- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Raindance S 27636xx0 27658xx1...
-
Page 2: Technical Information
English Technical Information Recommended water pressure 15 - 75 PSI Max. water pressure 145 PSI Recommended hot water temp. 120° - 140° F* Max. hot water temp 176°F* Max. flow rate of handshower 2.5 GPM *Please know and follow all applicable local plumbing codes when setting the temperature on the water heater. Installation Considerations • For best results, Hansgrohe recommends that this unit be installed by a licensed, professional plumber. • Please read over these instructions thoroughly be- fore beginning installation. Make sure that you have all tools and supplies needed to complete the installation. 27636xx0 • To prevent scald injury, the maximum output tem- perature of the shower valve must be no higher than 120°F. In Massachusetts, the maximum out- put temperature can be no higher than 112° F. • The screws and anchors included with this set are suitable for use in a tile or other solid surface wall. They are not suitable for use in an acrylic or fiberglass shower enclosure. Please contact the manufacturer of the enclosure regarding recommended mounting locations, reinforcement requirements, and mounting hardware. •... -
Page 3: Datos Tecnicos
Français Español Données techniques Datos tecnicos Pression d’eau recommandée 15 - 75 PSI Presión recomendada en servicio 15 - 75 PSI Pression d’eau maximum 145 PSI Presión en servicio max. 145 PSI Température recommandée 120° - 140° F* Temperatura recomendada del 120� - 140� F* d'eau chaude agua caliente Température maximum d'eau chaude 176°F* Temperatura del agua caliente max. 176�F* Capacité nominale- douchette 2.5 GPM Caudal máximo - teleducha 2.5 GPM * Vous devez connaître et respecter tous les codes de plom- *Debe conocer y cumplir todos los códigos locales apli- berie locaux applicables pour le réglage de la température cables para ajustar la temperatura del calentador de agua. du chauffe-eau. À prendre en considération pour Consideraciones para la l’installation instalación •... -
Page 4: Installation
English Installation Do not drill through the wallbar. Damage to the bar may result. Install the wall fixation pieces. Mark the positions of the screw holes. - Page 5 Français Español Installation Instalación de Unica’S Ne percez pas dans la barre ¡No perfore el soporte de pared! murale! Installez les fixations murales. Instale los soportes. Marquez les positions des trous de vissage. Marque las posiciones de los orificios para tornillos.
- Page 6 English Drill the holes using a ¼" bit. ¼" Install the anchors. Seal the wall around the anchors using waterproof sealant. Failure to seal the wall may lead to water damage. Install the offset adapters and the screws.
- Page 7 Français Español Percez les trous à l’aide d’une mèche de ¼". Perfore los orificios con una broca de ¼". Installez les chevilles. Instale los pernos de anclaje. Scellez le mur autour des chevilles Selle la pared alrededor de los à l’aide d’un agent d’étanchéité. pernos de anclaje con un sellador impermeable. Si le mur n’est pas scellé, l’eau pourrait éventuellement causer Si no se sella la pared, pueden des dommages.
- Page 8 English If the tile does not go all the way up the wall, install optional tile matching disk 98993000 behind the top 98993000 of the wallbar. If the bar does not hang straight, adjust the offset adapters. Install the screw covers.
- Page 9 Français Español Si c’est nécessaire, installez la barre avec cale de Si es necesario, instale el disco de compensación compensation 98993000 (pas inclus). 98993000 (no incluidos). Si c’est nécessaire, ajustez les adaptateurs. Si es necesario, ajusta los adaptadores de desviación. Installez les caches-vis. Instale las tapas de los tornillos.
- Page 10 English Place the screen washer in one end of the hose (not included with 27636xx0). Connect this end of the hose to the handshower (not included with 27636xx0). Connect the other end of the hose to the wall outlet (not included).
- Page 11 Français Español Placez une rondelle en caoutchouc noir dans l’une Coloque una arandela de goma negra en un ex- des extrémités du tuyau de douchette (pas inclus tremo de la manguera de la teleducha (no incluidos avec 27636xx0). con 27636xx0). Vissez le tuyau à la coude d’alimentation (pas inclus). Enrosque la manguera al codo abastecador (no incluidos). Placez la filtre dans l’autre extrémité du tuyau. Coloque el filtro en el otro extremo de la manguera. Vissez cette extrémité du tuyau à la douchette (pas inclus avec 27636xx0). Enrosque este extremo de la manguera a la teleducha (no incluidos con 27636xx0). Apoye la Déposez la douchette dans son support. teleducha en el soporte.
- Page 12 User Instructions / Instructions de service / Manejo 2 mm 4 mm 2 mm 4 mm...
- Page 13 Raindance S 120 AIR 3-Jet 28415xx1 ...
- Page 14 Cleaning / Nettoyage / Limpiar QUICK CLEAN Remove scale deposits from the spray face by soak- ing it in a commercial scale remover such as Lime- Away or CLR. Follow the instructions on the product label. Si la face des jets s’entartre, faites-la tremper dans un détartrant commercial, tel que Lime-Away ou CLR. Suivez les instructions figurant sur l’étiquette du produit. Elimine los depósitos calcificados de la superficie de rociado remojándola en un desincrustante comercial como Lime-Away o CLR. Siga las instrucciones de la etiqu- eta del producto.
- Page 15 Rinse the handshower with clear water. Rincez la douchette à l’eau claire. Enjuague la ducha de mano con agua limpia. Install the handshower and flush it for at least one minute. Installez la douchette et faites-la fonctionner pendant au moins une minute. Instale la ducha de mano y lávela durante un minuto como mínimo.
- Page 16 Replacement Parts / Pièces détachées / Repuestos 98518xx0 28694000 98993000 98519xx0 optional en option opcional 98520xx0 94246000 28276xx3 28415xx1 96179000 98518xx0 98519xx0 xx = Colors / Couleurs / Acabados 00 = Chrome 82 = Brushed Nickel...
- Page 17 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen mixers and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to consider certain criteria when cleaning. At the cleaning of the fittings and showers, in principle, it must be pointed out: • Only use cleaning material which is explicitly intended for this type of application. • Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorine pale lye or acetic acid, as they cause considerable damage. • Phosphorus acidic cleaners are only conditionally applicable. • Do not mix cleaning agents, unless directed by the manufacturer. • Never use cleaning materials or appliances with an abrasive effect, such as unsuitable cleaning powders, sponge pads or microfiber cloths. • Always follow the instructions on the cleaning agent package with respect to specified cleaner dosage and contact time. • The building up of calcifications has to be removed by cleaning regularly. • When using spray cleaners, spray first onto a soft cloth or sponge never directly onto the product, as drops could enter openings and gaps and cause damage.
-
Page 18: Indications Importantes
• Pour le nettoyage avec produit vaporisé liquide, en aucun cas sur la robinetterie, mais au contraire aspergé sur le chiffon (torchon, éponge) et effectuer comme cela le nettoyage, car les aérosols peuvent pénétrer dans les ouvertures et fentes de la robinetterie et peuvent provoquer des détériorations. • Après le nettoyage rincez avec suffisamment d’eau claire pour éliminer les restes de produits attachés. • L’utilisation d’appareil de nettoyage à vapeur n’est pas autorisée, car les températures importantes peuvent détériorer les produits. Indications importantes • Les produits pour le corps comme les savons liquides, les shampooings ou les gels de douche peuvent causer des détériorations. • Ici aussi on doit: Après l’utilisation rincer soigneusement les restes avec de l’eau. Conseil de nettoyage • Les deteriorations imputables à un mauvais entretien ne peuvent être pris en considération par notre garantie. • Par l’action d’un nettoyant sur les revêtements déjà endommagé il se produit une aggravation des dég�ts. des dég�ts. Recomendación de limpieza para los productos de Hansgrohe Hoy en día, las griferías de baño y de cocina así como duchas modernas se componen de materiales muy distintos para satisfacer las exigencias del mercado respecto al diseño y la funcionalidad. Para evitar daños y reclamaciones hay que... -
Page 19: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. This warranty is non-transferable. WHAT IS COVERED BY THE WARRANTY The warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in material or workmanship as follows: Hansgrohe will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Hansgrohe may elect to refund the purchase price in exchange for the return of the product. LENGTH OF WARRANTY Replacement or repaired parts of products will be covered for the term of this warranty, as stated in the following two sentences. If you are a consumer who purchased the product for use primarily for personal, family or household purposes, this warranty extends for as long as you own the product and the home in which the product is originally installed. If you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Hansgrohe & Commercial products, and (ii) for 5 years, with respect to Axor products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: A. Conditions, malfunctions or damage not resulting from defects in material or workmanship. - Page 20 When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid. EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
