Figure 46. Evacuation time vs. pressure rise
1600
1400
1200
1000
800
600
400
Initial evacuation pressure.
200
-10
0
Compressors
Scroll Compressor Failure Diagnosis and
Replacement
If compressor failure is suspected, refer to COM-SVN01 for
detailed information regarding compressor failure diagnosis
and replacement of scroll compressors.
SCXF-SVX01T-EN
State of equilibrium indicates the
true amount of moisture left in
the system. It indicates that no
leaks are present and the system
is properly evacuated.
10
20
30
Time in Minutes
Continously increasing pressure
indicates the presence of leaks,
moisture, or both.
40
50
60
Maintenance
State of equilibrium indicates the
true amount of moisture left in
the system. It indicates that no
leaks, but requires further evacuation.
70
80
90
85
