30
Vision 1624R, 2525 and 2550 Series 5 Installation Guide
Installing Cutting Tools
The NSK Spindle can accept either 1/8" or 1/4" cutting tools., depending on which collet was shipped
with the system. The spindle will accept standard 2" shank bottom loading cutting tools. The collar at the
bottom of spindle and the spindle shaft both have flat areas (tool slots) to allow the user to loosen or
tighten the collet. Special thin wrenches are shipped with the NSK Spindle for this purpose.
© 2020 Vision Engraving & Routing Systems
