Summary of Contents for Linak MEDLINE & CARELINE CBJ-Home
- Page 1 CBJ-Home Battery Replacement User manual LINAK.COM/MEDLINE-CARELINE Page 1 of 12...
-
Page 2: Table Of Contents
Contents Preface ............................3 Important information ........................4 Safety instructions ......................... 4 General information about JUMBO Home ................... 5 Battery information ........................5 Prior to first use of batteries ......................5 Maintenance of batteries ......................5 Authorised replacement of batteries .................... 5 Tamper proof .......................... -
Page 3: Preface
LINAK systems are high-tech products based on many years of experience in manufacturing and development of actuators, electric control boxes, controls and chargers. This User Manual will tell you how to replace the batteries in your LINAK Control Box JUMBO Home (CBJ-Home). -
Page 4: Important Information
Important information Description of the various signs used in this manual. Warning! Failure to comply with these instructions may result in accidents involving serious personal injury. Failing to follow these instructions can result in the product being damaged or destroyed. Safety instructions Safe use of the system is possible only when the battery replacement is carried out according to the instructions in this user manual. -
Page 5: General Information About Jumbo Home
Frequent and high-powered discharges reduce the battery life. Authorised replacement of battery Only an authorised LINAK service centre or a properly trained customer should change the battery in a CBJ-Home. If a CBJ-Home is opened and a battery changed by an unauthorised person there is a risk that it may malfunction at a later date. -
Page 6: Types Of Batteries That Can Be Used For Replacement
Furthermore, the products must not be exposed to violent treatment. In the event of this, the warranty will be ineffective / invalid. LINAK’s warranty is only valid if the system is unopened and has been used correctly. -
Page 7: Replacement Of Batteries - Step By Step
Replacement of batteries - step by step: 1. Remove all external cables from the control box 2. Dismount the CBJ-Home. 3. Unscrew and remove the 7 torx screws on the rear of the CBJ-Home. 4. Remove the back cover. Please note that there are two assembly versions (Produced before 1 January 2008) (Produced after 1 January 2008) Note whether the battery poles are pointing downwards... - Page 8 8. Replace the batteries by same type or as (LINAK A/S part number BA0CBJH00 (2 batteries with 1 wireharness)) described in the section “Battery information”. 9. Remount the wires to the new batteries’ poles. (+ = red, - = black).
- Page 9 Please note that the removing of glue residue may take up to 5 minutes. The security label can be bought at LINAK A/S: Article no. 0891021-A, in rolls of 1,000 pcs. 16. Remount the CBJ-Home in the application.
-
Page 10: Disposal Of Batteries
10) must not be blocked or covered as a positive pressure may occur with risk of explosion. Disposal of the batteries The batteries, which are lead-acid batteries, can be returned to LINAK or dispose of in the same way as car batteries. Page 10 of 12... - Page 11 Page 11 of 12...
-
Page 12: Addresses
While LINAK uses its best efforts to fulfil orders, LINAK cannot, for the same reasons as mentioned above, guarantee the availability of any particular product. Therefore, LINAK reserves the right to discontinue the sale of any product displayed on its website or listed in its catalogues or other written material drawn up by LINAK.
