40
Vision 1624R, 2525 and 2550 Series 5 Installation Guide
2.5.6
UNIST Misting System
The optional UNIST Misting System is designed to provide lubrication to the cutting tool and material
when processing metals. The diagram shown below lists the main components and connections. This
system requires a compressed air supply (60 PSI Max) to be connected to the inlet air line.
Documentation for usage of the UNIST Misting System is included with the system. Please refer to this
documentation for operation details.
© 2020 Vision Engraving & Routing Systems
