need to be replaced, inside diameter of the drain pipe this should be carried out by our must be larger than the outside Service Centre. -
Page 33: Environment Concerns
Environment Concerns ENVIRONMENT CONCERNS 12.1 Packaging Materials For more detailed information about recycling of this product, The materials marked with please contact your local city the symbol office, your household waste recyclable. disposal service or the shop >PE<=polyethylene where you purchased the >PS<=polystyrene product. - Page 34 NOTE...
- Page 36 www.simpson.com.au...
