- Page 1 MANUAL ENGLISH Blacklight 400W Ordercode: 80319 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Blacklight 400W Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Overview ..................................7 Backside ..................................8 Installation ................................... 8 Set Up and Operation ............................... -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Blacklight 400W User manual Safety Instructions Every person involved with the installation, operation and maintenance of this device has to: ... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Blacklight 400W Operating Determinations • This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. • The minimum distance between light output and the illuminated surface must be bigger than 1 meter. - Page 6 Blacklight 400W The Blacklight can be placed on a flat stage floor or mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug.
-
Page 7: Return Procedure
Blacklight 400W Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. -
Page 8: Description Of The Device
Blacklight 400W Description of the device Features The Blacklight 400W is a robust housing for the Blacklight 400W E40 discharge lamp. Input voltage: 240V, 50Hz Light source: E40 (not included) Power consumption: 400W Housing: Metal & Flame retardant plastic ... -
Page 9: Backside
09) Mounting bracket with inclination screw Installation Remove all packing materials from the Blacklight 400W. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. -
Page 10: Set Up And Operation
Connect the device to the main power supply. Installation of the lamp Follow the steps below to insert the Blacklight 400W E40 discharge lamp into the housing. 01) Remove the 4 screws and remove the front cover. 02) Insert the E40 lamp (82485) into the housing. -
Page 11: Maintenance
03) The electric power supply cables must not show any damages or material fatigue. The Blacklight 400W requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. -
Page 12: Product Specifications
• Disconnect fixture. Check settings intermittently match local AC voltage and and correct if necessary frequency Product Specifications Model: Showtec Blacklight 400W Input Voltage: 240V, 50Hz Power consumption: 400W (full output) Fuse: T4AL/250V Dimensions: 490 x 270 x 220 mm (LxWxH) -
Page 13: Dimensions
Blacklight 400W Dimensions Ordercode: 80319... -
Page 14: Notes
Blacklight 400W Notes Ordercode: 80319... - Page 15 Blacklight 400W Ordercode: 80319...
