Dimensional Data
Figure 9. Detail A: electrical connections 20 to 110 tons
Table 8. Discharge dimensions (in.)
Unit Model Fan Size
SCWF 20-25 18"
SCWF 29-32 18"
SCWF 35-38 20"
SCWF 42-58 25"
SCWF 65-80 27.5"
SCWF 90-110 27.5"
SCWF 38 18"
SCWF 46 18"
SCWF 58 18"
SCWF 72 20"
24
40 3/8" (20-38 Ton)
A B
Standard Fan
31.85 23.5
31.85 23.5
30.5 26.2
43.75 33
43.5 33.5
50.7 33.5
Low Flow Fan Option
44.8 23.25
44.8 23.25
44.8 23.25
43.4 26.2
C D
23.11 20.4
23.11 20.4
21.25 25.75
31.5 31.5
28.63 34.5
28.8 34.5
36.78 19
36.78 19
36.78 20.4
34.77 24.6
