Table 2. SCWF/SIWF Water-cooled self-contained, 46-110 tons (continued)
Unit Size 46
Capacity Steps - %
100/70/41/30/0
Notes:
1. Compressors are Trane 3-D™ scroll.
2. All units operate with R-410A. Units ships with full operating charge.
3. Maximum cfm limits are set to prevent moisture carryover on the evaporator coil.
4. Minimum cfm limits are set to ensure stable thermal expansion valve operation at low load conditions.
Table 3. SCWF/SIWF water volumes
Unit Size W/o Economizer
Gallons
20 9.0
22 9.0
25 9.0
29 9.0
32 9.0
35 10.0
38 10.0
42 15.0
46 15.0
52 15.0
58 15.0
65 16.0
72 16.0
80 16.0
90 22.5
100 23.0
110 24.0
Table 4. SCWF/SIWF Refrigerant circuits, number of compressors by circuit
Unit Size 1
20/22/25 Ton 1- 10T
29/32 Ton 1- 15T
35/38 Ton 1- 10T
42/46 Ton 1- 15T
52/58 Ton 1- 15T
60/72 Ton 1- 15T
80 Ton 1- 15T
90 Ton 1- 15T
100 Ton 1-15T
SCXF-SVX01T-EN
52 58 65
100/65/ 100/65/30/ 100/71/
32/0 0 44/24/0
Water Volume in U.S. Gallons / Liters
With Mech. Cleanable Econ
Liters Gallons
34.1 17.4
34.1 17.4
34.1 17.4
34.1 20.5
34.1 20.5
37.9 21.9
37.9 21.9
56.8 32.2
56.8 32.2
56.8 36.9
56.8 36.9
60.6 37.9
60.6 37.9
60.6 37.9
85.2 50.1
87.1 50.6
90.8 51.6
2 3
1- 10T N/A
1- 10T N/A
1- 10T 1- 10T
1- 10T 1- 10T
1- 15T 1- 15T
1- 15T 1- 15T
1- 15T 1- 15T
1- 15T 1- 15T
1-15T 1-15T
72 80
100/71/43/ 100/73/46/ 100/80/40/
23/0 20/0 20/0
Liters
65.9
65.9
65.9
77.6
77.6
82.9
82.9
121.9
121.9
139.7
139.7
143.5
143.5
143.5
189.6
191.5
195.3
Circuit
4
N/A
N/A
N/A
N/A
N/A
1- 10T
1- 15T
1- 15T
1-15T
General Data
90 100 110
100/75/38/ 100/66/33/
19/0 17/0
With Chem. Cleanable Econ
Gallons Liters
16.9 64.0
16.9 64.0
16.9 64.0
18.8 71.2
18.8 71.2
20.2 76.5
20.2 76.5
31.4 118.9
31.4 118.9
35.9 135.9
35.9 135.9
36.9 139.7
36.9 139.7
36.9 139.7
N/A N/A
N/A N/A
N/A N/A
5 6
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
1- 15T
1-10T 1-10T
15
