USE AND CARE GUIDE
TUU R TLE ISLE PERGOLA
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
pergola
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY GG-11110-AAA
Summary of Contents for HAMPTON BAY GG-11110-AAA
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM THANK YOU pergola continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Pre-Assembly . -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Please read this entire instruction manual prior to assembly. Verify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a non-abrasive surface to avoid scratching. NOTE: More than one person may be required to complete the assembly of this product. -
Page 4: Package Contents
(continued) Pre-Assembly PACKAGE CONTENTS Part Description Quantity Part Description Quantity Post A S ide straight beam 2 Post B Middle post Top middle front beam Post C Post D Top middle back beam S upport bar Back right straight beam Connector tube Back left straight beam F ront right straight beam... -
Page 5: Assembly
Assembly Attaching the leg base plates to the posts □ bolts ( AA) with M6 Allen wrench ( F F ) . Attach the leg base plates ( T) to the posts ( A, B, C, D) and middle post ( M) using the M6 x 20 mm □... - Page 6 (continued) Assembly Attaching the back right staight beam and side straight beam to the post □ Attach the back right straight beam ( E) and side straight beam 1 ( K ) to the post ( A) using the M6 x 20 mm bolts ( AA) with M6 Allen wrench ( F F ) . □...
- Page 7 (continued) Assembly Attaching the side straight beam and front right straight beam to the post □ Attach the side straight beam 2 ( L) and front right straight beam ( G ) to the post ( D) using the M6 x 20 mm bolts ( AA) with M6 Allen wrench ( F F ) .
- Page 8 (continued) Assembly Attaching the front straight beam using the beam connector □ Attach the front right straight beam ( G ) to the front left straight beam ( H) with the beam connector ( U ) using the M6 x 20 mm bolts ( AA) with M6 Allen wrench ( F F ) .
- Page 9 (continued) Assembly Attaching the connector tube □ Attach the connector tube ( Q ) to the top of posts ( A, B, C and D) with the M6 x 45 mm bolts ( CC) using M6 Allen wrench ( F F ) . □...
- Page 10 Assembly (continued) Attaching the top middle beam □ Attach the top middle front beams ( N) to the top middle back beams ( O) with the beam connectors ( U ) using the M6 x 20 mm bolts ( AA) . □...
- Page 11 Assembly (continued) Attaching one decorative tube □ Attach the four decorative tubes 1 ( I) to the rabbet of the posts ( A, B and M) with M6 x 35 mm bolts ( BB) and M6 nuts ( DD) using M6 hex wrench ( G G ) .
- Page 12 Assembly (continued) Attaching the top middle beam □ Attach the top middle beams ( N and O) to the front and back straight beams ( E, F , G and H) with M6 x 45 mm bolts ( CC) using M6 Allen wrench ( F F ) .
- Page 13 Care and Maintenance □ For cleaning, use a mild detergent solution, rinse with water, and allow to air dry. Do not use acetone, abrasive, or other special detergents as they would be harmful to the product's nish. □ Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
- Page 14 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
