Item # 1006 471 543
GG-11076-AAP
Model #
USE AND CARE GUIDE
SPENCER HILL GAZEB O
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-841-1350
HAMPTONBAY.COM
THANK YOU
gaz ebo
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY SPENCER HILL GG-11076-AAP
Summary of Contents for HAMPTON BAY SPENCER HILL GG-11076-AAP
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HAMPTONBAY.COM THANK YOU gaz ebo continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Pre-Assembly . -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Please read this entire instruction manual prior to assembly. Verify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a non-abrasive surface to avoid scratching. NOTE: More than one person may be required to complete the assembly of this product. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Ｈ Ｇ Part Description Quantity Post Long left beam Long right beam S hort left beam S hort right beam Top diagonal support bar 1 S hort middle support bar Long middle support bar Top diagonal support bar 2 Top support bar Top support bar connector Corner connector... -
Page 5: Assembly
Assembly Attaching the U shape clips and leg base plates to the posts □ Attach the U shape clips 1( P) and leg base plates ( K ) to the posts ( A) using the M6 x 15 mm combination bolts ( BB) with an M6 Allen wrench ( F F ) . - Page 6 (continued) Assembly Attaching the short beams to the posts □ Attach the short beams ( C and C1) to the posts ( A) using the M6 x 12 mm bolts ( AA) . □ F ully tighten all the bolts with an M6 Allen wrench ( G G ) . Attaching the diagonal support bars □...
- Page 7 (continued) Assembly Attaching the long beams to the posts □ Attach the long left and right beams ( B and B1) to the posts ( A) using the M6 x 12 mm bolts ( AA) . □ Attach the left and right diagonal support bars ( N and O) to the posts ( A) and the short beams ( C and C1) using the M5 x 12 mm bolts ( EE) . □...
- Page 8 (continued) Assembly Attaching another U shape clips to the beams □ Attach the U shape clips 2 ( Q ) to the beams using M6 x 15 mm combination bolts ( BB) . Loosely tighten the bolts. □ Attach the corner connector ( ) to the posts ( A) using the M5 x 12 mm bolts ( EE) . F ully tighten the bolts. Attaching the top support bars □...
- Page 9 (continued) Assembly Attaching the top support bar connectors to top support bar □ Attach the top support bar connectors ( I) to the top support bar ( H) using the M6 x 15 mm combination bolts ( BB) . □ F ully tighten all the bolts with an M6 Allen wrench ( G G ) . Ｈ...
- Page 10 (continued) Assembly Attaching the short middle support bars to the top support bar connectors □ Attach the short middle support bars ( E) to the top support bar connectors ( I) using the M6 x 15 mm combination bolts ( BB) . □...
- Page 11 (continued) Assembly I nserting the canopy covers into the frame □ Insert the big and small canopy covers ( S and T) to the frame according to the following image and fix them into the frame. H anging the mosq uite net onto the beams □...
- Page 12 Care and Maintenance □ For cleaning, use a mild detergent solution, rinse with water, and allow to air dry. Do not use acetone, abrasive, or other special detergents as they would be harmful to the product’ s nish. □ Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
- Page 13 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HAMPTONBAY.COM Retain this manual for future use.
