4.3

Front Panel LCD Display

The display on the JVA Z114 shows the voltage at the fence and return terminals.
The left is the return and the right is the feed voltage. Arrows at the top of the display
indicate that the Energizer is in Conventional Mode. When configured for Bi-Polar
operation the left side is the positive return Voltage and the right is the negative
return Voltage.
The Lcd also shows the programming option and current setting when in program-
ming Mode. This allows the programming options settings to be checked easily.
4.4

Inputs and Outputs

see section 6.
4.5

Status Codes

see section 6.2.
4.6

Keypad (Optional)

A keypad can be used to remotely monitor and control the Z114. It is also used to set
the programmable options for installer programming options, see Section 8.
4.7

Z Series Models

Z11 Single Zone, conventional 1.5 Joule
Z13 Single Zone, conventional 2.8 Joule
Z14 Single Zone, conventional or Bi-Polar 4 Joule
Z14r Z14 with relays and Ir Tamper circuit
Z18 Single Zone, conventional or Bi-Polar 8 Joule, contains relays and IR Tamper
circuit
Z114 Single Zone, conventional or Bi-Polar 14 Joule
Z28 Dual Zone, conventional 8 Joule (4 Joules per zone)
ZM1 single zone start of fence monitor with distant Fault detection™
ZM20 Twenty sector loop monitor
Note: A Z114 configured for Bi-polar may be referred to as a Z114A.
