- Page 1 M-LBAS-IA1.*E, F*-LBAS-IA1 Ethernet-APL Surge Protector Manual...
- Page 2 Phone: +49 621 776 - 0 E-mail: info@de.pepperl-fuchs.com North American Headquarters Pepperl+Fuchs Inc. 1600 Enterprise Parkway Twinsburg, Ohio 44087 Phone: +1 330 425-3555 E-mail: sales@us.pepperl-fuchs.com Asia Headquarters Pepperl+Fuchs Pte. Ltd. P+F Building 18 Ayer Rajah Crescent Singapore 139942 Phone: +65 6779-9091 E-mail: sales@sg.pepperl-fuchs.com https://www.pepperl-fuchs.com...
-
Page 3: Table Of Contents
M-LBAS-IA1.*E, F*-LBAS-IA1 Contents Introduction........................ 4 Content of this Document ................4 Target Group, Personnel ................4 Symbols Used ....................5 Product Specifications....................6 Overview and Application................6 Use in PROFIBUS PA Applications............... 9 Dimensions and Component Overviews ........... 10 2.3.1 F*-LBAS-IA1 ........................ -
Page 4: Introduction
M-LBAS-IA1.*E, F*-LBAS-IA1 Introduction Introduction Content of this Document This document contains information that you need in order to use your product throughout the applicable stages of the product life cycle. These can include the following: • Product identification • Delivery, transport, and storage •... -
Page 5: Symbols Used
M-LBAS-IA1.*E, F*-LBAS-IA1 Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid prop- erty damage. -
Page 6: Product Specifications
M-LBAS-IA1.*E, F*-LBAS-IA1 Product Specifications Product Specifications Overview and Application The Ethernet-APL Surge Protectors are designed to protect Ethernet-APL spur ports of Ether- net-APL rail field switches and field devices against voltage surges and indirect lightning. The design ensures Ethernet-APL network performance at 10 Mbit/s due to the compatibility of the device to the Ethernet-APL Port Profile Specification. - Page 7 M-LBAS-IA1.*E, F*-LBAS-IA1 Product Specifications M-LBAS-IA1.IE protected side unprotected side Earth Figure 2.1 Circuit diagram M-LBAS-IA1.IE APL+ (screw terminal 3+4) APL- (screw terminal 2+5) Shielding (screw terminal 1) M-LBAS-IA1.DE protected side unprotected side Earth Figure 2.2 Circuit diagram M-LBAS-IA1.DE APL+ APL- Shield...
- Page 8 M-LBAS-IA1.*E, F*-LBAS-IA1 Product Specifications F*-LBAS-IA1 + (RD) - (BK) Earth (GNYE) Figure 2.3 Circuit diagram F*-LBAS-IA1 + (RD) Red wire, APL+ - (BK) Black wire, APL- Earth (GN/YE) Green/yellow wire, earth Cable Shield Grounding Concepts The surge protectors for cabinet installation support the two cable shield grounding concepts specified by Ethernet-APL (see also "Engineering Guideline Ethernet-APL").
-
Page 9: Use In Profibus Pa Applications
Use in PROFIBUS PA Applications Optionally, PROFIBUS PA devices are connectable to the spur ports of the Ethernet-APL rail field switch from Pepperl+Fuchs instead of Ethernet-APL field devices. Surge protectors for Ethernet-APL and PROFIBUS PA are technically different. Only a surge protector for Ethernet- APL can adequately protect an Ethernet-APL port and support its higher communication data rate. -
Page 10: Dimensions And Component Overviews
M-LBAS-IA1.*E, F*-LBAS-IA1 Product Specifications Dimensions and Component Overviews 2.3.1 F*-LBAS-IA1 Figure 2.6 Cable cross sec- Position Description Color tion Cable length APL+ 100 mm 0.8 mm APL- Black 100 mm 0.8 mm Earth Green/yellow 100 mm 1.3 mm FS-LBAS-IA1: M20 x 1.5 thread FN-LBAS-IA1: 1/2"NPT thread 2.3.2 M-LBAS-IA1.*E... - Page 11 M-LBAS-IA1.*E, F*-LBAS-IA1 Product Specifications Assembly Front view Protected side shield APL - APL + Unprotected side APL + APL - shield Figure 2.8...
-
Page 12: Installation
M-LBAS-IA1.*E, F*-LBAS-IA1 Installation Installation Installation Requirements Prior to mounting, installation, and commissioning of the device you should make yourself familiar with the device and carefully read the instruction manual. Mounting Mounting M-LBAS-IA.* Figure 3.1 Note Only use a 35 mm x 7.5 mm DIN mounting rail. Position the rail field switch on the DIN mounting rail. -
Page 13: Connection
M-LBAS-IA1.*E, F*-LBAS-IA1 Installation Mounting F*-LBAS-IA1 The surge protectors may be installed into a thread hole of a housing of the field device or an appropriate enclosure. Note To prevent the device from coming loose in the thread and to ensure the degree of protection., observe the following requirements: •... - Page 14 M-LBAS-IA1.*E, F*-LBAS-IA1 Installation Connecting the Cable via the Screw Terminals Figure 3.2 Device with screw terminals Slot-head screwdriver Cable wire Plug the protected cable wires APL+, APL– and shield of the cable connection to the switch port into the terminals on the device (top side “P”). Note Tightening Torque Observe the tightening torque of the terminal screws.
-
Page 15: Conection F*-Lbas-Ia1
M-LBAS-IA1.*E, F*-LBAS-IA1 Installation Observe that the unprotected cabling does not affect the protected cabling. When laying the cables, ensure that the distance between the unprotected cabling connected to earth and the protected cabling is sufficient. Example of a Correct Ground Connection Figure 3.3 Unprotected side Protected side... - Page 16 M-LBAS-IA1.*E, F*-LBAS-IA1 Installation Connecting the Cable to Screw Terminals of a Field Device or Junction Box Housing Transmitter Figure 3.4 Plug the wires +, –, and PE of the cable to the terminals of the field device or junction box housing.
-
Page 17: Operation
M-LBAS-IA1.*E, F*-LBAS-IA1 Operation Operation Danger! Explosion hazard from live wiring of non-intrinsically safe circuits If you connect or disconnect energized non-intrinsically safe circuits in a potentially explosive atmosphere, sparks can ignite the surrounding atmosphere. Only connect or disconnect energized non-intrinsically safe circuits in the absence of a poten- tially explosive atmosphere. -
Page 18: Dismounting, Maintenance, And Repair
• The device must not be repaired, changed or manipulated. • If there is a defect, always replace the device with an original device from Pepperl+Fuchs. Caution! Property damage from use of inappropriate tool Using an inappropriate tool may damage the housing. -
Page 19: Disconnection F*-Lbas-Ia1
M-LBAS-IA1.*E, F*-LBAS-IA1 Dismounting, Maintenance, and Repair Loosen the screw of the terminal with the slot-head screwdriver (B). Pull the individual wires out of the terminal. Dismounting the Surge Protector with DIN Rail Mounting Figure 5.2 Device Slot-head screwdriver Mounting bracket DIN mounting rail Insert the screwdriver (2) into the groove of the mounting bracket (3). - Page 20 Pepperl+Fuchs Quality Download our latest policy here: www.pepperl-fuchs.com/quality www.pepperl-fuchs.com © Pepperl+Fuchs · Subject to modifications / DOCT-8244A...
