32
Vision 1624R, 2525 and 2550 Series 5 Installation Guide
3. Locate the High Speed Engraving Spindle on the Rail Plate with the Dowel Pins inserted into the
Dowel Pin Holes.
4. Install and tighten the 4 Mounting Screws.
5. Connect the Proximity Sensor Plug into the Proximity Sensor Port on the rear of the router Carriage.
© 2020 Vision Engraving & Routing Systems
