Item # 1001 846 977
Model # GCS00394A
USE AND CARE GUIDE
STEEL WICKER DAYBED SWING-FRAME
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this daybed. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY GCS00394A
Summary of Contents for HAMPTON BAY GCS00394A
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this daybed. We strive continually to create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty 3-YEAR FRAME AND 2-YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three (3) years, and a two (2) year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M8x100 Combination Bolt 12+1 M6x15 Combination Bolt 52+1 Washer 18+1 Plastic Washer Hex Wrench... -
Page 5: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Long Beam Short Beam Middle Beam 2 Middle Beam 1 Post Canopy Corner Connector Post Base Post Base Cover Top Tube Shade Rod HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance. - Page 6 Assembly Attaching the Post Base Covers and the Post Bases to the Posts Insert the post base covers (I) into the post (E) from the bottom. Attach the post (E) to the post bases (H) using M6x15 combination bolts (BB). Repeat this step for other 3 posts.
- Page 7 Assembly (continued) Attaching the Middle Beams 1 and Middle Beam 2 to the Long Beams Attach the middle beams 1 (D) and middle beam 2 (C) to the long beams (A) using M6x15 combination bolts (BB) and washers (CC). Do not tighten the bolts at this step. Connecting the Corner Connector to the Beams and Posts Connect the corner connector (G) to the beams (A and B) and posts (E) using M6x15 combination bolts (BB).
-
Page 8: Care And Cleaning
Assembly (continued) Putting the Canopy on the Beams, Attaching the Shade Rods to the Posts Put the canopy (F) on the beams (A and B). Attach the shade rods (K) into the canopy (F), and tighten the bandage to post (E). Attaching the Top Tubes to the Long Beams Attach the top tubes (J) to the long beams (A) using M8x100 combination bolts (AA), washers (CC) and plastic washers (DD). - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
- Page 10 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this swing. We strive continually to create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 11: Important Safety Instructions
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 12: Warranty
Warranty 3-YEAR FRAME AND 3-YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for three (3) years, and a three (3) year limited warranty for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 13: Hardware Included
Pre-assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x45 Combination Bolt M6x15 Combination Bolt Hex Wrench... -
Page 14: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Seat Back Right Arm Left Arm Seat Cushion Back Cushion Bolster Short Iron Chain Long Iron Chain HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance. - Page 15 Assembly Connecting the Arms to the Seat Place the seat (A) on a soft surface. Insert the right arm (C) and left arm (D) into the seat (A), and secure with M6x15 combination bolts (BB). NOTE: Loosely tighten all the bolts using the hex wrench (CC). Connecting the Back to the Arms Attach the back (B) to the right arm (C) and left arm (D), and secure with M6x45 combination bolts (AA).
- Page 16 Assembly (continued) Placing the Seat/Back Cushions and Bolsters on the Seat Put the seat cushion (E), back cushion (F) and bolster (G) on the seat. Attaching the Long and Short Iron Chains Attach the short iron chains (H) to the front of the seat (A). Attach the long iron chains (I) to the back of the seat (A).
- Page 17 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
