Airside Economizer

Figure 13. Airside economizer
Table 13. Airside economizer sizes and dimensions (in.)
Size A
SXWF 20 44
SXWF 22 44
SXWF 32 44
SXWF 35-38 44
SXWF 42 57-3/8
SXWF 46 57-3/8
SXWF 52-58 57-3/8
SXWF 65-80 57-3/8
H (2)
Size
SXWF 20 11-1/8
SXWF 22 11-1/8
SXWF 32 11-1/8
SXWF 35-38 11-1/8
SXWF 42 15
SXWF 46 15
SXWF 52-58 9-1/4
SXWF 65-80 9-1/4

Service Clearances

See figure and table below for recommended service and
code clearances.
SCXF-SVX01T-EN
B C D
74 22-3/8 81-3/4
74 22-3/8 81-3/4
74 22-3/8 81-3/4
74 22-3/8 81-3/4
86-1/2 13-1/4 104-3/8
86-1/2 13-1/4 104-3/8
86-1/2 13-1/4 104-3/8
86-1/2 13-1/4 104-3/8
J K L
20-1/2 22-1/4 16
20-1/2 22-1/4 16
20-1/2 22-1/4 9-1/2
20-1/2 22-1/4 9-1/2
26 24-3/4 20-3/8
26 24-3/4 20-3/8
37-1/2 19 20-3/8
37-1/2 19 20-3/8
F (1) F (2)
E
8-3/4 66-3/4 49-3/4
8-3/4 68-5/8 49-3/4
8-3/4 74-1/4 62-3/4
8-3/4 73-1/2 62-3/4
8-7/8 83-5/8 63-1/2
8-7/8 94-1/8 63-1/2
8-7/8 96-5/8 63-1/2
8-7/8 96-5/8 63-1/2
Weight
M
49-3/4 430
49-3/4 500
62-3/4 500
62-3/4 500
63-1/2 640
63-1/2 640
63-1/2 700
63-1/2 800
Dimensional Data
G (1) G (2) H (1)
23-1/4 20-1/2 9-3/4
28-1/8 20-1/2 7-1/4
23-1/4 20-1/2 9-3/4
33 20-1/2 4-7/8
33 26 2-1/2
28-1/8 26 6-7/8
52 37-1/2 1-7/8
52 37-1/2 1-7/8
