Item # 1006 471
546
Model #
GG-110
-AS
78
P
USE AND CARE GUIDE
HOLLY BROO
K
GRILL
GAZEB O
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-800-841-1350
HAMPTONBAY.COM
THANK YOU
gaz ebo
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY HOLLY BROOK GG-11078-ASP
Summary of Contents for HAMPTON BAY HOLLY BROOK GG-11078-ASP
- Page 1 8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HAMPTONBAY.COM THANK YOU gaz ebo continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........2 Pre-Assembly . -
Page 3: Pre-Assembly
Pre-Assembly PLANNING ASSEMBLY Please read this entire instruction manual prior to assembly. Verify all parts packed in the carton against the parts list. Remove all protective materials and place the parts on a non-abrasive surface to avoid scratching. NOTE: More than one person may be required to complete the assembly of this product. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Ｇ Ｈ Part Description Quantity Part Description Quantity Pillar 1 Connector 1 Pillar 2 Corner rib brace Long crossbeam Center rib brace S hort crossbeam S upport bracket 1 Roof ribs 1 S upport bracket 2 Roof ribs 2 F oot base Roof top support 1... -
Page 5: Assembly
Assembly Attaching the foot base to the pillars □ Attach the foot bases ( M) to the pillars 1/ 2 ( A1 and A2) using the M6 x 15 mm bolts ( AA) with M6 Allen wrench ( □ F ully tighten all the bolts. □... - Page 6 (continued) Assembly Attaching the support brack ets to the shelf and pillar □ Attach the support brackets ( L and L1) to the shelves 1( H) and pillars 1/ 2 ( A1 and A2) using the M6 x 15 mm bolts ( AA) . Attaching the corner protectors □...
- Page 7 (continued) Assembly Attaching the roof ribs □ Assemble the roof frame by attaching the four roof ribs 1 ( D) to the roof top brace ( ) using the M6 x 12 mm bolts as shown in the diagram. Attaching the roof to the gaz ebo frame □...
- Page 8 (continued) Assembly Attaching the roof top support using connectors □ Attach the two roof top support 2 ( G ) and two roof top support 1 ( F ) with connectors 1 ( K 1) using M6 x 15 mm bolts ( AA) . Attaching the assembled roof support to the roof ribs □...
- Page 9 (continued) Assembly Attaching the roof ribs to the assembled roof top support □ Attach the four roof ribs 2 ( E) to the assembled roof top ( G / F ) using the M6 x 15 mm bolts ( AA) . Attaching the roof plates □...
- Page 10 (continued) Assembly Attaching the roof top borders to the roof □ Attach the roof top borders 1 ( I3) to the long edge of the roof, and roof top borders 2 ( I4) to the short edge of the roof. □...
- Page 11 (continued) Assembly Attaching the roof plates O , P, O 1, Q , Q 1 □ Attach the roof plates 1/ 2/ 3/ 4/ 5 ( O, P, O1, Q , Q 1) as shown in the diagram. HAMPTONBAY.COM Please contact 1-800-841-1350 for further assistance.
- Page 12 Assembly (continued) I nstalling the roof plates O , P, O 1, Q , Q 1 to the gaz ebo □ Install the roof plates on the long sides of the gazebo. Work your way from left to right. S tart by sliding the roof plate ( O) into position. Then overlap roof plate ( P) as shown in the diagram and slide roof plate ( P) into position.
- Page 13 (continued) Assembly Attaching the roof borders to the long edge of the roof □ Attach the roof borders 2 and 3 ( I2 / I3) to the long edge of the roof. □ Attach the roof borders 1 ( I ) to the short edge of the roof. □...
- Page 14 (continued) Assembly Attach the side panel to the shelf □ Attach the side panel of shelves ( U ) to the shelfs 2 ( T) using the M6 x 35 mm bolts ( EE) . □ Attach another shelf in the same way. Attaching the back panel to the shelf □...
- Page 15 (continued) Assembly Attaching the shelf box to the pillars □ Attach the shelf box to the pillars 1/ 2 ( A1 and A2) using the M6 x 35 mm bolts. □ Adj ust the position of the gazebo and insert the stakes ( HH) into the holes of all the four foot bases. Care and Maintenance □...
- Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-841-1350 HAMPTONBAY.COM Retain this manual for future use.
