ClimateMaster Genesis Series Installation Operation & Maintenance

Water-to-water heat pumps
Hide thumbs
Table of Contents

Advertisement

Quick Links

Genesis Series
GSW036, 60 & 120
Water-to-Water
Heat Pumps
Revision: 16 Oct, 2008B
G E N E S I S W A T E R - T O - W A T E R ( G S W ) S E R I E S
I N S T A L L A T I O N , O P E R A T I O N & M A I N T E N A N C E

Table of Contents

3
4
5
6
7
8
8
9
10
11
12
W A T E R - T O - W A T E R
13
15
18
19
26
27
28
29
30
32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genesis Series and is the answer not in the manual?

Questions and answers

Carl Baumann
January 21, 2025

I have a GSV036AGC01JLTS model. I no longer have the documentation. I **** looking for whatever manuals are available.

0

Related Manuals for ClimateMaster Genesis Series

Summary of Contents for ClimateMaster Genesis Series

  • Page 1: Table Of Contents

    Genesis Series GSW036, 60 & 120 Water-to-Water Heat Pumps Revision: 16 Oct, 2008B G E N E S I S W A T E R - T O - W A T E R ( G S W ) S E R I E S...

  • Page 3: Model Nomenclature

    G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v. : 1 6 O c t , 2 0 0 8 B Model Nomenclature S = Standard GS =Genesis Series C = Copper N = Cupro-Nickel W = Water to Water...

  • Page 4: General Information

    fi le all necessary claims with the or in locations subject to temperature or humidity carrier. Notify the ClimateMaster Traffi c Department of extremes (e.g., attics, garages, rooftops, etc.) Corrosive all damage within fi fteen (15) days of shipment.

  • Page 5: Physical Data

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 6: Gsw036 & 060 Dimensional Data

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 7: Gsw120 Dimensional Data

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 8: Installation

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 9: Load Plumbing Installation

    Piping Installation Optional pressure-rated hose assemblies designed CAUTION! specifi cally for use with ClimateMaster units are available. Similar hoses can be obtained from alternate suppliers. Corrosive system water requires corrosion resistant Supply and return hoses are fi tted with swivel-joint fi...

  • Page 10: Water-Loop Heat Pump Application

    Hose kits are an open type cooling tower is used continuously, chemical available from ClimateMaster in different confi gurations as treatment and fi ltering will be necessary. shown in Figure 2 for connection between the GSW Series and the piping system.

  • Page 11: Ground-Water Heat Pump Application

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 12: Water Quality Standards

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 13: Ground-Loop Heat Pump Application

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 14 C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 15: Electrical - Power Wiring

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 16 C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 17 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 18: Electrical - Low Voltage Wiring

    300 psig and a cut-in pressure of 250 psig. This pressure switch can be ordered from ClimateMaster with a 1/4” internal fl are connection as part number 39B0005N02. Water Solenoid Valves When using external solenoid valves on ground water installations.

  • Page 19: Wiring Diagrams

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 20 C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 21 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 22 C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 23 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 24 C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 25 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 26: Unit Starting & Operating Conditions

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 27: Piping System Cleaning & Flushing Procedure

    To avoid possible damage to a plastic (PVC) piping the unit and all components within the water system. system, do not allow temperatures to exceed 110°F. ClimateMaster will not be responsible or liable for damages from water leaks due to inadequate or CAUTION!

  • Page 28: Unit & System Checkout

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 29: Unit Start-Up Procedure

    T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 30: Preventive Maintenance

    C L I M AT E M A S T E R W AT E R - S O U R C E H E AT P U M P S G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.
  • Page 31 T H E S M A R T S O L U T I O N F O R E N E R G Y E F F I C I E N C Y G e n e s i s W a t e r- t o - W a t e r ( G S W ) S e r i e s R e v.

  • Page 32: Revision History

    ClimateMaster works continually to improve its products. As a result, the design and specifi cations of each product at the time of order may be changed without notice and may not be as described herein. Please contact ClimateMaster’s Customer Service Department at 1-405-745-6000 for specifi...

This manual is also suitable for:

Gsw036Gsw060Gsw120

Table of Contents
