No.
Name
10
Audio Out
11
LAN / PoE
12
I/O Terminal Block
13
DC 12V Port
14
Status LED
15
Power LED
166
Description
Connects a speaker for audio output.
Connects to a 10/100 Ethernet or PoE.
Connects to I/O devices. For details, see
Fixed IP Dome Chapter in the GV-IPCAM
H.264 Firmware Manual on the Software
DVD.
Connects to power.
Turns on (green) when the system
operates normally and turns off when
system error occurs.
Turns on (green) when the power is on and
turns off when there is no power supply.
