W 400 SPRAY GUN
Before use, adjustment or maintenance, it is important to read this instruction manual very
GB
carefully. This manual must be stored in a safe place for any future reference that may be necessary.
This ANEST IWATA spray guns kit complies to ATEX regulations 94/9/EC, protection level:
II 2 G X Suitable for using Zones 1 and 2.
X marking: Any static electricity discharge from the spray gun is to be diverted to the ground via the conductive air hose as stipulated.
IMPORTANT
This spray gun should be operated only by an adequately trained operator, for safe use and maintenance of the equipment. Any
misuse or handling other than those indicated in this Instruction Manual is not covered by guarantee. ANEST IWATA disclaims all
responsibility for any accident or damage caused by failure to observe the operational and safety procedures in this manual. In
the interest of user friendliness, this manual contains information in a brief and concise form.
For any additional information you may require regarding spray gun operations, or if any missing parts or any damage during
transportation is found, please contact your nearest ANEST IWATA Company (see last cover page).
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following
marked items which are especially important.
WARNING Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or pro-
perty damage.
IMPORTANT
Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the mini-
mum necessary conditions. Follow national and local regulations regarding fire prevention, electricity and
safety as well as your own company regulations.
IMPORTANT SPECIFICATIONS
Max. Pressure:
6.8 bar (98 PSI)
Noise Level (LAeqT)
79.7 dB (A)
Spray conditions
Recommended
Measuring point
1m backwards from gun, 1,6 m height
TECHNICAL SPECIFICATIONS
Model
Nozzle orifice
Air cap Air pressure Fluid output
No.
at gun inlet
mm (in)
bar (PSI)
High T.E.C. W400 Gravity feed
W400-082G
0.8 (0.031)
2.0 (29)
W400-102G
1.0 (0.039)
2.0 (29)
W400-122G
1.2 (0.047)
2.0 (29)
LV2
W400-132G
1.3 (0.051)
2.0 (29)
W400-142G
1.4 (0.055)
2.0 (29)
W400-152G
1.5 (0.059)
2.0 (29)
W400-162G
1.6 (0.063)
2.0 (29)
W400-182G
1.8 (0.071)
LV1
2.0 (29)
W400-202G
2.0 (0.079)
R2
3.0 (43)
W400-251G
2.5 (0.098)
W1
3.0 (43)
Manufactured by:
ANEST IWATA Corporation 3176,Shinyoshida-cho, Kohoku-ku, Yokohama, 223-8501 Japan
Instruction Manual
Max. Temperature:
Atmosphere
5 ~ 40 °C
Air and fluid
5 ~ 43 °C
Air connection:
G 1/4"
Fluid connection:
M16x1.5 mm
Air
Pattern
consumption
width
Spray
ml/min
l/min (cfm)
mm (in)
distance
60
280 (9.8)
80 (3.1)
150 (5.9)
95
280 (9.8)
150 (5.9)
150 (5.9)
140
280 (9.8)
175 (6.9)
150 (5.9)
160
280 (9.8)
225 (8.8)
150 (5.9)
210
280 (9.8)
225 (8.8)
200 (7.9)
230
280 (9.8)
250 (9.8)
200 (7.9)
240
280 (9.8)
270 (10.6) 200 (7.9)
320
290 (10.2)
260 (10.2) 200 (7.9)
460
360 (12.7)
320 (12.6) 200 (7.9)
580
360 (12.7)
340 (13.3) 200 (7.9)
Weight
380 g
